1996 TOYOTA LAND CRUISER Workshop Manual

R05894 AB0117H00001
Airbag Sensor
Assembly
LOCK
Spiral
Cable
D Squib P Squib
R14285 AB0119H00021
ON
Airbag Sensor Assembly
ACC IG2
(+)
(−)
DI−272
−
DIAGNOSTICS SUPPLEMENTAL RESTRAINT SYSTEM
1996 LAND CRUISER (RM451U)
INSPECTION PROCEDURE
1 Preparation.
PREPARATION:
(a) Disconnect negative ( −) terminal cable from the battery,
and wait at least 90 seconds.
(b) Remove steering wheel pad (See page SR−11).
(c) Disconnect connector of front passenger airbag assem- bly (See page RS−22 ).
(d) Disconnect connector of airbag sensor assembly (See page RS−33 ).
CAUTION:
Store the steering wheel pad with the front surface facing
upward.
2 Check source voltage.
PREPARATION:
(a) Connect negative ( −) terminal cable to battery.
(b) Turn ignition switch ON.
CHECK:
Measure voltage at IG2 or ACC on sensor and operate electric
system. (defogger, wiper, headlight, heater blower, etc.)
OK:
Voltage: 10 − 14 V
NG Check the harness between battery and airbag sensor assembly, and check the battery and
charging system.
OK
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

H00003
ON
−
DIAGNOSTICS SUPPLEMENTAL RESTRAINT SYSTEM
DI−273
1996 LAND CRUISER (RM451U)
3 Does SRS warning light turn off?
PREPARATION:
(a) Turn ignition switch to LOCK.
(b) Connect steering wheel pad connector.
(c) Connect front passenger airbag assembly connector.
(d) Connect airbag sensor assembly connector.
(e) Turn ignition switch ON.
CHECK:
Operate electric system (defogger, wiper, headlight, heater
blower, etc.) and check that SRS warning light goes off.
NO Check DTC, if a DTC is output, perform trouble-
shooting according to DTC, if a normal code is
output, replace airbag sensor assembly.
YES
From the results of the above inspection, the malfunctioning part can now be \
considered normal.
To make sure of this, use the simulation method to check.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

R13679
BatteryFL BLOCK 2
MAIN
W
W
ECU−B
1
F/B
S7
B−R
2
3
SRS Warning
Light
8LA
Tc
B−Y8
IH1 Airbag Sensor
Assembly
DLC1
5 W−L
11
GENERATOR
(ALTERNATOR)
W
Cruise Control ECU
W−L
W−L
B−Y
B−Y
IH1 S7 S6
S6
Short Connector
Short Connector W−L
B−L
11
12
3
EA3 11
22
7
DI−274
−
DIAGNOSTICS SUPPLEMENTAL RESTRAINT SYSTEM
1996 LAND CRUISER (RM451U)
SRS Warning Light System Malfunction (Always lit up, when igni-
tion switch is in LOCK position.)
CIRCUIT DESCRIPTION
The SRS warning light is located on the combination meter.
When the SRS is normal, the SRS warning light lights up for approx. 6 seconds after the \
ignition switch is
turned from LOCK position to ACC or ON position, and then turns off automatically.
If there is a malfunction in the SRS, the SRS warning light lights up to\
inform the driver of the abnormality.
When terminals Tc and E1 of the DLC1 are connected, the DTC is displayed by the blinking\
of the SRS warn-
ing light.
WIRING DIAGRAM
DI5QD−03
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

H00094
Airbag Sensor
Assembly
Spiral
Cable
P squib
D squib LOCK
AB0117
N12639
H00026
Airbag Sensor Assembly
LOCK
−
DIAGNOSTICS SUPPLEMENTAL RESTRAINT SYSTEM
DI−275
1996 LAND CRUISER (RM451U)
INSPECTION PROCEDURE
1 Preparation.
PREPARATION:
(a) Disconnect negative ( −) terminal cable from the battery,
and wait at least 90 seconds.
(b) Remove steering wheel pad. (See SR section)
(c) Disconnect connector of front passenger airbag assem- bly. (See page RS−22 )
CAUTION:
Store the steering wheel pad with the front surface facing
upward.
2 Does SRS warning light turn off?
PREPARATION:
(a) Turn ignition switch to LOCK.
(b) Disconnect negative ( −) terminal cable from the battery,
and wait at least 90 seconds.
(c) Disconnect airbag sensor assembly connector.
(d) Connect negative (−) terminal cable to battery.
CHECK:
Check operation of SRS warning light.
NO Check SRS warning light circuit or terminal AB circuit of DLC1.
YES
Replace airbag sensor assembly.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

N14677
Fuse
DI−276
−
DIAGNOSTICS SUPPLEMENTAL RESTRAINT SYSTEM
1996 LAND CRUISER (RM451U)
SRS Warning Light System Malfunction (Does not light up, when
ignition switch is turned to ACC or ON.)
CIRCUIT DESCRIPTION
The SRS warning light is located on the combination meter.
When the SRS is normal, the SRS warning light lights up for approx. 6 seconds after the \
ignition switch is
turned from LOCK position to ACC or ON position, and then turns off automatically.
If there is a malfunction in the SRS, the SRS warning light lights up to\
inform the driver of the abnormality.
When terminals Tc and E1 of the DLC1 are connected, the DTC is displayed by the blinking\
of the SRS warn-
ing light.
WIRING DIAGRAM
Refer to page DI−274 for the WIRING DIAGRAM.
INSPECTION PROCEDURE
1 Check ECU−B Fuse.
PREPARATION:
Remove ECU−B fuse.
CHECK:
Check continuity of ECU −B fuse.
OK:
Continuity
HINT:
Fuse may be burnt out even if it appears to be OK during
visual inspection.
If fuse is OK, install it.
NG Go to step 5.
OK
2 Preparation. (See step 1 on page DI−271)
DI5QE−03
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

AB0119
R14302H00027
Airbag Sensor Assembly
ON
LA
(−)(+)
H00051
Airbag Sensor
Assembly
P Squib
D Squib Spiral
Cable
ON
−
DIAGNOSTICS SUPPLEMENTAL RESTRAINT SYSTEM
DI−277
1996 LAND CRUISER (RM451U)
3 Check SRS warning light circuit.
PREPARATION:
(a) Connect negative ( −) terminal cable to battery.
(b) Turn ignition switch to ACC or ON.
CHECK:
Measure voltage LA terminal of harness side connector of air-
bag sensor assembly.
OK:
Voltage: 10 − 14 V
NG Check SRS warning light bulb/repair SRS warn-
ing light circuit.
OK
4 Does SRS warning light come on?
PREPARATION:
(a) Disconnect negative ( −) terminal cable from the battery.
(b) Connect airbag sensor assembly connector.
(c) Connect negative ( −) terminal cable to battery, and wait
at least 2 seconds.
(d) Turn ignition switch to ACC or ON.
CHECK:
Check operation of SRS warning light.
NO Check terminal LA of airbag sensor assembly. If normal, replace airbag sensor assembly.
YES
From the results of the above inspection, the malfunctioning part can now be \
considered normal.
To make sure of this, use the simulation method to check.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

DI−278
−
DIAGNOSTICS SUPPLEMENTAL RESTRAINT SYSTEM
1996 LAND CRUISER (RM451U)
5 Is new ECU−B fuse burnt out again?
NO Using simulation method, reproduce malfunc-
tion symptoms (See page IN−18 ).
YES
Check harness between ECU −B fuse and
SRS warning light.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

R13680
Airbag Sensor
AssemblyTc7
B−L
IH1B−Y
11
3
Tc E 1
DLC1 BR−B
EC
S6
S7 11
B−Y
Short Connector 2
2
−
DIAGNOSTICS SUPPLEMENTAL RESTRAINT SYSTEM
DI−279
1996 LAND CRUISER (RM451U)
Tc Terminal Circuit
CIRCUIT DESCRIPTION
By connecting terminals Tc and E1 of the DLC1 the airbag sensor assembly is set in the DTC output mode.
The DTCs are displayed by the blinking of the SRS warning light.
WIRING DIAGRAM
DI5QF−03
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
