INFINITI QX56 2010 Factory Service Manual NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTINGDLN-119
< SYMPTOM DIAGNOSIS > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
NOISE, VIBRATION AND HARSHN ESS (NVH) TROUBLESHOOTING
NVH Troubleshooting Ch

Page 1202 of 4210

INFINITI QX56 2010 Factory Service Manual DLN-120
< PRECAUTION >[ATX14B]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint Syst
em (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000005327513
The Supplemental

DLN-120
< PRECAUTION >[ATX14B]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint Syst
em (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000005327513
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and w hether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SR and SB section of this Service Man-
ual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery, and wait at least 3 minu tes before performing any service.
Precaution Necessary for Steering W heel Rotation After Battery Disconnect
INFOID:0000000005327515
NOTE:
• This Procedure is applied only to models with Intelligent Key system and NATS (NISSAN ANTI-THEFT SYS-
TEM).
• Remove and install all control units after disconnecting both battery cables with the ignition knob in the
″LOCK ″ position.
• Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work.
If DTC is detected, perform trouble diagnosis according to self-diagnostic results.
For models equipped with the Intelligent Key system and NATS, an electrically controlled steering lock mech-
anism is adopted on the key cylinder.
For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and
steering wheel rotation will become impossible.
If steering wheel rotation is required when battery pow er is interrupted, follow the procedure below before
starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables. NOTE:
Supply power using jumper cables if battery is discharged.
2. Use the Intelligent Key or mechanical key to turn the ignition switch to the ″ACC ″ position. At this time, the
steering lock will be released.
3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be rotated.
4. Perform the necessary repair operation.
Revision: April 20092010 QX56

Page 1203 of 4210

INFINITI QX56 2010 Factory Service Manual PRECAUTIONSDLN-121
< PRECAUTION > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
5. When the repair work is completed, return the ignition switch to the ″LOCK ″ position before connecting
the battery

PRECAUTIONSDLN-121
< PRECAUTION > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
5. When the repair work is completed, return the ignition switch to the ″LOCK ″ position before connecting
the battery cables. (At this time, the steering lock mechanism will engage.)
6. Perform a self-diagnosis check of al l control units using CONSULT-III.
Precaution for Transfer Assembly and Transfer Control Unit ReplacementINFOID:0000000005148879
When replacing transfer assembly or transfer control uni t, check the 4WD shift indicator lamp as follows.
1. Turn ignition switch ON.
2. Check 4WD shift indicator lamp is turned ON for approximately 1 second.
• If OK, the position between transfer assembly and transfer control unit is correct.
• If NG, the position is different between transfer assembly and transfer control unit. Adjust the position between transfer assembly and transfer control unit. See METHOD FOR POSITION
ADJUSTMENT that follows.
METHOD FOR POSITION ADJUSTMENT
1. Start engine. Run the engine for at least 10 seconds.
2. Stop vehicle and move A/T selector lever to N position with brake pedal depressed. Stay in N for at least 2
seconds.
3. Turn 4WD shift switch to 2WD position. Stay in 2WD for at least 2 seconds.
4. Turn ignition switch OFF.
5. Start engine.
6. Erase self-diagnosis. Refer to DLN-18, "
CONSULT-III Function (ALL MODE AWD/4WD)".
7. Check 4WD shift indicator lamp. Refer to DLN-7, "
Preliminary Check".
If 4WD shift indicator lamp does not indicate 2WD, install new transfer control unit and retry the above
check.
PrecautionINFOID:0000000005148880
• Before connecting or disconnect ing the transfer control unit
harness connector, turn ignition switch “OFF” and disconnect
battery cables. Failure to do so may damage the transfer con-
trol unit. Battery voltage is ap plied to transfer control unit
even if ignition swit ch is turned “OFF”.
• When connecting or disconnecting pin connectors into or
from transfer control unit, take care not to damage pin termi-
nals (bend or break).
When connecting pin connectors make sure that there are not
any bends or breaks on transfer control unit pin terminals.
SEF289H
SEF291H
Revision: April 20092010 QX56

Page 1204 of 4210

INFINITI QX56 2010 Factory Service Manual DLN-122
< PRECAUTION >[ATX14B]
PRECAUTIONS
•
Before replacing transfer cont rol unit, perform transfer con-
trol unit input/output signal inspection and make sure transfer
control unit functions pr

Page 1205 of 4210

INFINITI QX56 2010 Factory Service Manual PREPARATIONDLN-123
< PREPARATION > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
PREPARATION
PREPARATION
Special Service ToolINFOID:0000000005148882
The actual shapes of Kent-Moore tools may differ from t

Page 1206 of 4210

INFINITI QX56 2010 Factory Service Manual DLN-124
< PREPARATION >[ATX14B]
PREPARATION
ST33200000
(J-26082)
Drift• Removing mainshaft front bearing
• Installing sun gear assembly and planetary
carrier assembly
• Installing mainshaft fro

Page 1207 of 4210

INFINITI QX56 2010 Factory Service Manual PREPARATIONDLN-125
< PREPARATION > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
Commercial Service ToolINFOID:0000000005148883
KV31103300
(—)
Drift • Removing press flange snap ring
• Installing pr

Page 1208 of 4210

INFINITI QX56 2010 Factory Service Manual DLN-126
< PREPARATION >[ATX14B]
PREPARATION
Tool name
Description
Puller • Removing companion flange
Pin punch • Removing retainer pin
• Installing retainer pin
a: 6 mm (0.24 in) dia.
Power tool

Load next 8 pages
