ATP SWITCHDLN-115
< SYMPTOM DIAGNOSIS > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
1. Turn ignition switch OFF. (Stay for at least 5 seconds.)
2. Disconnect ATP switch harness connector.
3. Check continuity between ATP switch harness connector F55 terminal 9 and ground.
Also check harness for short to ground and short to power.
Are inspection results normal?
YES >> GO TO 4.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
4.CHECK ATP SWITCH
1. Turn ignition switch OFF. (Stay for at least 5 seconds.)
2. Disconnect ATP switch harness connector.
3. Remove ATP switch. Refer to DLN-16, "
Component Parts Location".
4. Push and release ATP switch and check continuity between ATP
switch terminals 8 and 9.
Are inspection results normal?
YES >> GO TO 5.
NO >> Replace ATP switch.
5.CHECK TRANSFER CONTROL UNIT
Check transfer control unit input/output signal. Refer to DLN-80, "
Reference Value".
Are inspection results normal?
YES >> GO TO 6.
NO >> Check transfer control unit pin terminals for damage or loose connection with harness connector. If any items are damaged, repair or replace damaged parts.
6.CHECK ATP WARNING LAMP
1. Turn ignition switch ON. (Do not start engine.)
2. Move A/T selector lever to P position.
3. Set 4WD shift switch from 4H to 4LO or 4LO to 4H.
Does ATP warning lamp turn ON while switching?
YES >> Inspection End.
NO >> GO TO DLN-107, "
Diagnosis Procedure".
Continuity should exist.
SDIA2394E
Terminal
Condition Continuity
8 - 9 Push ATP switch
Yes
Release ATP switch No
SDIA2757E
Revision: March 2010 2008 QX56
Page 1146 of 4083
![INFINITI QX56 2008 Factory Service Manual DLN-116
< SYMPTOM DIAGNOSIS >[ATX14B]
4WD SYSTEM DOES NOT OPERATE
4WD SYSTEM DOES NOT OPERATE
DescriptionINFOID:0000000001737201
The vehicle can not be put into 4WD mode. (Possible hydraulic malfunct INFINITI QX56 2008 Factory Service Manual DLN-116
< SYMPTOM DIAGNOSIS >[ATX14B]
4WD SYSTEM DOES NOT OPERATE
4WD SYSTEM DOES NOT OPERATE
DescriptionINFOID:0000000001737201
The vehicle can not be put into 4WD mode. (Possible hydraulic malfunct](/manual-img/42/57030/w960_57030-1145.png)
DLN-116
< SYMPTOM DIAGNOSIS >[ATX14B]
4WD SYSTEM DOES NOT OPERATE
4WD SYSTEM DOES NOT OPERATE
DescriptionINFOID:0000000001737201
The vehicle can not be put into 4WD mode. (Possible hydraulic malfunction)
Diagnosis ProcedureINFOID:0000000001737202
1.CHECK SYSTEM FOR
4WD SHIFT SWITCH
Perform trouble diagnosis for 4WD shift switch system. Refer to DLN-31, "
Diagnosis Procedure".
Are the inspection results normal?
YES >> GO TO 2.
NO >> Repair or replace damaged parts.
2.CHECK SYSTEM FOR CLUT CH PRESSURE SWITCH
Perform trouble diagnosis for clutch pressure switch system. Refer to DLN-70, "
Diagnosis Procedure".
Are the inspection results normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3.SYMPTOM CHECK
Check again.
Are the inspection results normal?
YES >> Inspection End.
NO >> GO TO 4.
4.CHECK TRANSFER CONTROL UNIT
Check transfer control unit input/output signal. Refer to DLN-80, "
Reference Value".
Are the inspection results normal?
YES >> GO TO 5.
NO >> Check transfer control unit pin terminals fo r damage or loose connection with harness connector.
If any items are damaged, repair or replace damaged parts.
5.CHECK TRANSFER INNER PARTS
1. Disassemble transfer assembly. Refer to DLN-140, "
Disassembly and Assembly".
2. Check transfer inner parts.
Are the inspection results normal?
YES >> Inspection End.
NO >> Repair or replace damaged parts.
Revision: March 2010 2008 QX56
Page 1147 of 4083
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTINGDLN-117
< SYMPTOM DIAGNOSIS > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
NOISE, VIBRATION AND HARSHN ESS (NVH) TROUBLESHOOTING
