1991 MITSUBISHI MONTERO Service Manual

View of A/C & Coolant
Temperature Sensor On front of intake manifold.
View of Thermostat Housing On front of intake manifold.
Crank Angle/TDC Sensor Inside distributor.

Idle Speed Control Sensor On throttle body assembly.
Intake Air Temperature Sensor Inside airflow sensor
assembly.
Oil Pressure Sending Unit On right side of engine, near
oil filter.
Temp. Gauge Sending Unit On thermostat housing.

Throttle Position Sensor (TPS) On side of throttle body.
Vehicle Speed Sensor Built into speedometer.









\









\









\









\









\









\









\







SOLENOIDS & SOLENOID VALVES








\









\









\









\









\









\









\







Component Component Location








\









\









\









\









\









\









\







Overdrive Solenoid (A/T) Left side of transmission.
Purge Control Solenoid In left front of engine
compartment.

Throttle Opener Control Sol. On firewall.








\









\









\









\









\









\









\







SWITCHES








\









\









\









\









\









\









\







Component Component Location








\









\









\









\









\









\









\







A/C Dual Pressure Switch On right front corner of
engine compartment, near right
headlight.
A/C Thermoswitch Above evaporator.

A/T Thermoswitch On thermostat housing.
Brakelight Switch On bracket, above brake pedal.
Clutch Switch On bracket, above brake pedal.
Coolant Temperature Switch On front of intake manifold.

Inhibitor Switch (A/T) At base of shift lever.
Oil Pressure Switch On right side of engine, near
oil filter.
Power Steering Pressure Switch On power steering pump.









\









\









\









\









\









\









\







MISCELLANEOUS








\









\









\









\









\









\









\







Component Component Location








\









\









\









\









\









\









\







A/C-Heater Blower Motor Resistor On blower motor housing.
Diagnostic/Test Connector:

Ignition Timing Adjustment Under wiper motor.
Fuel Pump Check In right side kick panel.

Self-Diagnosis Behind glove compartment.
Ignition Coil Power Transistor At rear of coil.
Maintenance Reminder Light Reset Behind instrument panel.









\









\









\









\









\









\









\
