1996 TOYOTA LAND CRUISER Workshop Manual

DI−12
−
DIAGNOSTICS ENGINE
1996 LAND CRUISER (RM451U)
(b) TOYOTA Enhanced Signals.
TOYOTA hand−held tester displayMeasurement ItemNormal Condition*
MISFIRE RPMEngine RPM for first misfire rangeMisfire 0: 0 rpm
MISFIRE LOADEngine load for first misfire rangeMisfire 0: 0 g/r
INJECTORFuel injection time for cylinder No.1Idling: 2.0 − 3.5 ms
IAC STEP POSIntake Air Control Valve step position
Opening position step motor type IAC valveIdling: 10 − 50 step
STARTER SIGStarter SignalCranking: ON
CTP SWClosed Throttle Position Switch SignalThrottle Fully Closed: ON
A/C SIGA/C Switch SignalA/C ON: ON
PNP SWPark/Neutral Position Switch SignalP or N Position: ON
STOP LIGHT SWStop Light Switch SignalStop light switch ON: ON
FC IDLFuel Cut Idle: Fuel cut when throttle valve fully
closed, during decelerationFuel cut operating: ON
FC TAUFuel Cut TAU: Fuel cut during very light loadFuel cut operating: ON
CYL#1 − CYL#6Ratio of revolution variation for each cylinder
when variation is large0%
IGNITIONIgnition rate for all cylinders every 1,000 revolu-
tions0 − 3,000 rpm
EGRT GASEGR Gas Temp. Sensor V alueEGR not operating: Temp. between intake air
temp. and engine coolant temp.
EGR SYSTEMEGR System Operating ConditionIdling: OFF
FUEL PRES UP VSVFuel Pressure Up VSV SignalHigh temp. restarting: ON
FUEL PUMPFuel Pump SignalIdling: ON
TOTAL FT B1Total Fuel Trim Bank 1: Average value for fuel
trim system of bank 1Idling: 0.8 − 1.2 V
O2 LR B1, S1
Oxygen Sensor Lean Rich Bank 1, Sensor 1
Response time for oxygen sensor output to
switch from lean to rich
Idling after warmed up: 0 − 1,000 msec.
O2 RL B1, S1
Oxygen Sensor Rich Lean Bank 1, Sensor 1
Response time for oxygen sensor output to
switch from rich to lean
Idling after warmed up: 0 − 1,000 msec.
∗: If no conditions are specifically stated for ”ldling”, it means t\
he shift lever is at N or P position, the A/C switch
is OFF and all accessory switches are OFF.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

DI5OV−03
−
DIAGNOSTICS ENGINE
DI−13
1996 LAND CRUISER (RM451U)
DIAGNOSTIC TROUBLE CODE CHART
HINT:
Parameters listed in the chart may not be exactly the same as your reading due to \
the type of instrument
or other factors.
If a malfunction code is displayed during the DTC check in check mode, che\
ck the circuit for that code listed
in the table below. For details of each code, turn to the page referred to under the ’’See page ’’ for the respe-
cire ’’DTC No.’’ in the DTC chart.
DTC No.
(See Page)Detection ItemTrouble AreaMILMemory
P0100
( DI−20 )Mass Air Flow Circuit
MalfunctionOpen or short in mass air flow meter circuit
 Mass air flow meter
 ECM
 *1
P0101
( DI−25 )Mass Air Flow Circuit
Range/Performance
Problem
Mass air flow meter *1
P0110
( DI−26 )Intake Air Temp. Circuit
MalfunctionOpen or short in intake air temp. sensor circuit
 Intake air temp. sensor
 ECM
 *1
P0115
( DI−30 )Engine Coolant Temp. Circuit
MalfunctionOpen or short in engine coolant temp. sensor circuit
 Engine coolant temp. sensor
 ECM
 *1
P0116
( DI−34 )Engine Coolant Temp. Circuit
Range/Performance ProblemEngine coolant temp. sensor
 Cooling system *1
P0120
( DI−35 )Throttle/Pedal Position
Sensor/Switch ”A” Circuit
MalfunctionOpen or short in throttle position sensor circuit
 Throttle position sensor
 ECM
 *1
P0121
( DI−39 )Throttle/Pedal Position
Sensor/Switch ”A” Circuit
Range/Performance Problem
Throttle position sensor *1
P0125
( DI−40 )Insufficient Coolant Temp. for
Closed Loop Fuel Control Open or short in heated oxygen sensor circuit
 Heated oxygen sensor *1
P0130
( DI−43 )Heated Oxygen Sensor Circuit
Malfunction (Bank 1 Sensor 1)Heated oxygen sensor
 Fuel trim malfunction *1
P0133
( DI−46 ) Heated Oxygen Sensor Circuit
Slow Response
(Bank 1 Sensor 1)
Heated oxygen sensor *1
P0135
( DI−47 ) Heated Oxygen Sensor Heater
Circuit Malfunction
(Bank 1 Sensor 1)Open or short in heater circuit of heated oxygen sensor
 Heated oxygen sensor heater
 ECM
 *1
P0136
( DI−49 )Heated Oxygen Sensor Circuit
Malfunction
(Bank 1 Sensor 2)
Heated oxygen sensor *1
P0141
( DI−47 ) Heated Oxygen Sensor Heater
Circuit Malfunction
(Bank 1 Sensor 2)
Same as DTC No. P0135 *1
*1: MIL lights up
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

DI−14
−
DIAGNOSTICS ENGINE
1996 LAND CRUISER (RM451U)
DTC No.
(See Page)
Detection ItemTrouble AreaMILMemory
P0171
( DI−51 )System too Lean
(Fuel T rim)
Air intake (hose loose)
 Fuel line pressure, leak
 Injector blockage
 Heated oxygen sensor malfunction
 Mass air flow meter
 Engine coolant temp. sensor
 *1
P0172
( DI−51 )System too Rich
(Fuel T rim)
Fuel line pressure
 Injector leak, blockage
 Heated oxygen sensor malfunction
 Mass air flow meter
 Engine coolant temp. sensor
 *1
P0300
( DI−54 )Random/Multiple Cylinder
Misfire DetectedIgnition system
 Injector
 Fuel line pressure
 EGR
 Compression pressure
 Valve clearance not to specification
 Valve timing
 Mass air flow meter
 Engine coolant temp. sensor
 *2
P0301
P0302
P0303
P0304
P0305
P0306
( DI−54 )Misfire Detected
− Cylinder 1
− Cylinder 2
− Cylinder 3
− Cylinder 4
− Cylinder 5
− Cylinder 6
P0325
( DI−59 )Knock Sensor 1 Circuit
MalfunctionOpen or short in knock sensor 1 circuit
 Knock sensor 1 (looseness)
 ECM
 *1
P0330
( DI−59 )Knock Sensor 2 Circuit
MalfunctionOpen or short in knock sensor 2 circuit
 Knock sensor 2 (looseness)
 ECM
 *1
P0335
( DI−62 )Crankshaft Position Sensor
”A” Circuit Malfunction
Open or short in crankshaft position sensor circuit for NE sig-
nal
 Crankshaft position sensor for NE signal
 Starter
 ECM
 *1
P0340
( DI−65 )Camshaft Position Sensor
Circuit MalfunctionOpen or short in camshaft position sensor circuit
 Camshaft position sensor
 ECM
 *1
P0385
( DI−67 )Crankshaft Position Sensor
”B” Circuit Malfunction
Open or short in crankshaft position sensor circuit for NE2
signal
 Crankshaft position sensor for NE2 signal
 ECM
 *1
P0401
( DI−69 )Exhaust Gas Recirculation
Flow Insufficient Detected
EGR valve stuck closed
 Short in VSV circuit for EGR
 Open in EGR gas temp. sensor circuit
 EGR hose disconnected
 ECM
 *1
P0402
( DI−80 )Exhaust Gas Recirculation
Flow Excessive Detected
EGR valve stuck open
 EGR VSV open malfunction
 Open in VSV circuit for EGR
 Short in EGR gas temp. sensor circuit
 ECM
 *1
*1: MIL lights up
*2: MIL lights up or blinking
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

−
DIAGNOSTICS ENGINE
DI−15
1996 LAND CRUISER (RM451U)
DTC No.
(See Page)
Detection ItemTrouble Area*MILMemory
P0420
( DI−84 )Catalyst System Efficiency
Below Threshold Three− way catalytic convertor
 Open or short in heated oxygen sensor circuit
 Heated oxygen sensor

P0500
( DI−87 )Vehicle Speed Sensor
Malfunction
Combination meter
 Open or short in speed sensor circuit
 ECM
 Vehicle speed sensor

P0505
( DI−89 )Idle Control System
Malfunction
IAC valve is stuck or closed
 Open or short in IAC valve circuit
 Open or short A/C signal circuit
 Air intake (hose loose)

P0510
( DI−93 )Closed Throttle Position
Switch MalfunctionOpen in closed throttle position switch circuit
 Closed throttle position switch
 ECM

P1300
( DI−97 )Igniter Circuit Malfunction
Open or short in IGF or IGT circuit from igniter to ECM
 Igniter
 ECM

P1335
( DI−102 )Crankshaft Position Sensor
Circuit Malfunction
(during engine running)
Open or short in crankshaft position sensor circuit for NE sig-
nal
 Crankshaft position sensor for NE signal
 Starter
 ECM
−
P1500
( DI−103 )Stater signal circuit MalfunctionOpen or short in starter signal circuit
 ECM−
P1600
( DI−105 )ECM BATT MalfunctionOpen in back up power source circuit
 ECM
P1605
( DI−107 )Knock Control CPU MalfunctionECM
P1780
( DI−108 )Park/Neutral Position Switch
MalfunctionShort in park/neutral position switch circuit
 Park/neutral position switch
 ECM

*: −  MIL does not light up,   MIL lights up
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

DI5OW−03
A15824
DI−16
−
DIAGNOSTICS ENGINE
1996 LAND CRUISER (RM451U)
PARTS LOCATION
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

DI5OX−03
FI6526
12345678910
11
1213
1415161718192021222324252612345678
910
11
1213141516 123456
78
910
11
12 12345678910
11
1415161718192021221213
E4 E5E6 E7
ECM Terminals
−
DIAGNOSTICS ENGINE
DI−17
1996 LAND CRUISER (RM451U)
TERMINALS OF ECM
Symbols (Terminals No.)Wiring ColorConditionSTD Voltage (V)
BATT (E7 − 2) − E1 (E4 − 24)R − Y ↔ BR − BAlways9 − 14
+ B (E7 − 12) − E1 (E4 − 24)Y ↔ BR − BIG switch ON9 − 14
VCC (E5 − 1) − E2 (E5 − 9)R − G ↔ BR − BIG switch ON4.5 − 5.5
IDL (E5 − 11) − E2 (E5 − 9)G − W ↔ BR − B
IG switch ON and apply vacuum to the throttle opener
Throttle valve fully closed0 − 3
IG switch ON
Throttle valve fully open9 − 14
VTA (E5 − 10) − E2 (E5 − 9)G − B↔ BR − B
IG switch ON
Throttle valve fully closed0.3 − 0.8
IG switch ON
Throttle valve fully open3.2 − 4.9
VG (E5 − 2) − E21 (E5 − 16)G − BRIdling, N position, A/C switch OFF1.1 − 1.5
THA (E5 − 3) − E2 (E5 − 9)L − Y ↔ BR − BIdling, Intake air temp. 20° C (68° F)0.5 − 3.4
THW (E5 − 4) − E2 (E5 − 9) R − W↔BR − BIdling, Engine coolant temp. 80 °C (176°F)0.2 − 1.0
STA (E7 − 11) − E1 (E4 − 24)B − R ↔ BR − BCranking6.0 or more
#10 (E4 − 12) − E01 (E4 − 13)W − L ↔ BR
IG switch ON9 − 14
IdlingPulse generation
(See page DI−54)
#20 (E4 − 11) − E01 (E4 − 13)W − R ↔ BR
IG switch ON9 − 14
IdlingPulse generation
(See page DI−54)
#30 (E4 − 25) − E01 (E4 − 13)W − G ↔ BR
IG switch ON9 − 14
IdlingPulse generation
(See page DI−54)
#40 (E4 − 2) − E01 (E4 − 13)Y ↔ BR
IG switch ON9 − 14
IdlingPulse generation
(See page DI−54)
#50 (E4 − 1) − E01 (E4 − 13)Y − R ↔ BR
IG switch ON9 − 14
IdlingPulse generation
(See page DI−54)
#60 (E4 − 15) − E01 (E4 − 13)Y − L ↔ BR
IG switch ON9 − 14
IdlingPulse generation
(See page DI−54)
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

DI−18
−
DIAGNOSTICS ENGINE
1996 LAND CRUISER (RM451U)
IGT (E4 −
23) − E1 (E4 − 24)
B − G ↔ BR − BIdlingPulse generation
(See page DI−97)
IGF (E4 − 17) − E1 (E4 − 24)B − Y ↔ BR − B
IG switch ON
Disconnect igniter connector4.5 − 5.5
IdlingPulse generation
(See page DI−97)
G1 (E6 − 11) − G − (E6 − 6)R ↔LIdlingPulse generation
(See page DI−62)
G2 (E6 − 10) − G − (E6 − 6)G ↔LIdlingPulse generation
(See page DI−62)
NE (E6 − 12) − G − (E6 − 6)W ↔LIdlingPulse generation
(See page DI−62)
NE2 (E6 − 5) − G − (E6 − 6)BR ↔ LIdlingPulse generation
(See page DI−62)
W (E7 − 4) − E1 (E4 − 24)Y − R ↔ BR − BIdling9 − 14
IG switch ON0 − 3
EGR (E4 − 22) − E1 (E4 − 24)L − W ↔ BR − BIG switch ON9 − 14
ISC1 (E4 − 7) − E01 (E4 − 13)R − G ↔ BRIG switch ON9 − 14
ISC2 (E4 − 6) − E01 (E4 − 13)R − B ↔ BRIG switch ON9 − 14
ISC3 (E4 − 5) − E01 (E4 − 13)G − Y ↔ BRIG switch ON9 − 14
ISC4 (E4 − 4) − E01 (E4 − 13)L − Y ↔ BRIG switch ON9 − 14
OX1 (E5 − 5) − E1 (E4 − 24)L ↔ BR − BMaintain engine speed at 2,500 rpm for 2 mins. after
warming upPulse generation
OX2 (E5 − 13) − E1 (E4 − 24)W ↔ BR − BMaintain engine speed at 2,500 rpm for 2 mins. after
warming upPulse generation
HT1 (E6 − 1) − E03 (E6 − 16)GR↔BRIdlingBelow 3.0
IG switch ON9 − 14
HT2 (E6 − 7) − E03 (E6 − 16)O↔ BRIdlingBelow 3.0
IG switch ON9 − 14
KNK1 (E5 − 6) − E1 (E4 − 24)W ↔BR − BIdlingPulse generation
(See page DI−62)
KNK2 (E5 − 14) − E1 (E4 − 24)L − W ↔ BR − BIdlingPulse generation
(See page DI−62)
SPD (E7 − 8) − E1 (E4 − 24)L − W ↔ BR − BIG switch ON
Rotate driving wheel slowly.Pulse generation
TE1 (E5 − 7) − E1 (E4 − 24)L↔ BR − BIG switch ON9 − 14
A/C (E7 − 7) − E1 (E4 − 24)B − W↔BR − BIdling, A/C switch ON9 − 14
Idling, A/C switch OFFBelow 2.0
THG (E4 − 19) − E2 (E5 − 9)G − Y↔ BR − BIG switch ON4.5 − 5.5
FC (E4 − 14) − E1 (E4 − 24)R − W↔BR − BIG switch ON9 − 14
Idling0 − 3
FPU (E4 − 21) − E1 (E4 − 24)L − R ↔BR − BIG switch ON9 − 14
Restarting at high engine coolant temp.0 − 3
SDL (E7 − 6) − E1 (E4 − 24)W ↔BR − BDuring transmissionPulse generation
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

DI5OY−03
−
DIAGNOSTICS ENGINE
DI−19
1996 LAND CRUISER (RM451U)
PROBLEM SYMPTOMS TABLE
When the malfunction code is not confirmed in the DTC check and the problem \
still can not be confirmed
in the basic inspection, then proceed to this step and perform troubleshooting according to the numbered
order given in the table below.
SymptomSuspect AreaSee page
Engine does not crank (Does not start)1. Starting systemST−16
No initial combustion (Does not start)1. ECM power source circuit
2. Fuel pump control circuitDI−11 0
DI−11 5
No complete combustion (Does not start)1. Fuel pump control circuitDI−11 5
Engine cranks normally (Difficult to start)
1. Starter signal circuit
2. Fuel pump control circuit
3. CompressionDI−103
DI−11 5 EM−3
Cold engine (Difficult to start)1. Starter signal circuit
2. Fuel pump control circuitDI−103DI−11 5
Hot engine (Difficult to start)
1. Starter signal circuit
2. Fuel pressure control circuit
3. Fuel pump control circuitDI−103
DI−125DI−11 5
High engine idle speed (Poor idling)1. A/C signal circuit
2. ECM power source circuitAC−5
DI−11 0
Low engine idle speed (Poor idling)1. A/C signal circuit
2. Fuel pump control circuitAC−5
DI−11 5
Rough idling (Poor idling)1. Compression
2. Fuel pump control circuitEM−3
DI−11 5
Hunting (Poor idling)1. ECM power source circuit
2. Fuel pump control circuitDI−11 0
DI−11 5
Hesitation/Poor acceleration (Poor driveability)1. Fuel pump control circuit
2. A/T faultyDI−11 5
DI−147
Surging (Poor driveability)1. Fuel pump control circuitDI−11 5
Soon after starting (Engine stall)1. Fuel pump control circuitDI−11 5
During A/C operation (Engine stall)1. A/C signal circuit
2. Engine control module (ECM)AC−5
IN−18
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
