Page 2369 of 3787
DOOR FINISHEREI-39
< ON-VEHICLE REPAIR >
C
DE
F
G H
J
K L
M A
B
EI
N
O P
6. Release the clips, then lift rear door finisher upward to remove it from door body panel.
Installation
Installation is in the reverse order of removal.
SIIA0810E
Revision: May 2010 2011 Versa
Page 2370 of 3787

EI-40
< ON-VEHICLE REPAIR >
BACK DOOR TRIM
BACK DOOR TRIM
Removal and InstallationINFOID:0000000005929570
REMOVAL
CAUTION:
• Insert a suitable tool between panel on vehicle and clips (asindicated with arrow) to release clips.
• Use a suitable tool when removing metal clips from garnishes.
• Be careful not to damage the body while prying to release clips.
• Make sure clips are properly al igned in panel holes on body
when installing, then pr ess them in completely.
1. Open back door.
2. Release the clips, then lift upward to release the pawls and remove the back door finisher lower.
3. Release the clips, then remove back door side garnish RH/LH.
4. Release the clips, then remove back door finisher upper from the back door.
INSTALLATION
Installation is in the reverse order of removal.
1. Back door finisher upper 2. Back door weatherstrip 3. Back door side garnish (RH)
4. Cover 5. Back door finisher lower 6. Back door side garnish (LH)
7. Back door PawlMetal clip
Clip C101 Vehicle front
LIIA2577E
SIIA0810E
Revision: May 2010 2011 Versa
Page 2371 of 3787
BODY SIDE TRIMEI-41
< ON-VEHICLE REPAIR >
C
DE
F
G H
J
K L
M A
B
EI
N
O P
BODY SIDE TRIM
ComponentINFOID:0000000005929571
Hatchback Models
LIIA2574E
1. Front pillar garnish 2. Front body side welt 3. Front kicking plate inner
4. Front kicking plate outer 5. Center pillar lower garnish6. Rear kicking plate inner
7. Rear pillar finisher 8. Rear body side welt9. Rear kicking plate outer
10. Center pillar upper garnish PawlMetal clip
Clip Vehicle front
Revision: May 2010 2011 Versa
Page 2372 of 3787
EI-42
< ON-VEHICLE REPAIR >
BODY SIDE TRIM
Sedan Models
Removal and InstallationINFOID:0000000005929572
WARNING:
Do not reuse center pillar upper garnish if removed.
CAUTION:
• Insert a suitable tool between panel on vehicle and clips (asindicated with arrow) to release clips.
• Use a suitable tool when removing metal clips from garnishes.
• Be careful not to damage the body while prying to release clips.
• Make sure clips are properly al igned in panel holes on body
when installing, then pr ess them in completely.
WIIA1414E
1. Front pillar garnish 2. Front body side welt3. Front kicking plate inner
4. Front kicking plate outer 5. Center pillar lower garnish6. Rear kicking plate inner
7. Rear pillar finisher 8. Rear body side welt9. Rear kicking plate outer
10. Center pillar upper garnish PawlMetal clip
Clip Vehicle front
SIIA0810E
Revision: May 2010 2011 Versa
Page 2373 of 3787
BODY SIDE TRIMEI-43
< ON-VEHICLE REPAIR >
C
DE
F
G H
J
K L
M A
B
EI
N
O P
• When releasing molded-in pawls or resin clips, follow the steps below to prevent garnish or clip
damage.
FRONT PILLAR GARNISH
Removal
Release the clips, then remove front pillar garnish.
Installation
Installation is in the reverse order of removal.
FRONT KICKING PLATE INNER
Removal
Release the clips, then remove front kicking plate inner.
Installation
Installation is in the reverse order of removal.
CAUTION:
Install the kicking plate inner starting at the front and engage the metal clips and pawls towards the
rear of the vehicle.
FRONT KICKING PLATE OUTER
Removal
PIIB2600J
PIIB2569J
PIIB2570J
Revision: May 2010 2011 Versa
Page 2374 of 3787
EI-44
< ON-VEHICLE REPAIR >
BODY SIDE TRIM
Release the clips, then remove front kicking plate outer.
Installation
Installation is in the reverse order of removal.
REAR KICKING PLATE INNER
Removal
Release the clips, then remove rear kicking plate inner.
Installation
Installation is in the reverse order of removal.
CAUTION:
Install the kicking plate inner starting at the front and engage the metal clips and pawls towards the
rear of the vehicle.
REAR KICKING PLATE OUTER
Removal
Release the clips, then remove rear kicking plate outer.
Installation
Installation is in the reverse order of removal.
CENTER PILLAR LOWER GARNISH
Removal
1. Remove front kicking plate inner. Follow the FRONT KICKING PLATE INNER procedure in this section.
2. Remove rear kicking plate inner. Follow the REAR KICKING PLATE INNER procedure in this section.
3. Remove front and rear body side welts.
PIIB2571J
PIIB2573J
PIIB2572J
Revision: May 2010 2011 Versa
Page 2375 of 3787

BODY SIDE TRIMEI-45
< ON-VEHICLE REPAIR >
C
DE
F
G H
J
K L
M A
B
EI
N
O P
4. Release the clips, then remove center pillar lower garnish.
Installation
Installation is in the reverse order of removal.
CENTER PILLAR UPPER GARNISH
Removal
WARNING:
Do not reuse center pillar upper garnish if removed.
1. Remove center pillar lower garnish. Follow t he CENTER PILLAR LOWER GARNISH procedure in this
section.
2. Remove front seat belt shoulder anchor. Refer to SB-4,
"Removal and Installation of Front Seat Belt".
3. Remove front and rear body side welts.
4. Release the resin clips, then remove center pillar upper garnish.
Installation
Installation is in the reverse order of removal.
REAR PILLAR FINISHER
Removal - Sedan
1. Remove rear kicking plate outer and rear body side welt. Refer to REAR KICKING PLATE OUTER in this
section.
2. Remove rear seatback side cushion and seat cushion. Refer to SE-28, "
Removal and Installation" (Non-
Sliding Seat).
3. Fold down 60/40 seatback. • If equipped with fixed seat, remove seatback. .
4. Release the clips, then remove rear pillar finisher.
Installation - Sedan
Installation is in the reverse order of removal.
Removal - Hatchback
1. Remove rear kicking plate outer and rear body side welt. Refer to REAR KICKING PLATE OUTER in this
section.
2. Remove rear seatback side cushion. Refer to SE-28, "
Removal and Installation" (Non-Sliding Seat), or
SE-16, "
Removal and Installation" (Sliding Seat).
3. Remove rear seat. Refer to SE-28, "
Removal and Installation" (Non-Sliding Seat), or SE-16, "Removal
and Installation" (Sliding Seat).
4. Remove back door weatherstrip. Refer to EI-40, "
Removal and Installation".
5. Remove luggage floor center board and luggage rear plate. Refer to EI-56, "
Removal and Installation".
PIIB2574J
PIIB2575J
Revision: May 2010 2011 Versa
Page 2376 of 3787
EI-46
< ON-VEHICLE REPAIR >
BODY SIDE TRIM
6. Remove luggage side lower finisher. Refer to EI-56, "Removal and Installation".
7. Remove rear seat belt outer anchor bolt. Refer to SB-6, "
Removal and Installation of Rear Seat Belt".
8. Release the clips, then remove rear pillar finisher.
Installation - Hatchback
Installation is in the reverse order of removal.
Revision: May 2010 2011 Versa
