Page 1233 of 4210

INFINITI QX56 2010 Factory Service Manual TRANSFER ASSEMBLYDLN-151 < DISASSEMBLY AND ASSEMBLY > [ATX14B] C EF G H I J K L M A B DLN N O P 7. Remove the bolts and main oil pump cover. 8. Remove the outer gear, inner gear and main oil pump hous

Page 1234 of 4210

INFINITI QX56 2010 Factory Service Manual DLN-152 < DISASSEMBLY AND ASSEMBLY >[ATX14B] TRANSFER ASSEMBLY 12. Remove the C-rings from the mainshaft using suitable tool. 13. Set the center case on the press stand. Remove the mainshaft from the

Page 1235 of 4210

INFINITI QX56 2010 Factory Service Manual TRANSFER ASSEMBLYDLN-153 < DISASSEMBLY AND ASSEMBLY > [ATX14B] C EF G H I J K L M A B DLN N O P 17. Remove the snap ring from the mainshaft using suitable tool. 18. Remove the press flange from the ma

Page 1236 of 4210

INFINITI QX56 2010 Factory Service Manual DLN-154 < DISASSEMBLY AND ASSEMBLY >[ATX14B] TRANSFER ASSEMBLY 22. Remove the mainshaft from the clutch drum and clutch hub using suitable tool. 23. Remove the needle bearing and spacer from the mains

Page 1237 of 4210

INFINITI QX56 2010 Factory Service Manual TRANSFER ASSEMBLYDLN-155 < DISASSEMBLY AND ASSEMBLY > [ATX14B] C EF G H I J K L M A B DLN N O P 28. Remove the two D-rings from the clutch piston. 29. Remove the mainshaft rear bearing from the center

Page 1238 of 4210

INFINITI QX56 2010 Factory Service Manual DLN-156 < DISASSEMBLY AND ASSEMBLY >[ATX14B] TRANSFER ASSEMBLY 33. Remove the control valve assembly bolts. 34. Remove the control valve assembly. CAUTION: • Do not reuse any part that has been drop

Page 1239 of 4210

INFINITI QX56 2010 Factory Service Manual TRANSFER ASSEMBLYDLN-157 < DISASSEMBLY AND ASSEMBLY > [ATX14B] C EF G H I J K L M A B DLN N O P 39. Remove the outer gear and inner gear from the sub oil pump housing. 40. Remove the oil filter bolts

Page 1240 of 4210

INFINITI QX56 2010 Factory Service Manual DLN-158 < DISASSEMBLY AND ASSEMBLY >[ATX14B] TRANSFER ASSEMBLY a. Remove all the bolts except for the two shown. b. Remove the following from the control valve assembly: • Clutch pressure solenoid v
