1996 TOYOTA LAND CRUISER Workshop Manual

PP2YV−01
PP−68
−
PREPARATION BODY
11 7
Author: Date:
1996 LAND CRUISER (RM451U)
BODY
SST (Special Service Tools)
09806−30010Windshield Moulding Remover
09812−00010Door Hinge Set Bolt Wrench
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

PP2YW−01
−
PREPARATION BODY
PP−69
1996 LAND CRUISER (RM451U)
LUBRICANT
ItemCapacityClassification
MP grease−−
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

PP2YX−02
PP−70
−
PREPARATION BODY
1996 LAND CRUISER (RM451U)
SSM (Special Service Materials)
08833−00030Three cement black or equivalentBack door glass
08833−00070Adhesive 1324,
THREE BOND 1324 or equivalentFront door
Rear door
Power seat regulator
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

PP3KJ−01
−
PREPARATION AIR CONDITIONING
PP−71
120
Author: Date:
1996 LAND CRUISER (RM451U)
AIR CONDITIONING
SST (Special Service Tools)
07110−58060Air Conditioner Service Tool Set
(07117−58060)Refrigerant Drain Service Valve
(07117−58070)T−Joint
(07117−58080)Quick Disconnect AdapterDischarge (Diam.: 16 mm)
(07117−58090)Quick Disconnect AdapterSuction (Diam.: 13 mm)
(07117−78050)Refrigerant Charging Gauge
(07117−88060)Refrigerant Charging HoseDischarge (Color: Red)
(07117−88070)Refrigerant Charging HoseSuction (Color: Blue)
(07117−88080)Refrigerant Charging HoseUtility (Color: Green)
07112−66040Magnetic Clutch Remover
07112−76060Magnetic Clutch Stopper
07114−84010Snap Ring Pliers
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

PP−72
−
PREPARATION AIR CONDITIONING
121
Author: Date:
1996 LAND CRUISER (RM451U)
07114−84020Snap Ring Pliers
07116−38360Gas Leak Detector Assembly
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

PP2YZ−01
−
PREPARATION AIR CONDITIONING
PP−73
1996 LAND CRUISER (RM451U)
RECOMMENDED TOOLS
09082−00040TOYOTA Electrical Tester.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

PP2Z1−01
PP−74
−
PREPARATION AIR CONDITIONING
1996 LAND CRUISER (RM451U)
LUBRICANT
ItemCapacityClassification
Compressor oil
When replacing receiver
When replacing condenser
When replacing evaporator
When replacing compressor
10 cc (0.35 fl.oz.) 40 cc (1.4 fl.oz.)
40 cc (1.4 fl.oz.)
120 cc (4.1 fl.oz.)
ND− OIL 8 or equivalent
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

PR06N−01
−
PROPELLER SHAFT TROUBLESHOOTING
PR−1
849
Author: Date:
1996 LAND CRUISER (RM451U)
TROUBLESHOOTING
PROBLEM SYMPTOMS TABLE
Use the table below to help you find the cause of the problem. The numbers \
indicate the priority of the likely
cause of the problem. Check each part in order. If necessary, replace these parts.
SymptomSuspect AreaSee page
Noise3. Seeve yoke spline: worn
4. Spider bearing: worn or stuckPR−4
PR−4
Vibration
1. Sleeve yoke spline: stuck
2. Propeller shaft: runout
3. Propeller shaft: imbalancePR−4
PR−4
−
