Page 777 of 1399

−
EMISSION CONTROL EVAPORATIVE EMISSION (EVAP) CONTROL SYSTEM
EC−7
1996 LAND CRUISER (RM451U)
9. VISUALLY INSPECT CHARCOAL CANISTER
Look for cracks or damage.
10. INSPECT FOR CLOGGED FILTER AND STUCK VALVE
(a) Using low pressure compressed air (7.26 kPa, 74 gf/cm
2,
1.05 psi), blow into tank pipe and check that air flows with-
out resistance from the other pipes.
(b) While holding drain pipe closed, blow air (1.96 kPa, 20 gf/
cm
2, 0.28 psi) into purge pipe and check that air flow with-
out resistance from tank pipe.
If a problem is found, replace the charcoal canister.
11. CLEAN FILTER IN CANISTER
Clean the filter by blowing 294 kPa (3 kgf/cm
2, 43 psi) of com-
pressed air into tank pipe while holding purge pipe closed.
NOTICE:
Do not attempt to wash the canister.No activated carbon
should come out.
12. REINSTALL CAP TO CHARCOAL CANISTER
13. REINSTALL CHARCOAL CANISTER TO BRACKET Torque: 14 N·m (145 kgf·cm, 10 ft·lbf)
14. REINSTALL CHARCOAL CANISTER WITH BRACKET Torque: 18 N·m (185 kgf·cm, 13 ft·lbf)
15. DRAIN ENGINE COOLANT
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
Page 778 of 1399
EC−8
−
EMISSION CONTROL EVAPORATIVE EMISSION (EVAP) CONTROL SYSTEM
1996 LAND CRUISER (RM451U)
16. REMOVE TVV FROM CYLINDER HEAD
(a) Disconnect the 2 vacuum hoses.
(b) Remove the TVV.
17. INSPECT TVV OPERATION
(a) Cool the TVV to below 45° C (113°F) with cool water.
(b) Check that air flows from pipe J to the air filter.
(c) Heat the TVV to above 64° C (147°F) with hot water.
(d) Check that air flows from pipe J to pipe K.
If operation is not as specified, replace the TVV.
18. REINSTALL TVV
(a) Apply adhesive to 2 or 3 threads of the TVV, and install it.
Adhesive:
Part No. 08833 −00070, THREE BOND 1324
or equivalent
Torque: 29 N·m (300 kgf·cm, 22 ft·lbf)
(b) Reconnect 2 vacuum hoses.
19. REFILL WITH ENGINE COOLANT
20. REMOVE INTAKE MANIFOLD STAY
21. REMOVE VCV
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
Page 779 of 1399

EC0107
Orange PipeBlack Pipe
−
EMISSION CONTROL EVAPORATIVE EMISSION (EVAP) CONTROL SYSTEM
EC−9
1996 LAND CRUISER (RM451U)
22. INSPECT VCV
(a) Apply vacuum above 9.3 kPa (70 mmHg, 2.76 in.Hg) to
pipe S.
(b) Blow air into pipe Y and check that air comes out of pipe Z.
(c) Stop the applied vacuum.
(d) Blow air into pipe Y and check that air does not come out
of pipe Z.
If operation is not as specified, replace the VCV.
23. REINSTALL VCV
24. INSTALL INTAKE MANIFOLD STAY Torque: 36 N·m (360 kgf·cm, 26 ft·lbf)
25. REMOVE INTAKE MANIFOLD STAY
26. REMOVE CHECK VALVE
27. INSPECT CHECK VALVE
(a) Check that air flows from the orange pipe to the black pipe.
(b) Check that air does not flow from the black pipe to the
orange pipe.
If operation is not as specified, replace the check valve.
28. REINSTALL CHECK VALVE
HINT:
Reinstall the check valve with the black pipe facing the VCV
side.
29. INSTALL INTAKE MANIFOLD STAY Torque: 36 N·m (360 kgf·cm, 26 ft·lbf)
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
Page 780 of 1399
EC0GC−01
EC−10
−
EMISSION CONTROL EXHAUST GAS RECIRCULATION (EGR) SYSTEM
623
Author: Date:
1996 LAND CRUISER (RM451U)
EXHAUST GAS RECIRCULATION (EGR) SYSTEM
COMPONENTS
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
Page 781 of 1399

EC0JT−01
−
EMISSION CONTROL EXHAUST GAS RECIRCULATION (EGR) SYSTEM
EC−11
1996 LAND CRUISER (RM451U)
INSPECTION
1. INSPECT AND CLEAN FILTER IN EGR V ACUUM MOD-
ULATOR
(a) Remove the cap and filter.
(b) Check the filter for contamination or damage.
(c) Using compressed air, clean the filter.
(d) Reinstall the filter and cap.
HINT:
Install the filter with the coarser surface facing the atmospheric
side (outward).
2. INSTALL VACUUM GAUGE
Using a 3 −way connector, connect a vacuum gauge to the hose
between the EGR valve and EGR vacuum modulator.
3. INSPECT SEATING OF EGR VALVE
Start the engine and check that the engine starts and runs at
idle.
4. CONNECT TOYOTA HAND− HELD TESTER OR OBD II
SCAN TOOL (See page EM−10)
5. INSPECT VSV OPERATION WITH COLD ENGINE
(a) The engine coolant temperature should be below 47 °C
(117 °F).
(b) Check that the vacuum gauge indicates zero at 2,500 rpm.
(c) Check that the EGR pipe is not hot.
6. INSPECT OPERATION OF VSV AND EGR VACUUM
MODULATOR WITH HOT ENGINE
(a) Warm up the engine to above 53° C (127°F).
(b) Check that the vacuum gauge indicates low vacuum at 2,500 rpm.
(c) Disconnect the vacuum hose port R of the EGR vacuum modulator and connect port R directly to the air intake
chamber with another hose.
(d) Check that the vacuum gauge indicates high vacuum at 2,500 rpm.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
Page 782 of 1399

EC−12
−
EMISSION CONTROL EXHAUST GAS RECIRCULATION (EGR) SYSTEM
1996 LAND CRUISER (RM451U)
HINT:
As a large amount of exhaust gas enters, the engine will misfire
slightly.
7. DISCONNECT TOYOTA HAND −HELD TESTER OR
OBD II SCAN TOOL
8. REMOVE VACUUM GAUGE
Remove the vacuum gauge, and reconnect the vacuum hoses
to the proper locations.
9. INSPECT EGR VALVE
(a) Apply vacuum directly to the EGR valve with the engine idle.
(b) Check that the engine runs rough or dies.
(c) Reconnect the vacuum hoses to the proper locations.
If no problem is found with this inspection, system is normal;
otherwise inspect each part.
10. CANCEL DIAGNOSTIC TROUBLE CODE
11. REMOVE AIR INTAKE CHAMBER (See page EM−28)
12. DISCONNECT VACUUM HOSES AND CONNECTOR
13. INSPECT VSV FOR OPEN CIRCUIT
Using an ohmmeter, check that there is continuity between the
terminals. Resistance: 30 − 34 Ω at 20° C (68°F)
If there is no continuity, replace the VSV.
14. INSPECT VSV FOR GROUND
Using an ohmmeter, check that there is no continuity between
each terminal and the body.
If there is continuity, replace the VSV.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
Page 783 of 1399

(a)
(b)
(c)
−
EMISSION CONTROL EXHAUST GAS RECIRCULATION (EGR) SYSTEM
EC−13
1996 LAND CRUISER (RM451U)
15. INSPECT VSV OPERATION
(a) Check that the air flows from pipe G to pipe E.
(b) Apply battery voltage across the terminals.
(c) Check that the air does not flows from pipe G to pipe E.
If operation is not as specified, replace the VSV.
16. RECONNECT VACUUM HOSES AND CONNECTOR
17. REINSTALL AIR INTAKE CHAMBER (See page
EM−54 )
18. DISCONNECT V ACUUM HOSES FROM EGR V ACUUM
MODULATOR
(a) Disconnect the vacuum hose from R port.
(b) Disconnect the vacuum hose from Q port.
(c) Disconnect the vacuum hose from P port.
19. INSPECT EGR VACUUM MODULATOR OPERATION
(a) Block ports P and R with your finger.
(b) Blow air into port Q, and check that the air passes through
to the air filter side freely.
(c) Start the engine, and maintain speed at 2,500 rpm.
(d) Repeat the above test. Check that there is a strong resis-
tance to air flow.
If operation is not as specified, replace the EGR vacuum modu-
lator.
20. RECONNECT VACUUM HOSES TO EGR VACUUM
MODULATOR
(a) Connect the vacuum hose to R port.
(b) Connect the vacuum hose to Q port.
(c) Connect the vacuum hose to P port.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
Page 784 of 1399

EC−14
−
EMISSION CONTROL EXHAUST GAS RECIRCULATION (EGR) SYSTEM
1996 LAND CRUISER (RM451U)
21. REMOVE EGR VACUUM MODULATOR
22. REMOVE EGR VALVE
(a) Disconnect the vacuum hose from the EGR valve.
(b) Disconnect the engine wire from the clamp.
(c) Loosen the EGR pipe union nut.
(d) Remove the 2 nuts holding the EGR valve to the air intake
chamber.
(e) Using 2 nuts, remove the 2 stud bolts, EGR valve and gasket.
23. INSPECT EGR VALVE
Check for sticking and heavy carbon deposits.
If a problem is found, replace the valve.
24. REINSTALL EGR VALVE
(a) Using 2 nuts, temporarily install a new gasket, and EGR valve with the 2 stud bolts.
Torque: 9 N·m (90 kgf·cm, 78 in.·lbf)
(b) Install the 2 nuts holding the EGR valve to the air intake
chamber.
Torque: 18 N·m (180 kgf·cm, 13 ft·lbf)
(c) Tighten the union nut of the EGR pipe. Torque: 64 N·m (650 kgf·cm, 47 ft·lbf)
(d) Connect the engine wire to the clamp.
(e) Connect the vacuum hose to the EGR valve.
25. REINSTALL EGR VACUUM MODULATOR
Torque: 18 N·m (185 kgf·cm, 13 ft·lbf)
