MAINTENANCE ENGINE
MA−5
45
Author: Date:
1996 LAND CRUISER (RM451U)
ENGINE
INSPECTION
HINT:
Inspect these items when the engine is cold.
1. INSPECT DRIVE BELT (See page CH−2)
2. INSPECT AIR FILTER
(a) Visually check that the air cleaner element is not exces- sively dirty, damaged or oily.
If necessary, replace the air cleaner element.
(b) Clean the element with compressed air. First blow from the inside thoroughly, then blow off the
outside of the element.
3. REPLACE AIR FILTER
Replace the air cleaner element with a new one.
4. REPLACE SPARK PLUGS (See page IG−1 )
5. REPLACE ENGINE OIL AND OIL FILTER (See page LU−2)
6. REPLACE ENGINE COOLANT (See page CO−2)
7. INSPECT CHARCOAL CANISTER (See page EC−6 )
8. REPLACE GASKET IN FUEL TANK CAP (See page
EC−6)
9. INSPECT FUEL LINES AND CONNECTIONS (See page EC−6)
10. INSPECT EXHAUST PIPES AND MOUNTINGS
Visually inspect the p ipes, hangers and connections for severe
corrosion, leaks or damage.
11. ADJUST VALVE CLEARANCE (See page EM−4)
