NISSAN TIIDA 2011 Service Repair Manual AT-336 < SERVICE INFORMATION > REPAIR FOR COMPONENT PARTS • HR16DE engine models (1): O-ring (small diameter) (2): O-ring (large diameter) (3): Servo piston retainer • MR18DE engine models(1): O-r

Page 354 of 3787

NISSAN TIIDA 2011 Service Repair Manual REPAIR FOR COMPONENT PARTSAT-337 < SERVICE INFORMATION > DE F G H I J K L M A B AT N O P 8. Install OD servo piston (1) to OD servo piston retainer (2) in the direction shown. 9. Install 2nd servo ret

Page 355 of 3787

NISSAN TIIDA 2011 Service Repair Manual AT-338 < SERVICE INFORMATION > REPAIR FOR COMPONENT PARTS HR16DE engine modelsMR18DE models DISASSEMBLY SCIA7486E 1. Pinion mate gear thrust washer 2. Pinion mate gear 3. Pinion mate shaft 4. Side ge

Page 356 of 3787

NISSAN TIIDA 2011 Service Repair Manual REPAIR FOR COMPONENT PARTSAT-339 < SERVICE INFORMATION > DE F G H I J K L M A B AT N O P 1. Remove final gear (1) from differential case (2). 2. Remove differential side bearings according to the foll

Page 357 of 3787

NISSAN TIIDA 2011 Service Repair Manual AT-340 < SERVICE INFORMATION > REPAIR FOR COMPONENT PARTS 3. Remove speedometer drive gear from differential case. 4. Drive out lock pin from differential case (1) using Tool (A). 5. Draw out pinion m

Page 358 of 3787

NISSAN TIIDA 2011 Service Repair Manual REPAIR FOR COMPONENT PARTSAT-341 < SERVICE INFORMATION > DE F G H I J K L M A B AT N O P • Make sure bearings roll freely and are free from noise, cracks, pit- ting or wear. Replace if necessary. CA

Page 359 of 3787

NISSAN TIIDA 2011 Service Repair Manual AT-342 < SERVICE INFORMATION > REPAIR FOR COMPONENT PARTS c. Adjust the back clearance of side gear according to the followingprocedures. i. Insert feeler gauges (A) of the same thickness to the back

Page 360 of 3787

NISSAN TIIDA 2011 Service Repair Manual REPAIR FOR COMPONENT PARTSAT-343 < SERVICE INFORMATION > DE F G H I J K L M A B AT N O P i. Set Tool (A) on differential side bearing (RH side) (1), and press differential side bearing (RH side) to di
