Page 2329 of 2889

DODGE RAM 2001 Service Repair Manual HYDRAULIC FLOW IN DRIVE SECOND GEAR 21 - 694 AUTOMATIC TRANSMISSION - 47REBR/BE AUTOMATIC TRANSMISSION - 47RE (Continued)

Page 2330 of 2889

DODGE RAM 2001 Service Repair Manual HYDRAULIC FLOW IN DRIVE THIRD GEAR (CONVERTER CLUTCH NOT APPLIED) BR/BEAUTOMATIC TRANSMISSION - 47RE 21 - 695 AUTOMATIC TRANSMISSION - 47RE (Continued)

Page 2331 of 2889

DODGE RAM 2001 Service Repair Manual HYDRAULIC FLOW IN DRIVE THIRD GEAR (CONVERTER CLUTCH APPLIED) 21 - 696 AUTOMATIC TRANSMISSION - 47REBR/BE AUTOMATIC TRANSMISSION - 47RE (Continued)

Page 2332 of 2889

DODGE RAM 2001 Service Repair Manual HYDRAULIC FLOW IN DRIVE FOURTH GEAR (CONVERTER CLUTCH NOT APPLIED) BR/BEAUTOMATIC TRANSMISSION - 47RE 21 - 697 AUTOMATIC TRANSMISSION - 47RE (Continued)

Page 2333 of 2889

DODGE RAM 2001 Service Repair Manual HYDRAULIC FLOW IN DRIVE FOURTH GEAR (CONVERTER CLUTCH APPLIED) 21 - 698 AUTOMATIC TRANSMISSION - 47REBR/BE AUTOMATIC TRANSMISSION - 47RE (Continued)

Page 2334 of 2889

DODGE RAM 2001 Service Repair Manual HYDRAULIC FLOW IN MANUAL LOW (1) BR/BEAUTOMATIC TRANSMISSION - 47RE 21 - 699 AUTOMATIC TRANSMISSION - 47RE (Continued)

Page 2335 of 2889

DODGE RAM 2001 Service Repair Manual HYDRAULIC FLOW IN MANUAL SECOND (2) 21 - 700 AUTOMATIC TRANSMISSION - 47REBR/BE AUTOMATIC TRANSMISSION - 47RE (Continued)

Page 2336 of 2889

DODGE RAM 2001 Service Repair Manual HYDRAULIC FLOW DURING FULL THROTTLE 3-2 DOWNSHIFT (PASSING BR/BEAUTOMATIC TRANSMISSION - 47RE 21 - 701 AUTOMATIC TRANSMISSION - 47RE (Continued)
