1996 TOYOTA LAND CRUISER Workshop Manual

R11852Weight
R04211
Inner Diam
Tires
(3 or More) Width
−
SUPPLEMENTAL RESTRAINT SYSTEM STEERING WHEEL PAD AND SPIRAL CABLE
RS−17
1996 LAND CRUISER (RM451U)
(f) Cover the steering wheel pad with a cardboard box or
tires.
Covering method using a cardboard box:
Cover the steering wheel pad with the cardboard
box and weight the cardboard box down in 4 places
with at least 190 N (20 kg, 44 lb).
Size of cardboard box:
Must exceed the following dimensions:
x=460 mm (18.11 in.)
When dimension of the cardboard box exceeds the di-
ameter of the disc wheel with tire to which the steer-
ing wheel pad is tied
x=460 mm (18.11 in.) + width of tire
y= 650 mm (25.59 in.)
NOTICE:
If a cardboard box smaller than the specified size is used,
the cardboard box will be broken by the shock from the air-
bag deployment.
Covering method using tires:
Place at least 3 ti res without disc wheel on top of the
disc wheel with tire to which the steering wheel pad
is tied.
Tire size: Must exceed the following dimensions −
Width: 185 mm (7.87 in.)
Inner diameter: 360 mm (14.17 in.)
CAUTION:
Do not use tires with disc wheels.
NOTICE:
The tires may be marked by the airbag deployment, so use
the redundant tires.
(g) Deploy the airbag. (1) Connect the SST red clip to the battery positive (+)
terminal and the black clip to the battery negative
(−) terminal.
(2) Check that no one is within 10 m (33 ft) area around
the disc wheel which the steering wheel pad is tied
to.
(3) Press the SST activation switch and deploy the air- bag.
HINT:
The airbag deploys simultaneously as the LED of the SST ac-
tivation switch lights up.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

AB0166
RS−18
−
SUPPLEMENTAL RESTRAINT SYSTEM STEERING WHEEL PAD AND SPIRAL CABLE
1996 LAND CRUISER (RM451U)
(h) Dispose of the steering wheel pad (with airbag).
CAUTION:
The steering wheel pad is very hot when the airbag is
deployed, so leave it alone for at least 30 minutes af-
ter deployment.
Use gloves and safety glasses when handling a steer-
ing wheel pad with deployed airbag.
Always wash your hands with water after completing
the operation.
Do not apply water, etc. to a steering wheel pad with
deployed airbag.
(1) Remove the steering wheel pad from the disc wheel.
(2) Place the steering wheel pad in a vinyl bag, tie the end tightly and dispose of it in the same way as oth-
er general parts disposal.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

RS0RT−01
−
SUPPLEMENTAL RESTRAINT SYSTEM STEERING WHEEL PAD AND SPIRAL CABLE
RS−19
1996 LAND CRUISER (RM451U)
REPLACEMENT
REPLACEMENT REQUIREMENTS
In the following cases, replace the steering wheel pad, steering wheel o\
r spiral cable.
CaseReplacing part
If the airbag has been deployed.Steering wheel pad
If the steering wheel pad has been found to be faulty in troubleshooting\
.Steering wheel pad
If the spiral cable has been found to be faulty in troubleshooting.Spiral cable
If the steering wheel pad has been found to be faulty during checking it\
ems.
(See page RS−9)Steering wheel pad
If the steering wheel has been found to be faulty during checking items.\

(See page RS−9)Steering wheel
If the spiral cable has been found to be faulty during checking items.
(See page RS−9)Spiral cable
If the steering wheel pad has been dropped.Steering wheel pad
CAUTION:
For removal and installation of the steering wheel pad, see pages SR−11 and SR−19, and be sure to
follow the correct procedure.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

RS0P6−01
RS−20
−
SUPPLEMENTAL RESTRAINT SYSTEM STEERING WHEEL PAD AND SPIRAL CABLE
1996 LAND CRUISER (RM451U)
INSTALLATION
INSTALL STEERING WHEEL AND SPIRAL CABLE (See page RS−7)
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

RS0P7−01
−
SUPPLEMENTAL RESTRAINT SYSTEM FRONT PASSENGER AIRBAG ASSEMBLY
RS−21
1120
Author: Date:
1996 LAND CRUISER (RM451U)
FRONT PASSENGER AIRBAG ASSEMBLY
COMPONENTS
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

RS0P8−01
RS−22
−
SUPPLEMENTAL RESTRAINT SYSTEM FRONT PASSENGER AIRBAG ASSEMBLY
1996 LAND CRUISER (RM451U)
REMOVAL
NOTICE:
If the wiring connector of the SRS is disconnected with the
ignition switch at ON or ACC, DTCs will be recorded.
1. DISCONNECT AIRBAG CONNECTOR
(a) Remove the glove compartment door (See page BO−76 ).
(b) Remove the airbag connector from the airbag bracket.
NOTICE:
When handling the airbag connector , take care not to dam-
age the airbag wire harness.
(c) Disconnect the airbag connector.
2. REMOVE INSTRUMENT PANEL
(See pages BO−76 )
3. REMOVE FRONT PASSENGER AIRBAG ASSEMBLY
(a) Remove the 4 bolts and 2 nuts, and remove front passen-
ger airbag assembly.
(b) Pry up the 6 clips shown in the illustration and remove the airbag door.
CAUTION:
Do not store the front passenger airbag assembly with the
airbag deployment direction facing down.Never disas-
semble the front passenger airbag assembly.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

RS0P9−01
−
SUPPLEMENTAL RESTRAINT SYSTEM FRONT PASSENGER AIRBAG ASSEMBLY
RS−23
1996 LAND CRUISER (RM451U)
INSPECTION
1. VEHICLES NOT INVOLVED IN COLLISION
(a) Do a diagnostic system check (See page DI−240).
(b) Do a visual check which includes the following items with the front passenger airbag assembly installed in the ve-
hicle.
Check cuts, minute cracks or marked discoloration on the
front passenger airbag assembly and instrument panel.
2. VEHICLE INVOLVED IN COLLISION AND AIRBAG IS NOT DEPLOYED
(a) Do a diagnostic system check (See page DI−240).
(b) Do a visual check which includes the following items with the front passenger airbag assembly removed from the
vehicle.
Check cuts, minute cracks or marked discoloration
on the front passenger airbag assembly.
Check cuts and cracks in wire harnesses, and for
chipping in connectors.
Check the deformation or cracks on the instrument
panel and instrument panel reinforcement.
HINT:
If the instrument panel or instrument panel reinforcement is de-
formed or cracked, never repair it. Always replace it with a new
one.
CAUTION:
For removal and installation of the front passenger airbag
assembly, see page RS−22 and RS−31 and be sure to follow
the correct procedure.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

RS−24
−
SUPPLEMENTAL RESTRAINT SYSTEM FRONT PASSENGER AIRBAG ASSEMBLY
1996 LAND CRUISER (RM451U)
3. VEHICLE INVOLVED IN COLLISION AND AIRBAG IS
DEPLOYED
(a) Do a diagnostic system check (See page DI−240).
(b) Do a visual check which includes the following items with the front passenger airbag assembly removed from the
vehicle.
Check the deformation or cracks on the instrument
panel and instrument panel reinforcement.
Check the damage on the connector and wire har-
ness.
HINT:
If the instrument panel or instrument panel reinforcement is de-
formed or cracked, never repair it. Always replace it with a new
one.
