1991 MITSUBISHI MONTERO Service Manual

See FUEL DELIVERY under FUEL SYSTEM.
Idle Speed Control Servo
See IDLE SPEED under FUEL SYSTEM.
Power Transistor(s) & Ignition Coils
See IGNITION SYSTEMS.
Purge Control Solenoid Valve
See EVAPORATIVE CONTROL under EMISSION SYSTEMS.
Self-Diagnostic Connector
See SELF-DIAGNOSTIC SYSTEM.
Wastegate Control Solenoid Valve
See TURBOCHARGED ENGINES under AIR INDUCTION SYSTEM.
FUEL SYSTEM
FUEL DELIVERY
Electric fuel pump (located in gas tank) feeds fuel through
in-tank fuel filter, external fuel filter (located in engine
compartment) and fuel injector rail.
Fuel Pump
Consists of an impeller driven by a motor. Pump has an
internal check valve to maintain system pressure and a relief valve to
protect the fuel pressure circuit. Pump receives voltage supply from
Multi-Point Injection (MPI) control relay.
Fuel Pressure Control Solenoid Valve (Turbo Only)
Prevents rough idle due to fuel percolation. On engine
restart, if engine coolant or intake air temperatures reach a preset
value, ECU applies voltage to fuel pressure control solenoid valve for
2 minutes after engine re-start. Valve opens, allowing atmospheric
pressure to be applied to fuel pressure regulator diaphragm. This
allows maximum available fuel pressure at injectors, enriching fuel
mixture and maintaining stable idle at high engine temperatures.
Fuel Pressure Regulator
Located on fuel injector rail, this diaphragm-operated relief
valve adjusts fuel pressure according to engine manifold vacuum.
As engine manifold vacuum increases (closed throttle), fuel
pressure regulator diaphragm opens relief valve, allowing pressure to
bleed off through fuel return line, reducing fuel pressure.
As engine manifold vacuum decreases (open throttle), fuel
pressure regulator diaphragm closes valve, preventing pressure from
bleeding off through fuel return line, increasing fuel pressure.
FUEL CONTROL
Fuel Injectors
Fuel is supplied to engine through electronically pulsed
(timed) injector valves located on fuel rail(s). ECU controls amount\
of fuel metered through injectors based upon information received from
sensors.
IDLE SPEED
Air Conditioner Relay
When A/C is turned on with engine at idle, ECU signals ISC

motor to increase idle speed. To prevent A/C compressor from switching
on before idle speed has increased, ECU momentarily opens A/C relay
circuit.
Idle Speed Control (ISC) Motor
Controls pintle-type air valve (DOHC engines) or throttle
plate angle (SOHC engines) to regulate volume of intake air at idle.
During start mode, ECU controls idle intake air volume
according to coolant temperature input. After starting, with idle
position switch activated (throttle closed), fast idle speed is
controlled by ISC motor and fast idle air control valve (if equipped).\
When idle switch is deactivated (throttle open), ISC motor
moves to a preset position in accordance with coolant temperature
input.
When automatic transmission (if equipped) is shifted from
Neutral to Drive, A/C is turned on or power steering pressure reaches
a preset value, ECU signals ISC motor to increase engine RPM.
Fast Idle Air Control Valve
Some models use a coolant temperature-sensitive fast idle air
control valve, located on throttle body, to admit additional intake
air volume during engine warm-up. Control valve closes as temperature
increases, restricting by-pass airflow rate. At engine warm-up, valve
closes completely.
IGNITION SYSTEMS
DIRECT IGNITION SYSTEM (DIS) - DOHC ENGINES
Ignition system is a 2-coil, distributorless ignition system.
Crankshaft angle and TDC sensor assembly, mounted in place of
distributor, are optically controlled.
Power Transistors & Ignition Coils
Based on crankshaft angle and TDC sensor inputs, ECU controls
timing and directly activates each power transistor to fire coils.
Power transistor "A" controls primary current of ignition coil "A" to
fire spark plugs on cylinders No. 1 and 4 at the same time. Power
transistor "B" controls primary current of ignition coil "B" to fire
spark plugs on cylinders No. 2 and 3 at the same time.
Although each coil fires 2 plugs at the same time, ignition
takes place in only one cylinder since the other cylinder is on its
exhaust stroke when plug fires.
ELECTRONIC IGNITION SYSTEM - SOHC ENGINES
Mitsubishi breakerless electronic ignition system uses a disc
and optical sensing unit to trigger power transistor.
Power Transistor & Ignition Coil
Power transistor is mounted inside distributor with disc and
optical sensing unit. When ignition is on, ignition coil primary
circuit is energized. As distributor shaft rotates, disc rotates,
triggering optical sensing unit. ECU receives signals from optical
sensing unit. Signals are converted and sent to power transistor,
interrupting primary current flow and inducing secondary voltage.
IGNITION TIMING CONTROL SYSTEM
Ignition timing is controlled by ECU. ECU adjusts timing
based upon various conditions, such as engine temperature, altitude
and detonation (turbo vehicles only).

EMISSION SYSTEMS
EXHAUST GAS RECIRCULATION (EGR) CONTROL
Federal (Non-Turbocharged)
To lower oxides of nitrogen (NOx) exhaust emissions, a non-
computer controlled exhaust gas recirculation system is used. EGR
operation is controlled by throttle body ported vacuum. Vacuum is
routed through thermovalve to prevent EGR operation at low engine
temperatures.
Spring pressure holds EGR valve closed during low vacuum
conditions (engine idling or wide open throttle). When vacuum pressure\
increases and overcomes EGR spring pressure, EGR valve is lifted and
allows exhaust gases to flow into intake manifold for combustion.
California & Turbocharged
ECU controls EGR operation by activating EGR control solenoid
valve according to engine load. When engine is cold, ECU signals EGR
control solenoid valve to deactivate EGR.
California models are equipped with an EGR temperature
sensor. When EGR malfunction occurs, EGR temperature decreases and ECU
illuminates CHECK ENGINE (malfunction indicator) light.
EGR Control Solenoid Valve
Denies or allows vacuum supply to EGR valve, based upon ECU
commands.
Thermovalve
Denies or allows vacuum supply to EGR valve based on coolant
temperature.
EVAPORATIVE CONTROL
Fuel evaporation system prevents fuel vapor from entering
atmosphere. System consists of a special fuel tank with vapor
separator tanks (if equipped), vacuum relief filler cap, overfill
limiter (2-way valve), fuel check valve, thermovalve (if equipped),
charcoal canister, purge control valve, purge control solenoid valve
and connecting lines and hoses.
Purge Control Solenoid Valve
When engine is off, fuel vapors are vented into charcoal
canister. When engine is warmed to normal operating temperature and
running above idle, ECU energizes purge control solenoid valve,
allowing vacuum to purge valve.
Canister vapors are then drawn through purge valve into
intake manifold for burning. Purge control solenoid valve remains
closed during idle and engine warm-up to reduce HC and CO emissions.
HIGH ALTITUDE CONTROL (HAC)
This system compensates for variations in altitude. When
atmospheric (barometric) pressure sensor determines vehicle is above
preset altitude, ECU compensates by adjusting air/fuel mixture and
ignition timing. If HAC system is inoperative, there will be an
increase in emissions.
PCV VALVE
Positive Crankcase Ventilation (PCV) valve operates in the
closed crankcase ventilation system. Closed crankcase ventilation

system consists of PCV valve, oil separator, breather and ventilation
hoses.
PCV valve is a one-way check valve, located in valve cover.
When engine is running, manifold vacuum pulls PCV valve open, allowing
crankcase fumes to enter intake manifold. If engine backfires through
intake manifold, PCV valve closes to prevent crankcase combustion.
SELF-DIAGNOSTIC SYSTEM
Self-diagnostic system monitors input and output signals. On
all models, codes can be read using analog voltmeter. On some models,
scan tool can be used to read codes. For additional information, see G
- TESTS W/ CODES article.
CHECK ENGINE Light
Also called Malfunction Indicator Light by manufacturer,
comes on when ignition is turned on. Light remains on for several
seconds after engine has started. If an abnormal input signal occurs,
light comes on and code is stored in memory. If an abnormal input
signal returns to normal, ECU turns light off but code remains stored
in memory until cleared. If ignition is turned on again, light will
not come on until ECU detects malfunction during system operation.
NOTE: ECU diagnostic memory is retained by direct power supply
from the battery. Memory is not erased by turning off
ignition but is erased if battery or ECU is disconnected.

\003
TR AIL E R H IT C H W ELD C AN B REA K : N EW T R AIL E R H IT C H

1991 M it s u bis h i M onte ro
NHTSA RECALL BULLETIN
Models: 1986 Isuzu Trooper II
1987 Dodge Raider
1987 Isuzu Trooper II
1988 Dodge Raider
1988 Isuzu Trooper II
1989 Dodge Raider
1989 Isuzu Amigo
1989 Isuzu Trooper II
1990 Isuzu Amigo
1990 Isuzu Trooper
1991 Isuzu Amigo
1991 Isuzu Trooper
1991 Mitsubishi Montero
1991 Toyota Land Cruiser
1992 Mitsubishi Montero
1992 Toyota Land Cruiser
1993 Toyota Land Cruiser
Number of Affected Vehicles: 670
Beginning Date of Manufacture: 1992 MAR
Ending Date of Manufacture: 1993 JUN
FAULT:
Weld, Solder broken
SYSTEM:
Trailer hitch.
EQUIPMENT DESCRIPTION:
Reese class II trailer hitch, Part No. 06070.
DESCRIPTION OF DEFECT:
The weld on the receiver unit of the trailer hitch can break.
CONSEQUENCE OF DEFECT:
If the failure occurs, the trailer can separate from the towing
vehicle, and could result in a vehicle crash without warning.
CORRECTIVE ACTION:
Replace the trailer hitch.
NOTE:
If your vehicle is presented to the dealer from whom you purchased the
item on an agreed service date and the remedy is not provided or the
remedy does correct the safety-related defect or noncompliance, please
contact Reese Products warranty department at 1-800-326-1090, ext.
203. Also contact the National Highway Traffic Safety Administration's
auto safety hotline at 1-800-424-9393.
ADDITIONAL INFORMATION:
The National Highway Traffic Safety Administration operates Monday

through Friday from 8:00 AM to 4:00 PM, Eastern Time. For more
information call (800) 424-9393 or (202) 366-0123. For the hearing
impaired, call (800) 424-9153.

TR AN SFE R C ASE

1991 M it s u bis h i M onte ro
1991-94 TRANSFER CASES
Mitsubishi
Dodge; Ram-50
Mitsubishi; Pickup, Montero
APPLICATION
TRANSFER CASE APPLICATIONS TABLE








\









\









\









\









\









\






Application ( 1) Transmission Model
Dodge
1991-93 Ram-50 (2.4L) .......................... V5M21-1
1991-93 Ram-50 (3.0L M/T) ...................... V5MT1-2
1991-93 Ram-50 (3.0L A/T) ...................... V4AC1-2
Mitsubishi
1991-92 Pickup ................................. V5MT1-2
1991 Montero (M/T) ............................. V5MT1-2
1991 Montero (A/T) ............................. V4AW2-2
1992 Montero (M/T) ......................... ( 2) V5MT1-3
1992 Montero (A/T) ......................... ( 2) V4AW2-3
1993-94 Montero (M/T) ...................... ( 2) V5MT1-2
1993-94 Montero (A/T) ........................ ( 2) R4AC1
( 1) - Transfer case is indicated by a -2 or -3 following the
transmission model number.
( 2) - Transfer cases for Montero are identical for automatic and
manual transmission models.









\









\









\









\









\









\






DESCRIPTION
Transfer case is a part-time, 2-speed unit with a 3-piece
aluminum case. Transfer case has a floor-mounted shifter and integral
speedometer gear. In Montero a Viscous Coupling Unit (VCU) and center
differential allows 2WD-to-4WD shifting at speeds under 62 MPH and
full-time 4WD operation.
WARNING: When battery is disconnected, vehicles equipped with
computers may lose memory data. When battery power is
restored, driveability problems may exist on some vehicles.
These vehicles may require a relearn procedure. See the
COMPUTER RELEARN PROCEDURES article in the GENERAL
INFORMATION section.
TESTING
4WD INDICATOR CONTROL UNIT (MONTERO)
The 4WD indicator control unit is located behind radio or CD
player. Remove 4WD indicator control unit and disconnect harness.
Backprobe harness connector and measure voltage between terminal No. 8
(ground) and each respective terminal. Compare test results with
chart. See Fig. 1.
DETECTION SWITCH

NOTE: With switch removed, check continuity between switch
connector terminal and switch body. With switch installed,
check continuity between switch connector terminal and
transfer case.
4WD Indicator Light Switch (RAM-50)
With switch removed, check continuity between connector
terminal and switch body. With switch end pressed, there should be no
continuity. With switch end released, there should be continuity.
Center Differential Lock Operation Detection Switch (Montero)
Check continuity between terminals at Brown wire connector
terminal on top of transfer case. With transfer control lever in "4H"
position, there should be no continuity. With transfer control lever
in "4HLc" position, there should be continuity. See Fig. 2.
4WD Operation Detection Switch (Montero)
Check continuity between terminals at Black wire connector
terminal on top of transfer case. With transfer control lever in "2H"
position, there should be no continuity. With transfer control lever
in "4H" position, there should be continuity. See Fig. 2.
Center Differential Lock Detection Switch (Montero)
Check continuity between terminals at Brown wire connector
terminal on side of transfer case. With transfer control lever in "4H"
position, there should be no continuity. With transfer control lever
in "4HLc" position, there should be continuity. See Fig. 2.
2WD-4WD Detection Switch (Montero)
Check continuity between terminals at Black wire connector
terminal on side of transfer case. With transfer control lever in "4H"
position, there should be no continuity. With transfer control lever
in "2H" position, there should be continuity. See Fig. 2.
HI/LO Detection Switch (Montero)
Check continuity between terminals at White wire connector
terminal on side of transfer case. With transfer control lever in "N"
(between "4HLc" and "4LLc") position, there should be no continuity.
With transfer control lever in "4HLc" position, there should be
continuity. With transfer control lever in "4LLc" position, there
should be continuity. See Fig. 2.
