Page 1241 of 4210

INFINITI QX56 2010 Factory Service Manual TRANSFER ASSEMBLYDLN-159 < DISASSEMBLY AND ASSEMBLY > [ATX14B] C EF G H I J K L M A B DLN N O P g. Remove each retainer plate (1), plug (2), control valve (3) and spring (4) from the upper body (5). I

Page 1242 of 4210

INFINITI QX56 2010 Factory Service Manual DLN-160 < DISASSEMBLY AND ASSEMBLY >[ATX14B] TRANSFER ASSEMBLY • Check if the oil passage of the sun gear assembly is clogged. For this, try to pass a 3.6 mm (0.142 in) dia. pin through the oil pas-

Page 1243 of 4210

INFINITI QX56 2010 Factory Service Manual TRANSFER ASSEMBLYDLN-161 < DISASSEMBLY AND ASSEMBLY > [ATX14B] C EF G H I J K L M A B DLN N O P 1. Check the inner and outer circumference, tooth face, and side- face of the inner and outer gears for

Page 1244 of 4210

INFINITI QX56 2010 Factory Service Manual DLN-162 < DISASSEMBLY AND ASSEMBLY >[ATX14B] TRANSFER ASSEMBLY • Check each control valve spring for damage or distortion. Also check its free length, outer diameter and wire diameter. If any dam- a

Page 1245 of 4210

INFINITI QX56 2010 Factory Service Manual TRANSFER ASSEMBLYDLN-163 < DISASSEMBLY AND ASSEMBLY > [ATX14B] C EF G H I J K L M A B DLN N O P c. Install each control valve (3), springs (4), and plugs (2) to the upper body (5), and install retaine

Page 1246 of 4210

INFINITI QX56 2010 Factory Service Manual DLN-164 < DISASSEMBLY AND ASSEMBLY >[ATX14B] TRANSFER ASSEMBLY 1. Apply ATF to the new O-ring, and install it on the oil filter stud. CAUTION: Do not reuse O-rings. 2. Install the oil filter stud to

Page 1247 of 4210

INFINITI QX56 2010 Factory Service Manual TRANSFER ASSEMBLYDLN-165 < DISASSEMBLY AND ASSEMBLY > [ATX14B] C EF G H I J K L M A B DLN N O P 7. Apply ATF to the new O-ring and install it to the transfer motor. CAUTION: Do not reuse O-rings. 8. F

Page 1248 of 4210

INFINITI QX56 2010 Factory Service Manual DLN-166 < DISASSEMBLY AND ASSEMBLY >[ATX14B] TRANSFER ASSEMBLY 14. Tighten the bolts to the specified torque. Refer to DLN-142, "Dis- assembly and Assembly". 15. Apply ATF to the new D-rings, and ins
