1996 TOYOTA LAND CRUISER Workshop Manual

BO39D−01
−
BODY FRONT SEAT (Manual Adjuster T ype)
BO−89
1323
Author: Date:
1996 LAND CRUISER (RM451U)
FRONT SEAT (Manual Adjuster Type)
COMPONENTS
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BO39J−01
BO−90
−
BODY REAR NO.1 SEAT
1324
Author: Date:
1996 LAND CRUISER (RM451U)
REAR NO.1 SEAT
COMPONENTS
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BO39K−01
−
BODY REAR NO.2 SEAT
BO−91
1325
Author: Date:
1996 LAND CRUISER (RM451U)
REAR NO.2 SEAT
COMPONENTS
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BO39L−01
BO−92
−
BODY SEAT BELT
1326
Author: Date:
1996 LAND CRUISER (RM451U)
SEAT BELT
COMPONENTS
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BO0632
BO39M−01
BO0633
15°
45°
N10070
Full Belt Length
minus 200 mm
(7.87 in.)
−
BODY SEAT BELT
BO−93
1996 LAND CRUISER (RM451U)
SEAT BELT
INSPECTION
CAUTION:
Replace the seat belt assembly (outer belt, inner belt, bolts,
nuts or sill −bar) if it has been used in a severe impact. The
entire assembly should be replaced even if damage is not
obvious.
1. All seat belts: RUNNING TEST (IN SAFE AREA)
(a) Fasten the front seat belts.
(b) Drive the car at 10 mph (16 km/h) and make a very hard stop.
Check that the belt locks and cannot be extended at this
time.
HINT:
Conduct this test in a safe area. If the belt does not lock, remove
the belt mechanism assembly and conduct the following static
check. Also, whenever installing a new belt assembly, verify the
proper operation before installation.
2. Driver ’s seat belt (ELR): STATIC TEST
(a) Make sure that the belt locks when pulled out quickly.
(b) Remove the locking retractor assembly.
(c) Tilt the retractor slowly.
(d) Make sure that the belt can be pulled out at a tilt of 15 de-
grees or less, and cannot be pulled out at over 45 degrees
of tilt.
If a problem is found, replace the assembly.
3. Except driver’s seat belt (ALR/ELR):
STATIC TEST
(a) Make sure that the belt locks when pulled out quickly.
(b) Remove the locking retractor assembly.
(c) Pull out the whole belt and measure the length of the whole belt.
Then retract the belt slightly and pull it out again.
(d) Make sure that the belt cannot be extended further.
If a problem is found, replace the assembly.
(e) Retract the whole belt, then pull it out to the full length mi-
nus 200 mm (7.87 in.).
(f) Tilt the retractor slowly.
(g) Make sure that the belt can be pulled out at a tilt of 15 de-
grees or less, and cannot be pulled out at over 45 degrees
of tilt.
If a problem is found, replace the assembly.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BR1CC−01
−
BRAKE BRAKE SYSTEM
BR−1
983
Author: Date:
1996 LAND CRUISER (RM451U)
BRAKE SYSTEM
GENERAL DESCRIPTION
Care must be taken to replace each part properly as it could affect the perfo\
rmance of the brake
system and result in a driving hazard. Replace the parts with parts of the same part number or
equivalent.
It is very important to keep parts and the area clean when repairing the\
brake system.
If the vehicle is equipped with a mobile communication system, refer to the precaution in the
IN section.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BR1CD−01
BR−2
−
BRAKE TROUBLESHOOTING
984
Author: Date:
1996 LAND CRUISER (RM451U)
TROUBLESHOOTING
PROBLEM SYMPTOMS TABLE
Use the table below to help you find the cause of the problem. The numbers \
indicate the priority of the likely
cause of the problem. Check each part in order. If necessary, replace these parts.
SymptomSuspect AreaSee page
Low pedal or spongy pedal
4. Fluid leaks for brake system
5. Air in brake system
6. Piston seals: worn or damaged
7. Master cylinder: faulty
8. Booster push rod: out of adjustment−
−
BR−33
BR−33 BR−9
BR−20
Brake drag
1. Brake pedal freeplay: minimal
2. Parking brake lever travel: out of adjustment
3. Parking brake wire: sticking
4. Pad: cracked or distorted
5. Piston: stuck
6. Piston: frozen
7. Tension or return spring: faulty
8. Booster push rod: out of adjustment
9. . Vacuum leaks for booster system
10.. Master cylinder: faultyBR−6
BR−8 −
BR−21
BR−30
BR−33
BR−33
BR−33
BR−33
BR−39
BR−20
BR−18 BR−9
Brake pull
1. Piston: stuck
2. Pad: oily
3. Piston: frozen
4. Disc: Scored
5. Pad: cracked or distortedBR−33
BR−33
BR−21
BR−30
BR−33
BR−33
BR−33
BR−33
BR−21
BR−30
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

−
BRAKE TROUBLESHOOTING
BR−3
985
Author: Date:
1996 LAND CRUISER (RM451U)
Hard pedal but brake inef
ficient
1. Fluid leaks for brake system
2. Air in brake system
3. Pad: worn
4. Pad: cracked or distorted
5. Pad: oily
6. Pad: glazed
7. Disc: scored
8. Booster push rod: out of adjustment
9. Vacuum leaks for booster system−
−
BR−21
BR−30
BR−21
BR−30
BR−21
BR−30
BR−21
BR−30
BR−21
BR−30
BR−20
BR−18
Noise from brake
1. Pad: cracked or distorted
2. Installation bolt: loosen
3. Disc: scored
4. Pad support plate: loosen
5. Sliding pin: worn
6. Pad: dirty
7. Pad: glazed
8. Tension or return spring: faulty
9. Anti− squeal shim: damaged
10.. Hold− down spring: damagedBR−21
BR−30
BR−33
BR−33
BR−33
BR−33
BR−30
BR−33
BR−21
BR−30
BR−21
BR−30
BR−39
BR−21
BR−30
BR−39
