Page 1161 of 4083
![INFINITI QX56 2008 Factory Service Manual REAR OIL SEALDLN-131
< ON-VEHICLE REPAIR > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
REAR OIL SEAL
Removal and InstallationINFOID:0000000001604414
REMOVAL
1. Partially drain the transfer fluid. Refer INFINITI QX56 2008 Factory Service Manual REAR OIL SEALDLN-131
< ON-VEHICLE REPAIR > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
REAR OIL SEAL
Removal and InstallationINFOID:0000000001604414
REMOVAL
1. Partially drain the transfer fluid. Refer](/manual-img/42/57030/w960_57030-1160.png)
REAR OIL SEALDLN-131
< ON-VEHICLE REPAIR > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
REAR OIL SEAL
Removal and InstallationINFOID:0000000001604414
REMOVAL
1. Partially drain the transfer fluid. Refer to DLN-127, "Replacement".
2. Remove the rear propeller shaft. Refer to DLN-194, "
Removal and Installation".
3. Remove the dust cover from the rear case. CAUTION:
Do not damage the rear case.
4. Remove the rear oil seal from the rear case using Tool. CAUTION:
Do not damage the rear case.
INSTALLATION
1. Install the new rear oil seal until it is flush with the end face of the
rear case using Tool.
CAUTION:
• Do not reuse oil seal.
• Apply petroleum jelly to oil seal.
2. Apply petroleum jelly to the circumference of the new dust cover. Position the new dust cover using the identification mark as
shown.
CAUTION:
• Do not reuse dust cover.
• Position the identification mark at the position shown.
WDIA0127E
Tool number : KV381054S0 (J-34286)
LDIA0139E
Tool number : ST30720000 (J-25405)
LDIA0140E
SDIA3436E
Revision: March 2010 2008 QX56
Page 1162 of 4083
DLN-132
< ON-VEHICLE REPAIR >[ATX14B]
REAR OIL SEAL
3. Install the new dust cover to the rear case using Tool.
CAUTION:
• Do not reuse dust cover.
• Apply petroleum jelly to dust cover.
4. Install the rear propeller shaft. Refer to DLN-194, "
Removal and
Installation".
5. Refill the transfer with fluid and check for fluid leakage and fluid level. Refer to DLN-127, "
Replacement".
Tool number : KV40105310 ( — )PDIA0116E
Revision: March 2010
2008 QX56
Page 1163 of 4083
![INFINITI QX56 2008 Factory Service Manual SIDE OIL SEALDLN-133
< ON-VEHICLE REPAIR > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
SIDE OIL SEAL
Removal and InstallationINFOID:0000000001604415
REMOVAL
1. Remove the front propeller shaft. Refer to INFINITI QX56 2008 Factory Service Manual SIDE OIL SEALDLN-133
< ON-VEHICLE REPAIR > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
SIDE OIL SEAL
Removal and InstallationINFOID:0000000001604415
REMOVAL
1. Remove the front propeller shaft. Refer to](/manual-img/42/57030/w960_57030-1162.png)
SIDE OIL SEALDLN-133
< ON-VEHICLE REPAIR > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
SIDE OIL SEAL
Removal and InstallationINFOID:0000000001604415
REMOVAL
1. Remove the front propeller shaft. Refer to DLN-184, "Removal and Installation".
2. Remove the companion flange. Refer to DLN-140, "
Disassembly and Assembly".
3. Remove the transfer control device from the transfer assembly. Refer to DLN-134, "
Removal and Installa-
tion".
4. Remove the side oil seal using suitable tool. CAUTION:
Do not damage shift cross.
INSTALLATION
1. Install the new side oil seal until it is flush with the end face ofcase using Tool.
CAUTION:
• Do not reuse oil seal.
• Apply petroleum jelly to oil seal.
2. Install the transfer control device to the transfer assembly. Refer to DLN-134, "
Removal and Installation".
3. Install the companion flange. Refer to DLN-140, "
Disassembly
and Assembly".
4. Install the front propeller shaft. Refer to DLN-184, "
Removal and Installation".
SDIA2666E
Tool number : ST22360002 (J-25679-01)
SDIA2665E
Revision: March 2010 2008 QX56
Page 1164 of 4083
DLN-134
< ON-VEHICLE REPAIR >[ATX14B]
TRANSFER CONTROL DEVICE
TRANSFER CONTROL DEVICE
Removal and InstallationINFOID:0000000001604416
CAUTION:
• Change vehicle state to AUTO, and then remove and install transfer control device.
• Check 4WD shift indicator after installation. Refer to
DLN-119, "
Precaution for Transfer Assembly
and Transfer Control Unit Replacement".
1. Shift lever2. Actuator
SDIA2654E
Revision: March 2010 2008 QX56
Page 1165 of 4083
![INFINITI QX56 2008 Factory Service Manual AIR BREATHER HOSEDLN-135
< ON-VEHICLE REPAIR > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
AIR BREATHER HOSE
Removal and InstallationINFOID:0000000001604417
REMOVAL
INSTALLATION
CAUTION:
• Make sure t INFINITI QX56 2008 Factory Service Manual AIR BREATHER HOSEDLN-135
< ON-VEHICLE REPAIR > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
AIR BREATHER HOSE
Removal and InstallationINFOID:0000000001604417
REMOVAL
INSTALLATION
CAUTION:
• Make sure t](/manual-img/42/57030/w960_57030-1164.png)
AIR BREATHER HOSEDLN-135
< ON-VEHICLE REPAIR > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
AIR BREATHER HOSE
Removal and InstallationINFOID:0000000001604417
REMOVAL
INSTALLATION
CAUTION:
• Make sure there are no pinched or restricted areas on each air breather hose caused by folding or
bending when installing it.
• Install each air breather hose into the breather tube (4). Set each air breather hose with paint mark facing upward.
• Install actuator/transfer motor air breather hose and transfer air breather hose on clip (A) with the paint mark facing
upward.
AWDIA0010ZZ
1. Breather tube 2. Clip A3. Clip B
4. Clip C 5. Clip D6. Actuator
7. Air breather hose clamp 8. Clip E 9. Transfer motor
10. Breather tube (transfer) Vehicle front
z A/T breather hose (1)
z Transfer breather hose (2)
z Actuator/transfer motor breather hose (3)
z z Breather tube (4)
z z Paint marks (A)
ALDIA0110ZZ
z Actuator/transfer motor breather hose (1)
z Transfer breather hose (2)
z Clip (A)
z Paint marks (B)
ALDIA0111ZZ
Revision: March 2010 2008 QX56
Page 1166 of 4083
![INFINITI QX56 2008 Factory Service Manual DLN-136
< ON-VEHICLE REPAIR >[ATX14B]
AIR BREATHER HOSE
• Install clip (B) on actuator/tr
ansfer motor air breather hose
and transfer air breather hose with the paint mark matched.
• Install actua INFINITI QX56 2008 Factory Service Manual DLN-136
< ON-VEHICLE REPAIR >[ATX14B]
AIR BREATHER HOSE
• Install clip (B) on actuator/tr
ansfer motor air breather hose
and transfer air breather hose with the paint mark matched.
• Install actua](/manual-img/42/57030/w960_57030-1165.png)
DLN-136
< ON-VEHICLE REPAIR >[ATX14B]
AIR BREATHER HOSE
• Install clip (B) on actuator/tr
ansfer motor air breather hose
and transfer air breather hose with the paint mark matched.
• Install actuator/transfer moto r air breather hose (1) and trans-
fer air breather hose (2) on clip (B) and clip (C) with the paint
mark (A) and (D) facing upward.
• Install the actuator air breather hose into the actuator (case connector) until the hose end reaches the base of the tube.
Set actuator air breather hose with paint mark facing leftward.
• Install clip (B) on transfer motor air breather hose (2) and transfer air breather hose (1) with the paint mark (A) matched.
z Actuator/transfer motor breather hose (1)
z Transfer breather hose (2)
z Paint marks (A)
z Clip (B)
AWDIA0011ZZ
z Actuator/transfer motor breather hose (1)
z Transfer breather hose (2)
z Paint marks (A)
z Clip (B)
z Clip (C)
z Paint marks (D)
AWDIA0012ZZ
SDIA3226E
z Transfer breather hose (1)
z Actuator/transfer motor breather hose (2)
z z Paint marks (A)
z Clip (B)
AWDIA0013ZZ
Revision: March 2010 2008 QX56
Page 1167 of 4083
AIR BREATHER HOSEDLN-137
< ON-VEHICLE REPAIR > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
• Install the transfer air breather hose into the breather tube (transfer, metal connector) un til the hose end reaches the
base of the tube. Set transfer air breather hose with paint
mark facing upwards.
• Install the transfer motor ai r breather hose into the transfer
motor (case connector) until the hose end reaches the end of
the curved section. Set transfer motor air breather hose with
paint mark facing leftward.
SDIA3196E
SDIA3194E
Revision: March 2010 2008 QX56
Page 1168 of 4083
![INFINITI QX56 2008 Factory Service Manual DLN-138
< ON-VEHICLE REPAIR >[ATX14B]
TRANSFER MOTOR
TRANSFER MOTOR
Removal and InstallationINFOID:0000000001604418
REMOVAL
1. Disconnect the transfer motor connector.
2. Remove the transfer motor air INFINITI QX56 2008 Factory Service Manual DLN-138
< ON-VEHICLE REPAIR >[ATX14B]
TRANSFER MOTOR
TRANSFER MOTOR
Removal and InstallationINFOID:0000000001604418
REMOVAL
1. Disconnect the transfer motor connector.
2. Remove the transfer motor air](/manual-img/42/57030/w960_57030-1167.png)
DLN-138
< ON-VEHICLE REPAIR >[ATX14B]
TRANSFER MOTOR
TRANSFER MOTOR
Removal and InstallationINFOID:0000000001604418
REMOVAL
1. Disconnect the transfer motor connector.
2. Remove the transfer motor air breather hose from the transfer
motor. Refer to DLN-135, "
Removal and Installation".
3. Remove the transfer motor bolts.
4. Remove the transfer motor.
INSTALLATION
1. Apply ATF to the new O-ring and install it to the transfer motor. CAUTION:
Do not reuse O-rings.
2. Fit the double-flat end of the transfer motor shaft into the slot of the sub-oil pump assembly. Then tighten to the specified torque.
Refer to DLN-140, "
Disassembly and Assembly".
CAUTION:
Be sure to install connector bracket.
3. Install the transfer motor air breather hose to the transfer motor. Refer to DLN-135, "
Removal and Installation".
4. Connect the transfer motor connector.
5. Check the transfer fluid. Refer to DLN-127, "
Inspection".
6. Start the engine for one minute. Then stop the engine and recheck the transfer fluid. Refer to DLN-127,
"Inspection".
SDIA2133E
SDIA2787E
Revision: March 2010 2008 QX56
