BRAKE PARKING BRAKE
1996 LAND CRUISER (RM451U)
REASSEMBLY
Reassembly is in the reverse order of disassembly (See
page BR−40 ).
NOTICE:
Apply high temperature grease and lithium soap base gly-
col grease to the parts indicated by the arrows (See page
BR−39 ).
1. ADJUST PARKING BRAKE SHOE CLEARANCE
(a) Disconnect the PKB cable from bellcrank and remove the 2 tension springs.
(b) Loosen the stopper bolt.
(c) Temporarily install the hub nuts.
(d) Remove the hole plug.
(e) Turn the adjuster and expand the shoes until the disc
locks.
(f) Return the adjuster 8 notches.
(g) Install the hole plug.
2. ADJUST BELLCRANK
(a) Pull the bellcrank until all play in the interior linkage is tak-
en up.
(b) Screw in the bellcrank adjusting bolt to where it contacts on the dust seal.
(c) Loosen it one turn, and lock it at that position with the lock nut.
Torque: 5.4 N·m (55 kgf·cm, 48 in.·lbf)
(d) Install the bellcrank spring.
(e) Connect the PKB cable to the bellcrank.
3. BEDDING DOWN PARKING BRAKE SHOES AND
DISC
(a) Drive the vehicle at about 50 km/h (31 mph) on a safe, lev-
el and dry road.
(b) With the parking brake release button pushed in, pull on the lever with 88 N (9 kgf, 19.8 lbf) of force.
(c) Drive the vehicle for about 400 meters (0.25 mile) in this condition.
(d) Repeat this procedure 2 or 3 times.
4. RECHECK AND ADJUST PARKING BRAKE LEVER TRAVEL
