SIDE OIL SEAL
Removal and InstallationINFOID:0000000005148890
REMOVAL
1. Remove the front propeller shaft. Refer to INFINITI QX56 2010 Factory Service Manual SIDE OIL SEALDLN-135
< ON-VEHICLE REPAIR > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
SIDE OIL SEAL
Removal and InstallationINFOID:0000000005148890
REMOVAL
1. Remove the front propeller shaft. Refer to](/manual-img/42/57032/w960_57032-1216.png)
SIDE OIL SEALDLN-135
< ON-VEHICLE REPAIR > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
SIDE OIL SEAL
Removal and InstallationINFOID:0000000005148890
REMOVAL
1. Remove the front propeller shaft. Refer to DLN-186, "Removal and Installation".
2. Remove the companion flange. Refer to DLN-142, "
Disassembly and Assembly".
3. Remove the transfer control device from the transfer assembly. Refer to DLN-136, "
Removal and Installa-
tion".
4. Remove the side oil seal using suitable tool. CAUTION:
Do not damage shift cross.
INSTALLATION
1. Install the new side oil seal until it is flush with the end face ofcase using Tool.
CAUTION:
• Do not reuse oil seal.
• Apply petroleum jelly to oil seal.
2. Install the transfer control device to the transfer assembly. Refer to DLN-136, "
Removal and Installation".
3. Install the companion flange. Refer to DLN-142, "
Disassembly
and Assembly".
4. Install the front propeller shaft. Refer to DLN-186, "
Removal and Installation".
SDIA2666E
Tool number : ST22360002 (J-25679-01)
SDIA2665E
Revision: April 20092010 QX56
Page 1218 of 4210
DLN-136
< ON-VEHICLE REPAIR >[ATX14B]
TRANSFER CONTROL DEVICE
TRANSFER CONTROL DEVICE
Removal and InstallationINFOID:0000000005380646
REMOVAL
CAUTION:
Change vehicle state to AUTO, and then
remove and install transfer control device.
1. Remove front propeller shaft. Refer to DLN-186, "
Removal and Installation".
2. Disconnect the transfer control device connector.
3. Remove transfer control lever.
4. Disconnect vacuum line.
5. Remove transfer control device.
INSTALLATION
CAUTION:
Check 4WD shift indicator after installation. Refer to DLN-121, "
Precaution for Transfer Assembly and
Transfer Control Unit Replacement".
Installation is in the reverse order of removal.
1. Shift lever 2. Actuator
SDIA2654E
Revision: April 20092010 QX56
Page 1219 of 4210
AIR BREATHER HOSEDLN-137
< ON-VEHICLE REPAIR > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
AIR BREATHER HOSE
Removal and InstallationINFOID:0000000005148892
REMOVAL
INSTALLATION
CAUTION:
Make sure there are no pinched or restricted areas on each air breather hose caused by folding or
bending when installing it.
1. Install each air breather hose into the breather tube (4). Set each air breather hose with paint mark facing upward.
• A/T breather hose (1)
• Transfer breather hose (2)
• Actuator/transfer motor breather hose (3)
• Paint marks (A)
2. Install actuator/transfer motor air breather hose (1) and transfer air breather hose (2) on clip (A) with the paint mark (B) facing
upward.
• :Front
AWDIA0010ZZ
1. Breather tube 2. Clip A3. Clip B
4. Clip C 5. Clip D6. Actuator
7. Air breather hose clamp 8. Clip E 9. Transfer motor
10. Breather tube (transfer) Vehicle front
ALDIA0110ZZ
ALDIA0111ZZ
Revision: April 20092010 QX56
Page 1220 of 4210
![INFINITI QX56 2010 Factory Service Manual DLN-138
< ON-VEHICLE REPAIR >[ATX14B]
AIR BREATHER HOSE
3. Install clip (B) on actuator/tr
ansfer motor air breather hose (1)
and transfer air breather hose (2) with the paint mark (A)
matched.
• : INFINITI QX56 2010 Factory Service Manual DLN-138
< ON-VEHICLE REPAIR >[ATX14B]
AIR BREATHER HOSE
3. Install clip (B) on actuator/tr
ansfer motor air breather hose (1)
and transfer air breather hose (2) with the paint mark (A)
matched.
• :](/manual-img/42/57032/w960_57032-1219.png)
DLN-138
< ON-VEHICLE REPAIR >[ATX14B]
AIR BREATHER HOSE
3. Install clip (B) on actuator/tr
ansfer motor air breather hose (1)
and transfer air breather hose (2) with the paint mark (A)
matched.
• :Front
4. Install actuator/transfer motor air breather hose (1) and transfer air breather hose (2) on clip (B) and clip (C) with the paint mark
(A) and (D) facing upward.
• :Front
5. Install the actuator air breather hose into the actuator (case con- nector) until the hose end reaches the base of the tube. Set
actuator air breather hose with paint mark facing leftward.
6. Install clip (B) on transfer motor air breather hose (2) and trans- fer air breather hose (1) with the paint mark (A) matched.
• :Front
7. Install the transfer air breather hose into the breather tube (transfer, metal connector) until the hose end reaches the base
of the tube. Set transfer air breather hose with paint mark facing
upwards.
AWDIA0011ZZ
AWDIA0012ZZ
SDIA3226E
AWDIA0013ZZ
SDIA3196E
Revision: April 20092010 QX56
Page 1221 of 4210
AIR BREATHER HOSEDLN-139
< ON-VEHICLE REPAIR > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
8. Install the transfer motor air breather hose into the transfer motor (case connector) until the hose end reaches the end of
the curved section. Set transfer motor air breather hose with
paint mark facing leftward.
SDIA3194E
Revision: April 20092010 QX56
Page 1222 of 4210
![INFINITI QX56 2010 Factory Service Manual DLN-140
< ON-VEHICLE REPAIR >[ATX14B]
TRANSFER MOTOR
TRANSFER MOTOR
Removal and InstallationINFOID:0000000005148893
REMOVAL
1. Disconnect the transfer motor connector.
2. Remove the transfer motor air INFINITI QX56 2010 Factory Service Manual DLN-140
< ON-VEHICLE REPAIR >[ATX14B]
TRANSFER MOTOR
TRANSFER MOTOR
Removal and InstallationINFOID:0000000005148893
REMOVAL
1. Disconnect the transfer motor connector.
2. Remove the transfer motor air](/manual-img/42/57032/w960_57032-1221.png)
DLN-140
< ON-VEHICLE REPAIR >[ATX14B]
TRANSFER MOTOR
TRANSFER MOTOR
Removal and InstallationINFOID:0000000005148893
REMOVAL
1. Disconnect the transfer motor connector.
2. Remove the transfer motor air breather hose from the transfer
motor. Refer to DLN-137, "
Removal and Installation".
3. Remove the transfer motor bolts.
4. Remove the transfer motor.
INSTALLATION
1. Apply ATF to the new O-ring and install it to the transfer motor. CAUTION:
Do not reuse O-rings.
2. Fit the double-flat end of the transfer motor shaft into the slot of the sub-oil pump assembly. Then tighten to the specified torque.
Refer to DLN-140, "
Removal and Installation".
CAUTION:
Be sure to install connector bracket.
3. Install the transfer motor air breather hose to the transfer motor. Refer to DLN-137, "
Removal and Installation".
4. Connect the transfer motor connector.
5. Check the transfer fluid. Refer to DLN-129, "
Replacement".
6. Start the engine for one minute. Then stop the engine and recheck the transfer fluid. Refer to DLN-129,
"Inspection".
SDIA2133E
SDIA2787E
Revision: April 20092010 QX56
Page 1223 of 4210
![INFINITI QX56 2010 Factory Service Manual TRANSFER ASSEMBLYDLN-141
< REMOVAL AND INSTALLATION > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
REMOVAL AND INSTALLATION
TRANSFER ASSEMBLY
Removal and InstallationINFOID:0000000005148894
REMOVAL
1. Se INFINITI QX56 2010 Factory Service Manual TRANSFER ASSEMBLYDLN-141
< REMOVAL AND INSTALLATION > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
REMOVAL AND INSTALLATION
TRANSFER ASSEMBLY
Removal and InstallationINFOID:0000000005148894
REMOVAL
1. Se](/manual-img/42/57032/w960_57032-1222.png)
TRANSFER ASSEMBLYDLN-141
< REMOVAL AND INSTALLATION > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
REMOVAL AND INSTALLATION
TRANSFER ASSEMBLY
Removal and InstallationINFOID:0000000005148894
REMOVAL
1. Set transfer state as 2WD when 4WD shift switch is at 2WD.
2. Remove the undercovers using power tool.
3. Drain the transfer fluid. Refer to TM-150, "
Changing the A/T Fluid (ATF)".
4. Remove the center exhaust tube and main muffler. Refer to EX-6, "
Removal and Installation".
5. Remove the front and rear propeller shafts. Refer to DLN-186, "
Removal and Installation" (front), DLN-
196, "Removal and Installation" (rear).
CAUTION:
Do not damage spline, sleeve yoke and rear oi l seal when removing rear propeller shaft.
NOTE:
Insert a plug into the rear oil seal after removing the rear propeller shaft.
6. Remove the A/T nuts from the A/T crossmember. Refer to TM-188, "
Removal and Installation (4WD)".
7. Position two suitable jacks under the A/T and transfer assembly.
8. Remove the crossmember. Refer to TM-188, "
Removal and Installation (4WD)".
WARNING:
Support A/T and transfer assembly using two suitable jacks while removing crossmember.
9. Disconnect the electrical connectors from the following: • ATP switch
• Neutral 4LO switch
• Wait detection switch
• Transfer motor
• Transfer control device
• Transfer terminal cord assembly
10. Disconnect each air breather hose from the following. Refer to DLN-137, "
Removal and Installation".
• Actuator
• Breather tube (transfer)
• Transfer motor
11. Remove the transfer control dev ice from the extension housing.
12. Remove the transfer to A/T and A/T to transfer bolts.
13. Remove the transfer assembly. WARNING:
Support transfer assembly with su itable jack while removing it.
CAUTION:
Do not damage rear oil seal (A/T).
INSTALLATION
Installation is in the reverse order of removal.
• Tighten the bolts to specification.
• Fill the transfer with new fluid and check for fluid leakage and fluid level. Refer to DLN-129, "
Replacement".
• Start the engine for one minute. Then stop the engine and recheck the transfer fluid. Refer to DLN-129, "
Inspection".
Transfer bolt torque : 36 N·m (3.7 kg-m, 27 ft-lb)
SMT872C
Revision: April 20092010 QX56
Page 1224 of 4210
DLN-142
< DISASSEMBLY AND ASSEMBLY >[ATX14B]
TRANSFER ASSEMBLY
DISASSEMBLY AND ASSEMBLY
TRANSFER ASSEMBLY
Disassembly and AssemblyINFOID:0000000005148895
COMPONENTS
1. 2-4 sleeve
2. L-H sleeve 3. Snap ring
4. Internal gear 5. Planetary carrier assembly 6. Metal bushing
7. Needle bearing 8. Sun gear 9. Carrier bearing
10. Snap ring 11. Snap ring 12. Input bearing
13. Wait detection switch 14. Check plug 15. Check spring
16. Check ball 17. Front case 18. Snap ring
19. Input oil seal 20. Shift cross 21. Side oil seal
22. Lock pin 23. Shift lever 24. Gasket
25. Drain plug 26. Front oil seal 27. Companion flange
28. Self-lock nut 29. Mainshaft 30. Needle bearing
31. Front bearing 32. Front drive shaft 33. Rear bearing
34. Spacer 35. Drive chain 36. Clutch drum
37. Snap ring 38. Clutch hub 39. Snap ring
AWDIA0014GB
