1991 MITSUBISHI MONTERO Service Manual

Fig. 114: Flow Chart DR-6 (1.6L) (2 of 3)

Fig. 115: Flow Chart DR-6 (1.6L) (3 of 3)
DR-7: CODE 21 COOLANT TEMPERATURE CIRCUIT - 1.6L
Fig. 116: Circuit Diagram DR-7 (1.6L)

Fig. 117: Flow Chart DR-7 (1.6L) (1 of 2)

Fig. 118: Flow Chart DR-7 (1.6L) (2 of 2)
DR-8: CODE 22 CRANK ANGLE SENSOR CIRCUIT - 1.6L

Fig. 119: Circuit Diagram DR-8 (1.6L)

Fig. 120: Flow Chart DR-8 (1.6L)
DR-9: CODE 23 TOP DEAD CENTER SENSOR CIRCUIT - 1.6L

Fig. 121: Circuit Diagram DR-9 (1.6L)

Fig. 122: Flow Chart DR-9 (1.6L) (1 of 2)
