1996 TOYOTA LAND CRUISER Workshop Manual

LU0KL−01
LU−20
−
LUBRICATION OIL NOZZLE
731
Author: Date:
1996 LAND CRUISER (RM451U)
OIL NOZZLE
COMPONENTS
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

LU0KM−04
−
LUBRICATION OIL NOZZLE
LU−21
1996 LAND CRUISER (RM451U)
REMOVAL
1. REMOVE CYLINDER HEAD (See page EM−28 )
2. REMOVE TIMING CHAIN AND GEARS (See page EM−13 )
3. REMOVE CRANKSHAFT (See page EM−83 )
4. REMOVE OIL NOZZLES
Remove the 6 check valves and oil nozzles. Torque: 25 N·m (250 kgf·cm, 18 ft·lbf)
HINT:
At the time of installation, align the pin of the nozzle with the pin
hole of the cylinder block.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

LU0KN−01
LU−22
−
LUBRICATION OIL NOZZLE
1996 LAND CRUISER (RM451U)
INSPECTION
1. INSPECT CHECK VALVES
Push the valve with a wooden stick to check if it is stuck.
If stuck, replace the check valve.
2. INSPECT OIL NOZZLES
Check the oil nozzles for damage or clogging.
If necessary, replace the oil nozzle.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

LU0KO−01
−
LUBRICATION OIL NOZZLE
LU−23
1996 LAND CRUISER (RM451U)
INSTALLATION
Installation is in the reverse order of removal (See page LU−21 ).
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

MA02P−04
−
MAINTENANCE OUTSIDE VEHICLE
MA−1
1
Author: Date:
1996 LAND CRUISER (RM451U)
OUTSIDE VEHICLE
GENERAL MAINTENANCE
The owners are responsible for these maintenance and inspection items.
They can be done by the owner or they can have them done at a service sh\
op.
These items include those which should be checked on a daily basis, thos\
e which, in most cases, do not
require (special) tools and those which are considered to be reasonabl\
e for the owner to do.
Items and procedures for general maintenance are as follows.
1. GENERAL NOTES
Maintenance items may vary from country to country. Check the owner’s manual supplement in which
the maintenance schedule is shown.
Every service item in the periodic maintenance schedule must be performe\
d.
Periodic maintenance service must be performed according to whichever interval in\
the periodic main-
tenance schedule occurs first, the odometer reading (miles) or the time inter\
val (months).
Maintenance service after the last period should be performed at the same interval \
as before unless
otherwise noted.
Failure to do even one item can cause the engine to run poorly and incre\
ase exhaust emissions.
2. TIRES
(a) Check the pressure with a gauge.
If necessary, adjust.
(b) Check for cuts, damage or excessive wear.
3. WHEEL NUTS
When checking the tires, check the nuts for looseness or for missing nut\
s.
If necessary, tighten them.
4. TIRE ROTATION
Check the owner’s manual supplement in which the maintenance schedule is shown.
5. WINDSHIELD WIPER BLADES
Check for wear or cracks whenever they do not wipe clean.
If necessary, replace.
6. FLUID LEAKS
(a) Check underneath for leaking fuel, oil, water or other fluid.
(b) If you smell gasoline fumes or notice any leak, have the cause found and\
corrected.
7. DOORS AND ENGINE HOOD
(a) Check that all doors and the tailgate operate smoothly, and that all larches lock securely.
(b) Check that the engine hood secondary latch secures the hood from opening\
when the primary latch is released.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

MA02Q−04
MA−2
−
MAINTENANCE INSIDE VEHICLE
42
Author: Date:
1996 LAND CRUISER (RM451U)
INSIDE VEHICLE
GENERAL MAINTENANCE
The owners are responsible for these maintenance and inspection items.
They can be done by the owner or they can have them done at a service sh\
op.
These items include those which should be checked on a daily basis, thos\
e which, in most cases, do not
require (special) tools and those which are considered to be reasonabl\
e for the owner to do.
Items and procedures for general maintenance are as follows.
1. GENERAL NOTES
Maintenance items may vary from country to country. Check the owner’s manual supplement in which
the maintenance schedule is shown.
Every service item in the periodic maintenance schedule must be performe\
d.
Periodic maintenance service must be performed according to whichever interval in\
the periodic main-
tenance schedule occurs first, the odometer reading (miles) or the time inter\
val (months).
Maintenance service after the last period should be performed at the same interval \
as before unless
otherwise noted.
Failure to do even one item can cause the engine to run poorly and incre\
ase exhaust emissions.
2. LIGHTS
(a) Check that the headlights, stop lights, taillights, turn signal lights, \
and other lights are all working.
(b) Check the headlights aim.
3. WARNING LIGHTS AND BUZZERS
Check that all warning lights and buzzers function properly.
4. HORN
Check that it is working.
5. WINDSHIELD
Check for scratches, pits or abrasions.
6. WINDSHIELD WIPER AND WASHER
(a) Check operation of the wipers and washer.
(b) Check that the wipers do not streak.
7. WINDSHIELD DEFROSTER
Check that air comes out from the defroster outlet when operating the heater \
or air conditioner at defroster
mode.
8. REAR VIEW MIRROR
Check that it is mounted securely.
9. SUN VISORS
Check that they move freely and mounted securely.
10. STEELING WHEEL
Check that it has the specified freeplay. Be alert for changes in steering condition, such as hard steering,
excessive freeplay or strange noises.
11. SEATS
(a) Check that all front seat controls such as seat adjusters, seatback recl\
iner, etc. operate smoothly.
(b) Check that all latches lock securely in any position.
(c) Check that the head restraints move up and down smoothly and that the lo\
cks hold securely in any latch position.
(d) For folding −down rear seat backs, check that the latches look securely.
12. SEAT BELTS
(a) Check that the seat belt system such as buckles, retractors and anchors operat\
e properly and smooth-
ly.
(b) Check that the belt webbing is not cut, frayed, worn or damaged.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

−
MAINTENANCE INSIDE VEHICLE
MA−3
43
Author: Date:
1996 LAND CRUISER (RM451U)
13. ACCELERATOR PEDAL
Check the pedal for smooth operation and uneven pedal effort or catching.
14. BRAKE PEDAL (See page BR−6 )
(a) Check that pedal for smoothly operation.
(b) Check that the pedal has the proper reserve distance and freeplay.
(c) Check the brake booster function.
15. BRAKES
At a safe place, check that the brakes do not pull to one side when appl\
ied.
16. PARKING BRAKE (See page BR−8 )
(a) Check that the lever has the proper travel.
(b) On a safe incline, check that the vehicle is held securely with only the\
parking brake applied.
17. AUTOMATIC TRANSMISSION ”PARK” MECHANISM
(a) Check the lock release button of the selector level for proper and smoot\
h operation.
(b) On a safe incline, check that the vehicle is held securely with the select\
or lever in the P position and all brakes released.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

MA02R−04
MA−4
−
MAINTENANCE UNDER HOOD
44
Author: Date:
1996 LAND CRUISER (RM451U)
UNDER HOOD
GENERAL MAINTENANCE
1. GENERAL NOTICE
Maintenance items may vary from country to country. Check the owner’s manual supplement in which
the maintenance schedule is shown.
Every service item in the periodic maintenance schedule must be performe\
d.
Periodic maintenance service must be performed according to whichever interval in\
the periodic main-
tenance schedule occurs first, the odometer reading (miles) or the time inter\
val (months).
Maintenance service after the last period should be performed at the same interval \
as before unless
otherwise noted.
Failure to do even one item can cause the engine to run poorly and incre\
ase exhaust emissions.
2. WINDSHIELD WASHER FLUID
Check that there is sufficient fluid in the tank.
3. ENGINE COOLANT LEVEL Check that the coolant level is between the FULL and LOW lines on the se\
e −through reservoir.
4. RADIATOR AND HOSES
(a) Check that the front of the radiator is clean and not blocked with leave\
s, dirt or bugs.
(b) Check the hoses for cracks, kinks, rot or loose connections.
5. BATTERY ELECTROLYTE LEVEL
Check that the electrolyte level of all battery cells is between the upp\
er and lower level lines on the case.
If level is low, add distilled water only.
6. BRAKE FLUID LEVELS
Check that the brake fluid level is near the upper level line on the see\
−through reservoir.
7. ENGINE DRIVE BELTS
Check drive belt for fraying, cracks, wear or oiliness.
8. ENGINE OIL LEVEL
Check the level on the dipstick with the engine turned off.
9. POWER STEERING FLUID LEVEL
(a) Check the level on the dipstick.
(b) The level should be in the HOT or COLD range depending on the fluid temp\
erature.
10. AUTOMATIC TRANSMISSION FLUID LEVEL
(a) Park the vehicle on a level surface.
(b) With the engine idling and the parking and foot brake applied, shift the sel\
ector into all positions from the P to L, and then shift into the P.
(c) Pull out the dipstick and wipe off the fluid with a clean rag. Re −insert the dipstick fully and check that
the fluid level is in the HOT range.
(d) Do this check with the fluid at normal driving temperature (70 − 80°C (158 − 176° F)).
HINT:
Wait about 30 minutes before checking the fluid level after extended driving\
at high speeds in hot weather,
driving in heavy traffic or with a trailer.
11. EXHAUST SYSTEM
Visually inspect for cracks, holes or loose supports.
If any change in the sound of the exhaust or smell of the exhaust fumes is\
noticed, have the cause located
and corrected.
