1996 TOYOTA LAND CRUISER Workshop Manual

BR1CK-01
BR-12
-
BRAKE BRAKE MASTER CYLINDER
1996 LAND CRUISER (RM451U)
INSPECTION
HINT:
Clean the disassembled parts with compressed air.
1. INSPECT CYLINDER BORE FOR RUST OR SCORING
2. INSPECT CYLINDER FOR WEAR OR DAMAGE
If necessary, clean or replace the cylinder.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BR1CL-01
-
BRAKE BRAKE MASTER CYLINDER
BR-13
1996 LAND CRUISER (RM451U)
REASSEMBLY
Reassembly is in the reverse order of disassembly.
NOTICE:
Apply lithium soap base glycol grease to the rubber parts indicated by t\
he arrows
(See page BR-9 ).
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BR1CM-01
BR-14
-
BRAKE BRAKE MASTER CYLINDER
1996 LAND CRUISER (RM451U)
INSTALLATION
Installation is in the reverse order of removal (See page BR-9).
HINT:

Before installation, adjust length of brake booster push rod (See page \
BR-18).

After installation, fill brake reservoir with brake fluid, bleed brake s\
ystem (See page BR-4).

Check for leaks, check and adjust brake pedal (See page BR-6).
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BR1CN-01
BR2238
-
BRAKE BRAKE BOOSTER ASSEMBLY
BR-15
1996 LAND CRUISER (RM451U)
BRAKE BOOSTER ASSEMBLY
OPERATION
1. OPERATING CHECK
(a) Depress the brake pedal several times with the engine off
and check that there is no change in the pedal reserve
distance.
(b) Depress the brake pedal and start the engine. If the pedal
goes down slightly, operation is normal.
2. AIR TIGHTNESS CHECK
(a) Start the engine and stop it after 1 or 2 minutes. Depress the brake pedal several times slowly. If the pedal goes
down furthest the 1st time, but gradually rises after the
2nd or 3rd time, the booster is air tight.
(b) Depress the brake pedal while the engine is running, and
stop the engine with the pedal depressed. If there is no
change in the pedal reserve travel after holding the pedal
for 30 seconds, the booster is air tight.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BR1CO-01
BR-16
-
BRAKE BRAKE BOOSTER ASSEMBLY
1996 LAND CRUISER (RM451U)
COMPONENTS
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BR2237
BR1NM−01
BR2238
−
BRAKE BRAKE BOOSTER ASSEMBLY
BR−17
999
Author: Date:
1996 LAND CRUISER (RM451U)
BRAKE BOOSTER ASSEMBLY
OPERATION
1. OPERATING CHECK
(a) Depress the brake pedal several times with the engine off
and check that there is no change in the pedal reserve
distance.
(b) Depress the brake pedal and start the engine. If the pedal
goes down slightly, operation is normal.
2. AIR TIGHTNESS CHECK
(a) Start the engine and stop it after 1 or 2 minutes. Depress
the brake pedal several times slowly. If the pedal goes
down furthest the 1st time, but gradually rises after the
2nd or 3rd time, the booster is air tight.
(b) Depress the brake pedal while the engine is running, and
stop the engine with the pedal depressed. If there is no
change in the pedal reserve travel after holding the pedal
for 30 seconds, the booster is air tight.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BR1CO−02
BR−18
−
BRAKE BRAKE BOOSTER ASSEMBLY
1996 LAND CRUISER (RM451U)
COMPONENTS
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BR1CP−03
BR3753
−
BRAKE BRAKE BOOSTER ASSEMBLY
BR−19
1996 LAND CRUISER (RM451U)
REMOVAL
1. REMOVE MASTER CYLINDER (See page BR−9 )
2. REMOVE THESE PARTS:
Return spring
Clip and clevis pin
Clevis
Vacuum hose
3. REMOVE BRAKE BOOSTER
(a) Remove the 4 booster installation nuts.
(b) Remove the booster and gasket.
Brought to you by BirfMark
