DIAGNOSTICS CRUISE CONTROL SYSTEM
DI−295
1996 LAND CRUISER (RM451U)
PROBLEM SYMPTOMS TABLE
SymptomSuspect AreaSee page
SET not occourring or CANCEL occurring.
(DTC is Normal)
1. Main Switch Circuit (Cruise control switch)
2. Vehicle Speed Sensor
3. Control Switch Circuit (Cruise control switch)
4. Stop Light Switch Circuit
5. Park/Neutral Position Switch Circuit
6. Actuator Motor Circuit
7. Cruise Control Cable
8. Cruise Control ECUDI−330
DI−306
DI−311
DI−314
DI−322
DI−296
DI−336 IN−28
SET not occurring or CANCEL occurring.
(DTC does not output)1. ECU Power Source Circuit
2. Cruise Control ECUDI−325IN−28
Actual vehicle speed deviates above or below the set speed.
1. Cruise Control Cable
2. Vehicle Speed Signal Abnormal
3. Electronically Controlled Transmission Communication
Circuit
4. Actuator Motor Circuit
5. Idle Signal Circuit (main throttle position sensor)
6. Cruise Control ECUDI−336
DI−310
DI−319
DI−296
DI−316IN−28
Gear shifting frequent between 3rd O/D when driving on uphill
road. (Hurting)1. Electronically Controlled Transmission Communication
Circuit
2. Cruise Control ECUDI−319
IN−28
Cruise control not cancelled, even when brake pedal is de-
pressed.
1. Cruise Control Cable
2. Stop Light Switch Circuit
3. Actuator Motor Circuit
4. Cruise Control ECUDI−336
DI−314
DI−296IN−28
Cruise control not cancelled, even when transmission is shifted to
”N” postion.
1. Cruise Control Cable
2. Park/Neutral Position Switch Circuit
3. Actuator Motor Circuit
4. Cruise Control ECUDI−336
DI−322
DI−296IN−28
Control switch does not operate.
(SET/COAST, A CC/RES, CANCEL not possible)
1. Cruise Control Cable
2. Control Switch Circuit
3. Actuator Motor Circuit
4. Cruise Control ECUDI−336
DI−311
DI−296 IN−28
SET possible at 40 km/h (25 mph) or less, or CANCEL does not
operate at 40 km/h (25 mph) or less.
1. Cruise Control Cable
2. Vehicle Speed Signal Abnormal
3. Actuator Motor Circuit
4. Cruise Control ECUDI−336
DI−310
DI−296IN−28
Poor response is ACCEL and RESUME modes.
1. Cruise Control Cable
2. Electronically Controlled Transmission Communication
Circuit
3. Actuator Motor Circuit
4. Cruise Control ECUDI−336
DI−319
DI−296IN−28
O/D does not RESUME, even though the road is not uphill.
1. Electronically Controlled Transmission Communication
Circuit
2. Cruise Control ECUDI−319
IN−28
DTC memory is erased.1. Back− up Power Source Circuit
2. Cruise Control ECUDI−328 IN−28
DTC is not output, or is output when is should not be.1. Diagnosis Circuit
2. Cruise Control ECUDI−319IN−28
Cruise MAIN indicator light remains ON or fall to light up.1. Cruise MAIN Indicator Light Switch CircuitDI−332
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

DI5OB−02
Duty Ratio =A + BA
