1991 MITSUBISHI MONTERO Service Manual

length. If spring length is not 6.97-7.09 in. (177-180 mm), adjust
cable or support until correct length is obtained. See Fig. 1.
Fig. 1: Testing LSPV Spring Length (Pickup & Ram-50)
Courtesy of Mitsubishi Motor Sales of America.
MASTER CYLINDER PUSH ROD
Check and adjust clearance between back of master cylinder
piston and power brake push rod. See PUSH ROD CLEARANCE SPECIFICATIONS
table. See Fig. 2. After adjusting push rod clearance, adjust pedal
height, and bleed brake system.
Fig. 2: Adjusting Push Rod Clearance
Courtesy of Mitsubishi Motor Sales of America.
PUSH ROD CLEARANCE SPECIFICATIONS TABLE









\









\









\









\









\









\

Application In. (mm)
Montero .............................. .004-.020 (0.1-0.5)
Pickup & Ram-50 ..................... .028-.043 (0.7-1.09)









\









\









\









\









\









\






PARKING/EMERGENCY BRAKE
NOTE: Adjust service brake before adjusting parking brake.
Montero
1) Start engine, and apply brake pedal. Pull parking brake
lever with a force of 44-45 lbs. (20.0-20.4 kg). Parking brake lever
should move up 4-6 notches.
2) If necessary, turn adjusting cable nut located under
console or at end of cable rod. See Fig. 3.
Fig. 3: Adjusting Parking/Emergency Brake (Typical)
Courtesy of Mitsubishi Motor Sales of America.
Pickup & Ram-50
Fully release parking brake, and allow slack in rear cable to
prevent brake shoe drag. Adjust turnbuckle for 2WD models (turn
adjusting nut on equalizer for 4WD models) to obtain a brake lever
stroke of 16-17 notches with a force of 66 lbs. (29.9 kg). Ensure
equalizer is at right angle to joint.
REAR DRUM BRAKE SHOES
Set adjustment assembly so brake shoes outside diameter is 9.
97-9.98 in. (253.2-253.5 mm). After brake drum installation, depress

brake pedal to center shoes, and check pedal travel. Rotate brake drum
to verify free movement.
STOPLIGHT SWITCH
Loosen lock nut, and adjust switch-to-pedal arm clearance to
.02-.04" (.5-1.0 mm). Tighten lock nut. DO NOT depress master cylinder
push rod during stoplight switch adjustment.
TESTING
POWER BRAKE UNIT
Check Valve Inspection
Remove vacuum hose from power brake unit. Remove check valve
from hose (if possible). Using a vacuum pump, ensure airflow is in
direction of intake manifold only.
System Check
1) Run engine for 2 minutes, and shut it off. Depress brake
pedal several times with normal pressure. If pedal height gradually
becomes higher with successive applications, power brake unit is okay.
If pedal height remains steady, power brake unit is faulty.
2) With engine stopped, depress brake pedal repeatedly until
it's height no longer falls. Hold brake pedal down, and start engine.
If pedal moves downward slightly, power brake unit is okay. If pedal
height does not change, power brake unit is faulty.
3) With engine running, press and hold brake pedal and shut
off engine. Hold brake pedal for 30 seconds. Brake pedal height should
not change. If pedal height falls, power brake unit is faulty.
LOAD-SENSING PROPORTIONING VALVE (LSPV) (PICKUP & RAM-50)
1) Before diagnosing Load-Sensing Proportioning Valve (LSPV)\
,
ensure all other brake components are operating properly. When all
other brake system components are determined to be okay, perform LSPV
test beginning with next step.
2) Ensure unladen vehicle is on level ground. Ensure lever is
not contacting stopper bolt. See Fig. 1.
3) When lever is pushed toward valve, distance from LSPV
lever hole and support hole must be 6.97-7.09 in. (177-180 mm). If
measured distance is not within specification, loosen support bolt.
Adjust support until measured distance is within specification.
4) After measured distance is within specification, connect
pressure gauges to input and output ports of LSPV. See Fig. 4. Bleed
brake system. See BLEEDING BRAKE SYSTEM .
Fig. 4: Connecting Pressure Gauges to LSPV (Pickup & Ram-50)
Courtesy of Mitsubishi Motor Sales of America.

5) Remove the LSPV load-sensing spring. Slowly depress the
brake pedal. Check the readings on the pressure gauges. Refer to the
LSPV PRESSURE SPECIFICATIONS table.
6) Install LSPV load-sensing spring. Load weight into rear of
vehicle until measured spring length distance is 7.0" (178 mm) with
lever slightly pressed in. See Fig. 1.
7) Slowly depress brake pedal. Check readings on pressure
gauges. See LSPV PRESSURE SPECIFICATIONS table. If fluid pressure is
not within specification, ensure all other brake system components are
okay. If other components are okay, replace LSPV assembly.
LSPV PRESSURE SPECIFICATIONS (PICKUP & RAM-50)









\









\









\









\









\









\






Application Inlet Pressure Outlet Pressure
psi (kg/cm) psi (kg/cm)
Load-Sensing Spring
Removed ........... 853 (60) ......... 242-327 (17-23)
Installed ........ 1991 (140) .... ( 1) 299-583 (21-40)
( 1) - On vehicles with 2WD and heavy-duty suspension,
outlet pressure is 526-697 psi (37-49 kg/cm
).








\









\









\









\









\









\






PROPORTIONING VALVE (NON-LOAD-SENSING) (MONTERO)
Pressure Test
1) Connect pressure gauges to input and output ports of the
proportioning valve. See Fig. 5. Bleed brake hydraulic system. Refer
to BLEEDING BRAKE SYSTEM .
2) Slowly depress brake pedal. Check readings on pressure
gauges. See the PROPORTIONING VALVE PRESSURE SPECIFICATIONS table. If
fluid pressures are not within specification, replace proportioning
valve.
Fig. 5: Connecting Pressure Gauges to Proportioning Valve (Typical)
Courtesy of Mitsubishi Motor Sales of America.
PROPORTIONING VALVE PRESSURE SPECIFICATIONS (MONTERO)









\









\









\









\









\









\

Inlet Pressure Outlet Pressure
Application psi (kg/cm) psi (kg/cm)
2.6L
Test 1 ............ 853 (59) ......... 473-526 (33-37)
Test 2 ........... 1280 (88) ......... 672-757 (46-52)
3.0L
2-Door Model
Test 1 .......... 853 (59) ......... 473-526 (33-37)
Test 2 ......... 1565 (108) ........ 768-865 (54-60)
4-Door Model
Test 1 .......... 597 (41) ......... 569-626 (39-43)
Test 2 ......... 1377 (95) ......... 843-928 (58-64)
( 1) - Maximum side-to-side pressure differential
is 57 psi (4kg/cm
).








\









\









\









\









\









\






REMOVAL & INSTALLATION
FRONT BRAKE PADS
CAUTION: DO NOT remove or contaminate special grease coating on lock
pins.
Removal
1) Raise and support vehicle. Remove front wheel(s). Remove
lower lock pin or sleeve bolt. See Fig. 6. Lift caliper body upward.
2) Support caliper using wire. Remove shim(s), shim holder
(if equipped), anti-squeak shim and pad assembly from support
mounting. Remove pad clips.
Installation
If installing new pads, compress piston to bottom of bore.
Install retaining clips, pad assembly, shim(s), shim holder (if
equipped) and anti-squeak shim onto support mounting.
Fig. 6: Exploded View of Front Disc Brake Assembly (Typical)
Courtesy of Chrysler Motors.
FRONT BRAKE CALIPER

Removal
1) Raise and support vehicle. Remove front wheel(s). Separat\
e
rubber flex hose from hydraulic line at brake hose mount, located on
strut housing. Secure end of hydraulic line to prevent spillage of
brake fluid.
2) Remove hose clip from brake hose mount. Disconnect brake
hose from caliper. Remove upper and lower caliper-to-steering knuckle
bolts. Lift caliper body upward. Remove caliper.
Installation
To install, reverse removal procedure. Tighten bolts to
specification. See the TORQUE SPECIFICATIONS table. Bleed brake
system. See BLEEDING BRAKE SYSTEM .
FRONT BRAKE ROTOR
Removal (Montero, Pickup 4WD & Ram-50 4WD)
Raise and support vehicle. Remove and support brake calipers.
Place hub in free-wheeling position. Remove drive hub cover using an
oil filter wrench and protective cloth. Remove snap ring, shim and
free-wheeling hub from drive axle. See Fig. 7. Remove lock washer.
Remove lock nut using Lock Nut Wrench (MB990954). Remove front hub
assembly.
Fig. 7: Exploded View of Front Brake Assembly (4WD)
Courtesy of Mitsubishi Motor Sales of America.
Installation
1) Install front hub assembly. Install and tighten lock nut
to 94-145 ft. lbs. (127-197 N.m), and then loosen and retighten to 18
ft. lbs. (24 N.m). Loosen lock nut 30-40 degrees. Reverse removal
procedure for remaining components. After installation is complete,
check drive axle end play. Adjust end play if not .002" (.05 mm) or
less. Rotate drive axle forward and rearward until maximum end play is
obtained.
2) If adjusting axle shaft end play, use proper shim to
obtain desired end play. Shim is located behind snap ring on end of
drive axle. Install shim, and recheck axle end play.
Removal (Pickup 2WD & Ram-50 2WD)
Raise and support vehicle. Remove front caliper. Remove hub
(dust) cap, cotter pin and nut. Remove washer and outer wheel bearing.\
Remove front hub assembly. Remove bolts attaching rotor to front hub,
and separate assemblies.

Installation
To install, reverse removal procedure. Tighten wheel bearings
to 22 ft. lbs. (30 N.m). Loosen nut, and then retighten to 72 INCH
lbs. (8 N.m). Install cotter pin. If pin does not align, loosen nut up\
to a maximum of 30 degrees.
REAR BRAKE DRUM & SHOES
Removal
1) Raise and support vehicle. Remove wheel and brake drum.
Remove shoe return spring and brake shoe adjuster. See Fig. 8. Remove
adjusting spring, shoe retaining spring and shoe hold-down pins.
2) Remove shoe and lining assembly with parking brake lever.
Remove cable from parking lever. Remove parking brake lever snap ring,
and disengage lever from brake shoe.
Fig. 8: Exploded View of Rear Brake Assembly
Courtesy of Mitsubishi Motor Sales of America.
Installation
1) To install, reverse removal procedure. Apply Lubriplate to
backing plate bosses, adjuster assembly threads and parking brake
lever pin.
2) Set adjustment assembly so brake shoes lightly contact
brake drum. Depress brake pedal to center shoes, and check pedal
travel. Rotate brake drum to ensure free movement.
WHEEL CYLINDERS
Removal & Installation
Raise and support vehicle. Remove rear brake drum and shoes.
See REAR BRAKE DRUM & SHOES under REMOVAL & INSTALLATION. Remove wheel
cylinder and seal assembly. To install, reverse removal procedure.
Bleed brakes.
MASTER CYLINDER
Removal
Drain brake fluid from master cylinder. Remove sensor
connector (if equipped). Disconnect brake lines from master cylinder,
and install plugs to prevent brake fluid spillage. Remove master
cylinder from booster unit and separate reservoirs from housing (if
necessary).
Installation
To install, reverse removal procedure. Before installation,
check and adjust clearance between back of master cylinder piston and
power brake push rod. Refer to MASTER CYLINDER PUSH ROD under
ADJUSTMENTS. After installation, adjust the brake pedal height. Refer
to BRAKE PEDAL HEIGHT & FREE PLAY under ADJUSTMENTS. Bleed brake
system. See BLEEDING BRAKE SYSTEM .

POWER BRAKE UNIT CHECK VALVE
NOTE: To test check valve before removal, stop engine, and apply
service brake to ensure air flows only toward intake
manifold.
Removal & Installation
Loosen hose clamps, and remove check valve. Before
installation, coat both ends of check valve with sealant, and install
valve with arrow (identification mark) pointing toward intake
manifold. Install check valve clamp, and secure hose clamps.
POWER BRAKE UNIT
Removal
Remove brake master cylinder. Disconnect vacuum hose from
power brake unit. Disconnect clevis pin attaching brake pedal to power
brake unit push rod. From inside vehicle, remove 4 nuts attaching
power brake unit to firewall. Remove power brake unit.
Installation
To install, reverse removal procedure. Install master
cylinder. Bleed brake system if necessary.
REAR AXLE BEARINGS & OIL SEAL
Removal (Montero)
1) With drum removed, disconnect brake line from wheel
cylinder. Disconnect bearing case from axle housing end. Remove brake
backing plate, bearing case and axle shaft as an assembly. If axle
shaft binds, use slide hammer with puller to remove.
2) Remove "O" ring and shims for preloading wheel bearing (if\
equipped). Retain shims for reassembly. To remove oil seal, use slide
hammer and hook.
3) To remove wheel bearing, straighten lock washer tabs. See
Fig. 9 . Remove lock nut using spanner wrench. Remove lock washer.
Install lock nut 3 turns on axle shaft. Install Puller (MB990787-01)
to remove axle shaft from bearing case. Rotate nuts with equal force
to remove axle shaft. Remove bearing outer race using a hammer and
drift.
Fig. 9: Removing Rear Axle Bearing (Montero)
Courtesy of Mitsubishi Motor Sales of America.
Installation
1) Apply Multipurpose Grease (SAE J310) to oil seal. Install\
