1996 TOYOTA LAND CRUISER Workshop Manual

RS0PE−01
−
SUPPLEMENTAL RESTRAINT SYSTEM AIRBAG SENSOR ASSEMBLY
RS−33
1996 LAND CRUISER (RM451U)
REMOVAL
NOTICE:
Do not open the cover or the case of the ECU and various
computers unless absolutely necessary.
(If the IC terminals are touched, the IC may be destroyed by
static electricity.)
1. REMOVE THESE PARTS:
(a) Transfer shirt knob
(b) Front console box
2. REMOVE AIRBAG SENSOR ASSEMBLY
(a) Disconnect the connector.
NOTICE:
Remove the connector with the sensor assembly installed.
(b) Using a torx wrench remove the 4 screws and the airbag sensor assembly.
Torx wrench: T40 (Part No. 09042 −00020 or locally
manufactured tool)
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

RS0PH−01
RS−34
−
SUPPLEMENTAL RESTRAINT SYSTEM AIRBAG SENSOR ASSEMBLY
1996 LAND CRUISER (RM451U)
INSPECTION
1. VEHICLE NOT INVOLVED IN COLLISION
Do a diagnostic system check. (See page DI−240)
2. VEHICLE INVOLVED IN COLLISION AND AIRBAG IS NOT DEPLOYED
Do a diagnostic system check. (See page DI−240)
3. VEHICLE INVOLVED IN COLLISION AND AIRBAG IS DEPLOYED
Replace the airbag sensor assembly. (See page RS−32)
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

RS0PG−01
−
SUPPLEMENTAL RESTRAINT SYSTEM AIRBAG SENSOR ASSEMBLY
RS−35
1996 LAND CRUISER (RM451U)
REPLACEMENT
REPLACEMENT REQUIREMENTS
In the following cases, replace the airbag sensor assembly.
If the SRS has been deployed in a collision.
If the airbag sensor assembly has been found to be faulty in troubleshoo\
ting.
If the airbag sensor assembly has been dropped.
CAUTION:
For removal and installation of the airbag sensor assembly, see page RS−33 and RS−36 . Be sure to
follow the correct procedure.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

RS0PF−01
RS−36
−
SUPPLEMENTAL RESTRAINT SYSTEM AIRBAG SENSOR ASSEMBLY
1996 LAND CRUISER (RM451U)
INSTALLATION
NOTICE:
Never use SRS parts from another vehicle. When replacing parts, replace with \
new parts.
Never reuse the airbag sensor assembly involved in a collision when the airbag has deployed.
Never repair a sensor in order to reuse it.
1. INSTALL AIRBAG SENSOR ASSEMBLY
(a) Using a torx wrench, install the airbag sensor assembly with the 4 screw\
s. Torx wrench: T40 (Part No. 09042 −00020 or locally manufactured tool)
Torque: 21 N·m (210 kgf·cm, 15 ft·lbf)
(b) Connect the connector.
NOTICE:
Installation of the connector is done with the sensor assembly installed\
.
Make sure the sensor assembly is installed to the specified torque.
If the sensor assembly has been dropped, or there are cracks, dents or o\
ther defects in the
case, bracket or connector, replace the sensor assembly with a new one.
When installing the sensor assembly, take care that the SRS wiring does not interfere with other
parts and is not pinched between other parts.
After installation, shake the sensor assembly to check that there is no \
looseness.
2. INSTALL THE REMOVED PARTS
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

RS0PK−01
R13515
Front Passenger Airbag Assembly
Steering Wheel Pad Airbag Sensor Assembly
−
SUPPLEMENTAL RESTRAINT SYSTEM WIRE HARNESS AND CONNECTOR
RS−37
1136
Author: Date:
1996 LAND CRUISER (RM451U)
WIRE HARNESS AND CONNECTOR
LOCATION
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

RS0PJ−01
RS−38
−
SUPPLEMENTAL RESTRAINT SYSTEM WIRE HARNESS AND CONNECTOR
1996 LAND CRUISER (RM451U)
INSPECTION
HINT:
The SRS wire harness is integrated with the cowl wire harness assembly and \
floor wire harness assembly.
The wires for the SRS wire harness are encased in a black corrugated tube a\
nd all the connectors in the
system are a standard yellow color.
1. VEHICLES NOT INVOLVED IN COLLISION
Do a diagnostic system check (See page DI−240).
2. VEHICLES INVOLVED IN COLLISION
(a) Do a diagnostic system check (See page DI−240).
(b) Check for breaks in all wires of the SRS wire harness, and for exposed c\
onductors.
(c) Check to see if the SRS wire harness connectors are cracked or chipped.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

RS0PI−01
−
SUPPLEMENTAL RESTRAINT SYSTEM WIRE HARNESS AND CONNECTOR
RS−39
1996 LAND CRUISER (RM451U)
REPLACEMENT
In the following cases, replace the wire harness or connector.
If any part of the SRS wire harness or any connector has been found to be \
faulty in troubleshoot-
ing.
If any part of the SRS wire harness or any connector has been found to be \
faulty during the check
in items 2−(b) or (c).
NOTICE:
If the wire harness used in the SRS is damaged, replace the whole wire h\
arness assembly.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

SA1U7−01
−
SUSPENSION AND AXLE TROUBLESHOOTING
SA−1
858
Author: Date:
1996 LAND CRUISER (RM451U)
TROUBLESHOOTING
PROBLEM SYMPTOMS TABLE
Use the table below to help you find the cause of the problem. The numbers \
indicate the priority of the likely
cause of the problem. Check each part in order. If necessary, replace these parts.
(w/ Differential locking system):
Check that center differential lock mode is set.
When switching differential Free↔Lock, the indicator lamp will blink if the gears of the differen-
tial lock sleeve are not meshed. If this occurs, when the tires are rotated \
to apply differential
power to the differential, the differential locks and the indicator lamp\
light up.
SymptomSuspect AreaSee page
Wander/ pulls
1. Tires: worn or improperly inflated
2. Wheel alignmemt: incorrect
3. Steering linkage: loosen or worn
4. Hub bearings: loosen or worn
5. Steering gear: out of adjustment or brokenSA−3
SA−4
SR−47 SA−8
SR−41
Bottoming
1. Vehicle: overloaded
2. Spring weak
3. Shock absorber: worn out−
SA−49
SA−49
Sways/ pitches
1. Tires: worn or improperly inflated
2. Stabilizer bar: bent or broken
3. Shock absorber: worn outSA−3
SA−60
SA−49
Front wheel shimmy
1. Tires: worn or improperly inflated
2. Wheels: out of balance
3. Shock absorber: worn out
4. Wheel alignmemt: incorrect
5. Hub bearings: loosen or worn
6. Steering linkage: loosen or worn
7. Steering gear: out of adjustment or brokenSA−3
SA−3
SA−49 SA−3
SA−7
SR−45
SR−38
Abnormal tire wear
1. Tires: worn or improperly inflated
2. Wheel alignmemt: incorrect
3. Suspension parts: worn out
4. Shock absorber: worn outSA−3
SA−3 −
SA−49
Noise in front dif ferential
1. Oil level: low or wrong grade
2. Excessive backlash between pinion and ring gear
3. Ring, pinion ro side gears: worn or chipped
4. Pinion shaft bearing: worn
5. Side bearing: worn
6. Differential bearing: loosen or wornSA−21
SA−29
SA−29
SA−29
SA−29
SA−29
Oil leak from front dif ferential
1. Oil level: too high or wrong grade
2. Drive pinion oil seal: worn or damaged
3. Side gear oil seal: worn or damaged
4. Companion flange: loosen or damaged
5. Side gear shaft: damagedSA−21
SA−29
SA−29
SA−29
SA−29
Noise in rear axle
1. Oil level: low or wrong grade
2. Excessive backlash between pinion and ring gear
3. Ring, pinion ro side gears: worn or chipped
4. Pinion shaft bearing: worn
5. Axle shaft bearing: worn
6. Differential bearing: loosen or wornSA−73
SA−87
SA−87
SA−87
SA−87
SA−87
Oil leak from rear axle1. Oil seal: worn or damaged
2. Rear axle housing: crackedSA−73
−
