1991 MITSUBISHI MONTERO Service Manual

Fig. 19: 1991 Cruise Control Switch Connector
Courtesy of Mitsubishi Motor Co.
Fig. 20: 1991 Stoplight Switch Connector
Courtesy of Mitsubishi Motor Co.

Fig. 21: 1991 Acturator Connector
Courtesy of Mitsubishi Motor Co.
CIRCUIT TESTS (1992)
NOTE: To identify circuit connector terminals, See Figs. 22-29.
For wiring diagram, See appropriate chassis wiring diagram in
the WIRING DIAGRAMS Section.
Test No. 1 (Power & Ground Circuit)
1) Turn ignition on. When cruise control main switch is
turned to ON position, battery voltage should be present on terminal
No. 2 of cruise control unit connector.
2) If voltage is not present, check fuse No. 11 and replace
as necessary. If fuse is okay, check and repair harness as necessary.
Terminal No. 8 should be grounded at all times. If terminal No. 8 is
not grounded, repair harness.
Test No. 2 (Set Switch Circuits)
When set switch is turned to ON position, 3 volts should be
present on terminal No. 18 of cruise control unit. When set switch is
turned to OFF position, voltage should not be present on terminal No.
18 of cruise control unit. If circuit does not test correctly, replace
switch as necessary or repair harness.
Test No. 3 (Resume Switch Circuit)
When resume switch is turned to ON position, 6 volts should
be present on terminal No. 18 of cruise control unit. When resume
switch is turned to OFF position, voltage should not be present on
terminal No. 18 of cruise control unit. If circuit does not test
correctly, replace switch as necessary or repair harness.
Test No. 4 (Cancel Switch Circuit)
When cancel switch is turned to On position, battery voltage
should be present on terminal No. 18 of cruise control unit. When
cancel switch is in Off position, voltage should not be present on
terminal No. 18 of cruise control unit. If circuit does not test
correctly, replace switch as necessary or repair harness.

Test No. 5 (Vehicle Speed Sensor Circuit)
When vehicle moves slowly, 0-2 or more volts should alternate
at terminal No. 19 of cruise control unit. If circuit does not test
correctly, replace sensor as necessary or repair harness.
Test No. 6 (Vacuum Pump Circuit)
1) When cruise system is in deceleration or release mode,
battery voltage should be present on terminals No. 26 and 13 of cruise
control unit. If circuit does not test correctly, replace vacuum pump
as necessary or repair harness.
2) When cruise system is in release mode, battery voltage
should be present on terminal No. 12 of cruise control unit. When
cruise system is in hold mode, voltage on terminals No. 12, 13 and 26
will go from battery voltage to zero volts depending on driving
conditions. If circuit does not test correctly, replace vacuum pump as
necessary or repair harness.
Test No. 7 (Stoplight Switch Circuit)
When brake pedal is pressed, battery voltage should be
present on terminal No. 15 of cruise control unit. If voltage is not
present, adjust or replace brake switch. If circuit does not test
correctly, replace switch as necessary or repair harness.
Test No. 8 (Clutch Switch Circuit)
When clutch pedal is pressed, battery voltage should be
present at terminal No. 1 of cruise control unit. If circuit does not
test correctly, replace switch as necessary or repair harness.
Test No. 9 (Inhibitor Switch Circuit)
When transmission is in Neutral position, battery voltage
should be present on terminal No. 1 of cruise control unit. If circuit
does not test correctly, replace switch as necessary or repair
harness.
Test No. 10 (Overdrive Switch Circuit)
When overdrive switch is pushed to ON position, battery
voltage should be present on terminal No. 11 of cruise control unit.
If circuit does not test correctly, replace switch as necessary or
repair harness.
Test No. 11 (Idle Switch & Throttle Position Sensor Circuit)
1) When accelerator pedal is pressed, 4.5-5.5 volts should be
present on terminal No. 4 (idle switch) of cruise control unit. When
accelerator pedal is released, voltage should not be present on
terminal No. 4 of cruise control unit.
2) When accelerator pedal is pressed to wide open throttle,
4.0-5.5 volts should be present on terminal No. 5 (throttle position
sensor) of cruise control unit. When accelerator pedal is released, .
5-.7 volts should be present on terminal No. 5 of cruise control unit.
If circuit does not test correctly, replace sensor as necessary or
repair harness.
Fig. 22: 1992 Cruise Control Unit Connector
Courtesy of Mitsubishi Motor Co.

Fig. 23: 1992 Main Cruise Control Switch Connector
Courtesy of Mitsubishi Motor Co.
Fig. 24: 1992 Stoplight Switch Connector
Courtesy of Mitsubishi Motor Co.

Fig. 25: 1992 Vacuum Pump Connector
Courtesy of Mitsubishi Motor Co.

Fig. 26: 1992 Instrument Cluster Connector
Courtesy of Mitsubishi Motor Co.
Fig. 27: 1992 Overdrive Switch Connector
Courtesy of Mitsubishi Motor Co.
Fig. 28: 1992 Inhibitor Switch Connector
Courtesy of Mitsubishi Motor Co.

Fig. 29: 1992 Throttle Position Sensor & Idle Switch Connector
Courtesy of Mitsubishi Motor Co.
CRUISE CONTROL SWITCH TESTS
Main, Set & Resume Switches (1991)
1) Disconnect 6-pin cruise control switch connector. See
Figs. 17 -21. With main switch in ON position, continuity should be
present between terminals No. 3 and 6 of cruise control switch
connector. With set switch in ON position, continuity should be
present between terminals No. 1 and 2.
2) With resume switch in On position, continuity should be
present between terminals No. 2 and 4, and 3 and 6. If continuity is
not present, replace cruise control switch.
Set & Resume Switches (1992)
1) Remove lower steering column cover. Disconnect 2-pin
switch connector. Operate and test switch. When cancel switch is
operated, continuity should be present between terminals No. 1 and 2.
Zero ohms resistance should be indicated.
2) When resume switch is operated, 820 ohms resistance should
be present between terminals No. 1 and 2. When set switch is operated,
2700 ohms resistance should be present between terminals No. 1 and 2.

Replace cruise control switch if it does not test correctly.
Main Switch (1992)
1) In each switch position, continuity should be present
between terminals No. 2 and 7 for switch illumination. See Figs. 22-
29. When switch is moved to Neutral position, continuity should be
present between terminals No. 1 and 4.
2) When switch is moved to ON position, continuity should be
present between terminals No. 1, 4 and 5. Connect battery voltage to
terminal No. 5 and ground terminal No. 4.
3) Battery voltage should then be present on terminal No. 1
when main switch is moved to On position. Replace switch if it does
not test correctly.
BRAKELIGHT/STOPLIGHT SWITCH TEST
Disconnect switch connector. When brake pedal is pressed,
continuity should be present between terminals No. 2 and 3. See
Figs. 22 -29. When brake pedal is released, continuity should be
present between terminals No. 1 and 4. Replace switch if it does not
test correctly.
IDLE SWITCH & THROTTLE POSITION SENSOR TESTS
Throttle Position Sensor (1992)
1) Disconnect sensor connector. Resistance between terminals
No. 1 and 4 should be 3500-6500 ohms. Use an analog ohmmeter to
measure resistance between terminals No. 1 and 3. See Figs. 22-29.
2) Slowly open throttle valve to wide open throttle.
Resistance should change smoothly as throttle is opened. Replace
throttle position sensor if it does not test correctly.
Idle Switch (1992)
1) Disconnect throttle position sensor connector. Continuity
should be present between terminals No. 1 and 2 with accelerator pedal
released. See Figs. 22-29. Continuity should not be present with
accelerator pedal pressed.
2) If continuity is not present with accelerator released,
loosen throttle position sensor mounting screw. Turn throttle position
sensor completely clockwise. Recheck continuity. Replace throttle
position sensor if idle switch does not test correctly.
INHIBITOR SWITCH TEST
Disconnect switch connector. Shift transaxle into Neutral and
Park positions. On 1991 models, continuity should be present between
Black/Yellow wire terminals No. 3 and 4. On 1992 models, continuity
should be present between terminals No. 7 and 12. See Figs. 22-29. On
all models, if continuity is not present, adjust inhibitor switch. If
switch is adjusted properly, replace switch.
VACUUM PUMP TEST
1992
1) Remove vacuum pump connector. Resistance should be 50-60
ohms between terminal No. 1 and terminals No. 2 and 3. See Figs. 22-
29. Ensure solenoid valve makes operating noise when battery voltage
is applied between terminal No. 1 and terminals No. 2 and 3.
2) If solenoid valve does not make noise, replace vacuum pump
assembly. Apply battery voltage to terminals No. 1 and 4, motor should
operate. Replace vacuum pump if motor does not operate.
