Page 2161 of 2889

DODGE RAM 2001 Service Repair Manual HYDRAULIC FLOW IN DRIVE THIRD GEAR (CONVERTER CLUTCH APPLIED) 21 - 526 AUTOMATIC TRANSMISSION - 46REBR/BE AUTOMATIC TRANSMISSION - 46RE (Continued)

Page 2162 of 2889

DODGE RAM 2001 Service Repair Manual HYDRAULIC FLOW IN DRIVE FOURTH GEAR (CONVERTER CLUTCH NOT APPLIED) BR/BEAUTOMATIC TRANSMISSION - 46RE 21 - 527 AUTOMATIC TRANSMISSION - 46RE (Continued)

Page 2163 of 2889

DODGE RAM 2001 Service Repair Manual HYDRAULIC FLOW IN DRIVE FOURTH GEAR (CONVERTER CLUTCH APPLIED) 21 - 528 AUTOMATIC TRANSMISSION - 46REBR/BE AUTOMATIC TRANSMISSION - 46RE (Continued)

Page 2164 of 2889

DODGE RAM 2001 Service Repair Manual HYDRAULIC FLOW IN MANUAL LOW (1) BR/BEAUTOMATIC TRANSMISSION - 46RE 21 - 529 AUTOMATIC TRANSMISSION - 46RE (Continued)

Page 2165 of 2889

DODGE RAM 2001 Service Repair Manual HYDRAULIC FLOW IN MANUAL SECOND (2) 21 - 530 AUTOMATIC TRANSMISSION - 46REBR/BE AUTOMATIC TRANSMISSION - 46RE (Continued)

Page 2166 of 2889

DODGE RAM 2001 Service Repair Manual HYDRAULIC FLOW DURING FULL THROTTLE 3-2 DOWNSHIFT (PASSING BR/BEAUTOMATIC TRANSMISSION - 46RE 21 - 531 AUTOMATIC TRANSMISSION - 46RE (Continued)

Page 2167 of 2889

DODGE RAM 2001 Service Repair Manual SPECIFICATIONS TRANSMISSION GENERAL Component Metric Inch Planetary end play 0.150-1.22 mm0.006-0.048 in. Input shaft end play 0.86-2.13 mm0.034-0.084 in. Clutch pack clearance/ Front.1.78-3.28 mm0.07

Page 2168 of 2889

DODGE RAM 2001 Service Repair Manual PRESSURE TEST Overdrive clutch Fourth gear only Pressure should be 469-496 kPa (68-72 psi) with closed throttle and increase to 620-896 kPa (90-130 psi) at 1/2 to 3/4 throttle. Line pressure (at accum
