1991 MITSUBISHI MONTERO Service Manual

federal law. Warranty period is 5 years or 50,000 miles, whichever
occurs first. Covers remedy of non-conformity if vehicle fails to pass
an EPA approved emissions test during the first 24 months or 24,000
miles of this warranty. During the remainder of the warranty period,
covers remedy of non-conformity resulting from failure of certain
emission-related components. See copy of warranty for specific
components covered.
EMISSION SYSTEM WARRANTY (CALIFORNIA)
Warrants that the vehicle was designed, built and equipped to
conform at the time of sale with all applicable U.S. and California
emission standards, and that the emission control system is free from
defects in materials or workmanship which would cause the vehicle not
to meet these standards for 5 years or 50,000 miles, whichever occurs
first. On 1990 and later models, warranty coverage is 3 years or 50,
000 miles, whichever occurs first, with certain emission-related
components covered for 7 years or 70,000 miles, whichever occurs
first. See copy of warranty for specific components covered.
FUSES & CIRCUIT BREAKERS
FUSE PANEL LOCATION
The electrical system is protected against shorts by fuses
that are designed to fail, to prevent damage to the wire harness. The
fuse block is located under the instrument panel on the driver's side.
If a fuse is blown, locate the cause before replacing the fuse. Spare
fuses are contained in the fuse block.
FUSE PANEL IDENTIFICATION (1983-91)
Fig. 8: Fuse Panel Identification (1983-91)
Courtesy of Mitsubishi Motor Sales of America, Inc.
Fuse & Circuit Breaker Identification

1 - 20 Amp (Yellow)
Hazard Light, Dome Light, Clock
2 - 10 Amp (Red)
Taillights
3 - 10 Amp (Red)
Turn Signal Lights
4 - 10 Amp (Red)
Back-Up Lights, Gauges
5 - 15 Amp (Light Blue)
Defogger
6 - 20 Amp (Yellow)
Heater
7 - 15 Amp (Light Blue)
Stoplights
8 - 15 Amp (Light Blue)
Horn, Wiper, Washer
9 - 10 Amp (Red)
Rear Wiper, Rear Washer
10 - 15 Amp (Light Blue)
Cigarette Lighter, Radio
FUSE PANEL IDENTIFICATION (1992-96)
Fig. 9: Fuse Panel Identification (1992-96)
Courtesy of Mitsubishi Motor Sales of America, Inc.
Fuse & Circuit Breaker Identification

1 - 20 Amp
Not Used
2 - Not Used
10 Amp (1994-96)
ELC-4 A/T Control Module, Cruise Control Unit
3 - 10 Amp
Blower Motor Relay, Headlight Washer Relay, Defogger Relay,
Car Telephone (1992-93)
4 - 10 Amp
Radio Clock, Accessory Socket Relay,
Cruise Control Unit (1994-96), Data Link Connector (1994-96)\
5 - 15 Amp
Remote Controlled Mirror, Cigarette Lighter
Accessory Socket Relay (1992-93)
6 - 15 Amp
Door Lock Relay, Door Lock Control Unit (1994-96)
7 - 10 Amp
Overdrive Relay, Variable Shock Absorber Control Unit,
4WD Indicator Control Unit, ABS Power Relay (1992-93),
ABS Control Unit (1994-96), Combination Meter (1994-96)
8 - 10 Amp
Power Window Relay
9 - 15 Amp
Wiper, Washer, Sunroof
10 - 10 Amp
Horn, Cruise Control Unit (1992-93)
11 - 10 Amp
Combination Meter, Multi-meter, Motor Antenna Control Unit,
Buzzer Assembly
12 - 15 Amp
Turn Signal Light, Hazard Light, SRS Diagnosis Unit
13 - 10 Amp
Not Used
14 - 15 Amp
Accessory Socket
15 - Not Used
16 - 25 Amp
Blower Motor
17 - 15 Amp
Stoplight
18 - 10 Amp
Back-up Light, Rear Differential Lock Control Unit
19 - 10 Amp
Engine Control Module, Dome Light, Reading Light,
Cargo Light, Combination Meter, Clock, Door Lock Relay,
Cruise Control Unit, Car Telephone (1992-93)
ELC-4 A/T Control Module (1994-96), Ignition Key Illumination\
Light Timer (1994-96)

MAIN TE N AN CE R EM IN DER L IG HT R ESET P R O CED URES
1991 M it s u bis h i M onte ro
1983-96 MAINTENANCE
Chrysler Motors/Mitsubishi Maintenance Reminder Lights
Dodge; Challenger, Colt, Colt Vista, Conquest, Raider,
Ram-50
Eagle; Summit, Summit Wagon
Plymouth; Colt, Colt Vista, Sapporo
Mitsubishi; 3000GT, Cordia, Diamante, Eclipse,
Expo/Expo LRV, Galant, Mirage, Montero, Pickup, Precis,
Sigma, Starion, Tredia, Van/Wagon
EGR/MAINTENANCE REQUIRED WARNING LIGHT
1) On some models, an EGR or MAINTENANCE REQUIRED warning
light in dash will come on as a reminder to have EGR system serviced
(each 50,000 miles), oxygen sensor replaced (each 80,000 miles) or
evaporative carbon canister replaced (100,000 miles).
2) After servicing or replacing components, reset mileage
counter. On all models except 1987-95 Pickup and 1987-93 Ram-50, reset
switch is located on back of instrument cluster.
3) On 1987-95 Pickup and 1987-93 Ram-50, reset switch is on
lower right corner of instrument cluster, behind instrument cluster
face trim. Slide switch to other side to reset indicator light.
4) Remove warning light bulb after 150,000 mile servicing on
Colt Vista and Wagon. Remove bulb after 120,000 mile servicing on Ram-
50.
Fig. 1: Locating Warning Light Reset Switch (Colt Vista; Colt
Wagon is Similar)
Courtesy of Chrysler Motors.

Fig. 2: Locating Warning Light Reset Switch (1985-86 Pickup & Ram-50)\
Courtesy of Chrysler Motors.
Fig. 3: Locating Warning Light Reset Switch (1987-92 Pickup & Ram-50)\
Courtesy of Chrysler Motors.

Fig. 4: Locating Warning Light Reset Switch (Raider)
Courtesy of Chrysler Motors.
Fig. 5: Locating Warning Light Reset Switch (Van & Wagon)
Courtesy of Chrysler Motors.

Fig. 6: Locating Warning Light Reset Switch (1983-93 Montero)
Courtesy of Chrysler Motors.
Fig. 7: Locating Warning Light Reset Switch (1994-96 Montero)
Courtesy of Chrysler Motors.

METR IC C O NVER SIO NS

1991 M it s u bis h i M onte ro
GENERAL INFORMATION
METRIC CONVERSIONS
METRIC CONVERSIONS
Metric conversions are making life more difficult for the
mechanic. In addition to doubling the number of tools required,
metric-dimensioned nuts and bolts are used alongside English
components in many new vehicles. The mechanic has to decide which tool
to use, slowing down the job. The tool problem can be solved by trial
and error, but some metric conversions aren't so simple. Converting
temperature, lengths or volumes requires a calculator and conversion
charts, or else a very nimble mind. Conversion charts are only part of
the answer though, because they don't help you "think" metric, or
"visualize" what you are converting. The following examples are
intended to help you "see" metric sizes:
LENGTH
Meters are the standard unit of length in the metric system.
The smaller units are 10ths (decimeter), 100ths (centimeter), and
1000ths (millimeter) of a meter. These common examples might help you
to visualize the metric units:
* A meter is slightly longer than a yard (about 40 inches).
* An aspirin tablet is about one centimeter across (.4 inches).
* A millimeter is about the thickness of a dime.
VOLUME
Cubic meters and centimeters are used to measure volume, just
as we normally think of cubic feet and inches. Liquid volume
measurements include the liter and milliliter, like the English quarts
or ounces.
* One teaspoon is about 4 cubic centimeters.
* A liter is about one quart.
* A liter is about 61 cubic inches.
WEIGHT
The metric weight system is based on the gram, with the most
common unit being the kilogram (1000 grams). Our comparable units are
ounces and pounds:
* A kilogram is about 2.2 pounds.
* An ounce is about 28 grams.
TORQUE
Torque is somewhat complicated. The term describes the amount
of effort exerted to turn something. A chosen unit of weight or force
is applied to a lever of standard length. The resulting leverage is
called torque. In our standard system, we use the weight of one pound
applied to a lever a foot long, resulting in the unit called a foot-
pound. A smaller unit is the inch-pound (the lever is one inch long).
Metric units include the meter kilogram (lever one meter long
with a kilogram of weight applied) and the Newton-meter (lever one
