2002 TOYOTA AVENSIS Repair Manual

02±10
± PREPARATIONENGINE MECHANICAL
AVENSIS REPAIR MANUAL (RM1018E)
09249±63010Torque Wrench AdaptorFAN AND GENERATOR V
BELT(1AZ±FE)
CHAIN SUB±ASSY(1AZ±FE)
CYLINDER HEAD GASKET(1AZ±FE)
TIMING GEAR CASE OR TIMING
CHAIN CASE OIL SEAL(1AZ±FE)
FAN AND GENERATOR V
BELT(1AZ±FSE)
CHAIN SUB±ASSY(1AZ±FSE)
CYLINDER HEAD
GASKET(1AZ±FSE)
TIMING GEAR CASE OR TIMING
CHAIN CASE OIL SEAL(1AZ±FSE)
09268±21010Fuel Hose PullerCYLINDER HEAD
GASKET(1ZZ±FE/3ZZ±FE)
09268±46021Nozzle Holder Retaining Nut
WrenchPARTIAL ENGINE ASSY(1AZ±FE)
PARTIAL ENGINE ASSY(1AZ±FSE)
09301±00210Clutch Guide ToolPARTIAL ENGINE ASSY(1CD±FTV)
PARTIAL ENGINE
ASSY(1ZZ±FE/3ZZ±FE)
09301±00220Clutch Guide ToolENGINE REAR OIL SEAL(1CD±FTV)
09316±60011Transmission & Transfer Bearing
ReplacerCRANKSHAFT SEAL(1CD±FTV)
(09316±00011)Replacer PipeCRANKSHAFT SEAL(1CD±FTV)
09330±00021Companion Flange Holding ToolPARTIAL ENGINE ASSY(1AZ±FE)
CHAIN SUB±ASSY(1AZ±FE)
CYLINDER HEAD GASKET(1AZ±FE)
ENGINE REAR OIL SEAL(1AZ±FE)
TIMING GEAR CASE OR TIMING
CHAIN CASE OIL SEAL(1AZ±FE)
PARTIAL ENGINE ASSY(1AZ±FSE)
CHAIN SUB±ASSY(1AZ±FSE)
CYLINDER HEAD
GASKET(1AZ±FSE)
ENGINE REAR OIL SEAL(1AZ±FSE)
TIMING GEAR CASE OR TIMING
CHAIN CASE OIL SEAL(1AZ±FSE)
TIMING BELT(1CD±FTV)
CAMSHAFT(1CD±FTV)
CYLINDER HEAD
GASKET(1CD±FTV)
CRANKSHAFT SEAL(1CD±FTV)
ENGINE REAR OIL SEAL(1CD±FTV)
PARTIAL ENGINE ASSY(1CD±FTV)

± PREPARATIONENGINE MECHANICAL
02±11
AVENSIS REPAIR MANUAL (RM1018E)
(09330±00030)PinPARTIAL ENGINE ASSY(1AZ±FE)
PARTIAL ENGINE ASSY(1AZ±FSE)
09520±01010Drive Shaft Remover AttachmentENGINE REAR OIL SEAL(1CD±FTV)
09520±24010Differential Side Gear Shaft
PullerENGINE REAR OIL SEAL(1CD±FTV)
(09520±32040)Shocker SetENGINE REAR OIL SEAL(1CD±FTV)
09628±62011Boll Joint PullerENGINE REAR OIL SEAL(1CD±FTV)
PARTIAL ENGINE ASSY(1CD±FTV)
PARTIAL ENGINE
ASSY(1ZZ±FE/3ZZ±FE)
09670±00010Front Crossmember Guide ToolENGINE REAR OIL SEAL(1CD±FTV)
PARTIAL ENGINE
ASSY(1ZZ±FE/3ZZ±FE)
09817±33190Sensor Socket WrenchPARTIAL ENGINE ASSY(1AZ±FE)
PARTIAL ENGINE ASSY(1AZ±FSE)
PARTIAL ENGINE
ASSY(1ZZ±FE/3ZZ±FE)
09843±18020Diagnosis Check WireENGINE(1AZ±FSE)
ENGINE(1ZZ±FE/3ZZ±FE)
09843±18040Diagnosis Check Wire No.2ENGINE(1AZ±FE)
ENGINE(1AZ±FSE)
ENGINE(1CD±FTV)
ENGINE(1ZZ±FE/3ZZ±FE)
PARTIAL ENGINE
ASSY(1ZZ±FE/3ZZ±FE)
CYLINDER HEAD
GASKET(1ZZ±FE/3ZZ±FE)
09930±00010Drive Shaft Nut ChiselENGINE REAR OIL SEAL(1CD±FTV)
PARTIAL ENGINE ASSY(1CD±FTV)
PARTIAL ENGINE
ASSY(1ZZ±FE/3ZZ±FE)

02±12
± PREPARATIONENGINE MECHANICAL
AVENSIS REPAIR MANUAL (RM1018E)
09950±50013Puller C SetCHAIN SUB±ASSY(1AZ±FE)
CYLINDER HEAD GASKET(1AZ±FE)
TIMING GEAR CASE OR TIMING
CHAIN CASE OIL SEAL(1AZ±FE)
CHAIN SUB±ASSY(1AZ±FSE)
CYLINDER HEAD
GASKET(1AZ±FSE)
TIMING GEAR CASE OR TIMING
CHAIN CASE OIL SEAL(1AZ±FSE)
TIMING BELT(1CD±FTV)
CAMSHAFT(1CD±FTV)
CYLINDER HEAD
GASKET(1CD±FTV)
CRANKSHAFT SEAL(1CD±FTV)
PARTIAL ENGINE ASSY(1CD±FTV)
(09951±05010)Hanger 150CHAIN SUB±ASSY(1AZ±FE)
CYLINDER HEAD GASKET(1AZ±FE)
TIMING GEAR CASE OR TIMING
CHAIN CASE OIL SEAL(1AZ±FE)
CHAIN SUB±ASSY(1AZ±FSE)
CYLINDER HEAD
GASKET(1AZ±FSE)
TIMING GEAR CASE OR TIMING
CHAIN CASE OIL SEAL(1AZ±FSE)
TIMING BELT(1CD±FTV)
CAMSHAFT(1CD±FTV)
CYLINDER HEAD
GASKET(1CD±FTV)
CRANKSHAFT SEAL(1CD±FTV)
PARTIAL ENGINE ASSY(1CD±FTV)
(09952±05010)Slide ArmCHAIN SUB±ASSY(1AZ±FE)
CYLINDER HEAD GASKET(1AZ±FE)
TIMING GEAR CASE OR TIMING
CHAIN CASE OIL SEAL(1AZ±FE)
CHAIN SUB±ASSY(1AZ±FSE)
CYLINDER HEAD
GASKET(1AZ±FSE)
TIMING GEAR CASE OR TIMING
CHAIN CASE OIL SEAL(1AZ±FSE)
TIMING BELT(1CD±FTV)
CAMSHAFT(1CD±FTV)
CYLINDER HEAD
GASKET(1CD±FTV)
CRANKSHAFT SEAL(1CD±FTV)
PARTIAL ENGINE ASSY(1CD±FTV)
(09953±05010)Center Bolt 100CRANKSHAFT SEAL(1CD±FTV)

± PREPARATIONENGINE MECHANICAL
02±13
AVENSIS REPAIR MANUAL (RM1018E)
(09953±05020)Center Bolt 150CHAIN SUB±ASSY(1AZ±FE)
CYLINDER HEAD GASKET(1AZ±FE)
TIMING GEAR CASE OR TIMING
CHAIN CASE OIL SEAL(1AZ±FE)
CHAIN SUB±ASSY(1AZ±FSE)
CYLINDER HEAD
GASKET(1AZ±FSE)
TIMING GEAR CASE OR TIMING
CHAIN CASE OIL SEAL(1AZ±FSE)
TIMING BELT(1CD±FTV)
CAMSHAFT(1CD±FTV)
CYLINDER HEAD
GASKET(1CD±FTV)
CRANKSHAFT SEAL(1CD±FTV)
PARTIAL ENGINE ASSY(1CD±FTV)
(09954±05021)Claw No.2CHAIN SUB±ASSY(1AZ±FE)
CYLINDER HEAD GASKET(1AZ±FE)
TIMING GEAR CASE OR TIMING
CHAIN CASE OIL SEAL(1AZ±FE)
CHAIN SUB±ASSY(1AZ±FSE)
CYLINDER HEAD
GASKET(1AZ±FSE)
TIMING GEAR CASE OR TIMING
CHAIN CASE OIL SEAL(1AZ±FSE)
CRANKSHAFT SEAL(1CD±FTV)
(09954±05031)Claw No.3TIMING BELT(1CD±FTV)
CAMSHAFT(1CD±FTV)
CYLINDER HEAD
GASKET(1CD±FTV)
CRANKSHAFT SEAL(1CD±FTV)
PARTIAL ENGINE ASSY(1CD±FTV)
09950±70010Handle SetENGINE REAR OIL SEAL(1AZ±FE)
ENGINE REAR OIL SEAL(1AZ±FSE)
ENGINE REAR OIL SEAL(1CD±FTV)
ENGINE REAR OIL
SEAL(1ZZ±FE/3ZZ±FE)
(09951±07100)Handle 100ENGINE REAR OIL SEAL(1AZ±FE)
ENGINE REAR OIL SEAL(1AZ±FSE)
ENGINE REAR OIL SEAL(1CD±FTV)
ENGINE REAR OIL
SEAL(1ZZ±FE/3ZZ±FE)
09960±10010Variable Pin Wrench SetTIMING BELT(1CD±FTV)
CAMSHAFT(1CD±FTV)
CYLINDER HEAD
GASKET(1CD±FTV)
CRANKSHAFT SEAL(1CD±FTV)
PARTIAL ENGINE ASSY(1CD±FTV)
PARTIAL ENGINE
ASSY(1ZZ±FE/3ZZ±FE)
CHAIN
SUB±ASSY(1ZZ±FE/3ZZ±FE)
CYLINDER HEAD
GASKET(1ZZ±FE/3ZZ±FE)
TIMING CHAIN OR BELT COVER OIL
SEAL(1ZZ±FE/3ZZ±FE)
ENGINE REAR OIL
SEAL(1ZZ±FE/3ZZ±FE)

02±14
± PREPARATIONENGINE MECHANICAL
AVENSIS REPAIR MANUAL (RM1018E)
(09962±01000)Variable Pin Wrench Arm AssyTIMING BELT(1CD±FTV)
CAMSHAFT(1CD±FTV)
CYLINDER HEAD
GASKET(1CD±FTV)
CRANKSHAFT SEAL(1CD±FTV)
PARTIAL ENGINE ASSY(1CD±FTV)
PARTIAL ENGINE
ASSY(1ZZ±FE/3ZZ±FE)
CHAIN
SUB±ASSY(1ZZ±FE/3ZZ±FE)
CYLINDER HEAD
GASKET(1ZZ±FE/3ZZ±FE)
TIMING CHAIN OR BELT COVER OIL
SEAL(1ZZ±FE/3ZZ±FE)
ENGINE REAR OIL
SEAL(1ZZ±FE/3ZZ±FE)
(09963±01000)Pin 10TIMING BELT(1CD±FTV)
CAMSHAFT(1CD±FTV)
CYLINDER HEAD
GASKET(1CD±FTV)
CRANKSHAFT SEAL(1CD±FTV)
PARTIAL ENGINE ASSY(1CD±FTV)
PARTIAL ENGINE
ASSY(1ZZ±FE/3ZZ±FE)
CHAIN
SUB±ASSY(1ZZ±FE/3ZZ±FE)
CYLINDER HEAD
GASKET(1ZZ±FE/3ZZ±FE)
TIMING CHAIN OR BELT COVER OIL
SEAL(1ZZ±FE/3ZZ±FE)
ENGINE REAR OIL
SEAL(1ZZ±FE/3ZZ±FE)
09992±00025Cylinder Compression Check Gauge
SetENGINE(1CD±FTV)
(09992±00121)No. 4 AttachmentENGINE(1CD±FTV)
(09992±00211)Gauge AssyENGINE(1CD±FTV)
09992±00242Turbocharger Pressure GaugeVALVE CLEARANCE(1CD±FTV)
CAMSHAFT(1CD±FTV)
CYLINDER HEAD
GASKET(1CD±FTV)
09992±00500Compression Gauge AttachmentENGINE(1AZ±FE)
ENGINE(1AZ±FSE)
ENGINE(1ZZ±FE/3ZZ±FE)
CYLINDER HEAD
GASKET(1ZZ±FE/3ZZ±FE)

± PREPARATIONENGINE MECHANICAL
02±15
AVENSIS REPAIR MANUAL (RM1018E)
Recomended Tools
09011±12301Socket Wrench 30 mmENGINE REAR OIL SEAL(1CD±FTV)
PARTIAL ENGINE ASSY(1CD±FTV)
PARTIAL ENGINE
ASSY(1ZZ±FE/3ZZ±FE)
ENGINE REAR OIL
SEAL(1ZZ±FE/3ZZ±FE)
09017±38120Deep Socket Wrench 12 mmPARTIAL ENGINE ASSY(1CD±FTV)
09040±00011Hexagon Wrench SetPARTIAL ENGINE
ASSY(1ZZ±FE/3ZZ±FE)
(09043±20050)Socket Hexagon Wrench 5PARTIAL ENGINE
ASSY(1ZZ±FE/3ZZ±FE)
(09043±20100)Socket Hexagon Wrench 10PARTIAL ENGINE
ASSY(1ZZ±FE/3ZZ±FE)
09043±50100Bi±hexagon Wrench 10 mmCYLINDER HEAD GASKET(1AZ±FE)
CYLINDER HEAD
GASKET(1AZ±FSE)
09090±04020Engine Sling DevicePARTIAL ENGINE ASSY(1CD±FTV)
PARTIAL ENGINE
ASSY(1ZZ±FE/3ZZ±FE)
09216±00021Belt Tension GaugeENGINE(1CD±FTV)
DRIVE BELT(1CD±FTV)
TIMING BELT(1CD±FTV)
CAMSHAFT(1CD±FTV)
CYLINDER HEAD
GASKET(1CD±FTV)
CRANKSHAFT SEAL(1CD±FTV)
(09857±00031)Spark Plug Gap GaugeENGINE(1AZ±FE)
ENGINE(1AZ±FSE)
ENGINE(1ZZ±FE/3ZZ±FE)
Equipment
Hexagon wrench (6mm)
Feeler gauge
CO/HC meter
Compression gauge
Dial indicator
Dial indicator or dial indicator with magnetic base
Micro meter
Radiator cap tester
Straight edge
Tachometer
Torque wrench

02±16
± PREPARATIONENGINE MECHANICAL
AVENSIS REPAIR MANUAL (RM1018E) Vernier calipers
Tire pressure gauge
Alignment tester
Toe±in gauge
OBD II scan tool
Deep socket wrench 24 mm
Slide calipers
Sand paper (#400)
Wooden block
Chain block
Spark plug cleaner
Angle gauge
Universal engine lifter
SSM
08826±00080Seal Packing Black or equivalent
(FIPG)VALVE CLEARANCE(1AZ±FE)
CYLINDER HEAD GASKET(1AZ±FE)
VALVE CLEARANCE(1AZ±FSE)
CYLINDER HEAD
GASKET(1AZ±FSE)
VALVE CLEARANCE(1CD±FTV)
TIMING BELT(1CD±FTV)
CAMSHAFT(1CD±FTV)
CYLINDER HEAD
GASKET(1CD±FTV)
CRANKSHAFT SEAL(1CD±FTV)
PARTIAL ENGINE ASSY(1CD±FTV)
VA LV E
CLEARANCE(1ZZ±FE/3ZZ±FE)
CHAIN
SUB±ASSY(1ZZ±FE/3ZZ±FE)
CAMSHAFT(1ZZ±FE/3ZZ±FE)
CYLINDER HEAD
GASKET(1ZZ±FE/3ZZ±FE)
08833±00070ºAdhesive 1324,º
THREE BOND 1324 or equivalentPARTIAL ENGINE ASSY(1AZ±FE)
ENGINE REAR OIL SEAL(1AZ±FE)
PARTIAL ENGINE ASSY(1AZ±FSE)
ENGINE REAR OIL SEAL(1AZ±FSE)
ENGINE REAR OIL SEAL(1CD±FTV)
PARTIAL ENGINE ASSY(1CD±FTV)
PARTIAL ENGINE
ASSY(1ZZ±FE/3ZZ±FE)
ENGINE REAR OIL
SEAL(1ZZ±FE/3ZZ±FE)

022J7±01
± PREPARATIONEXHAUST
02±17
AVENSIS REPAIR MANUAL (RM1018E)
EXHAUST
PREPARATION
Equipment
Torque wrench
Vernier calipers
Wooden block
