1991 MITSUBISHI MONTERO Service Manual

Fig. 142: Circuit Diagram DR-15 (1.6L)

Fig. 143: Flow Chart DR-15 (1.6L) (1 of 4)

Fig. 144: Flow Chart DR-15 (1.6L) (2 of 4)

Fig. 145: Flow Chart DR-15 (1.6L) (3 of 4)

Fig. 146: Flow Chart DR-15 (1.6L) (4 of 4)
DR-16: NO FAULT CODE TESTS - 1.6L

Fig. 147: Circuit Diagram DR-16 (1.6L)

Fig. 148: Flow Chart DR-16 (1.6L) (1 of 3)

Fig. 149: Circuit Diagram DR-16 (1.6L)
Fig. 150: Flow Chart DR-16 (1.6L) (2 of 3)
