Page 561 of 3787

NISSAN TIIDA 2011 Service Repair Manual POWER DOOR LOCK SYSTEMBL-51 < SERVICE INFORMATION > C DE F G H J K L M A B BL N O P 3. Check continuity between power window and door lock/unlock switch RH connector D105 terminal 3 and ground OK or N

Page 562 of 3787

NISSAN TIIDA 2011 Service Repair Manual BL-52 < SERVICE INFORMATION > POWER DOOR LOCK SYSTEM 5. Check continuity between BCM connector M19 terminal 46 andground. OK or NG OK >> Replace BCM. Refer to BCS-19, "Removal and Installa- tion of B

Page 563 of 3787

NISSAN TIIDA 2011 Service Repair Manual POWER DOOR LOCK SYSTEMBL-53 < SERVICE INFORMATION > C DE F G H J K L M A B BL N O P 1. Reconnect BCM. 2. Check voltage between BCM connector M20 terminals 59, 65 and ground. OK or NG OK >> Replace fro

Page 564 of 3787

NISSAN TIIDA 2011 Service Repair Manual BL-54 < SERVICE INFORMATION > POWER DOOR LOCK SYSTEM OK or NG OK >> Replace front door lock assembly RH (actuator). Refer to BL-167, "Removal and Installation" . NG >> Replace BCM. Refer to BCS-19, "

Page 565 of 3787

NISSAN TIIDA 2011 Service Repair Manual POWER DOOR LOCK SYSTEMBL-55 < SERVICE INFORMATION > C DE F G H J K L M A B BL N O P Check front door key cylinder switch ("KEY CYL LK -SW") and ("KEY CYL UN-SW) in DATA MONITOR mode in CONSULT–III.

Page 566 of 3787

NISSAN TIIDA 2011 Service Repair Manual BL-56 < SERVICE INFORMATION > POWER DOOR LOCK SYSTEM 1. Disconnect BCM connector M18. 2. Check continuity between BCM connector (A) M18 terminals 7,8 and front door lock assembly LH (key cylinder swit

Page 567 of 3787

NISSAN TIIDA 2011 Service Repair Manual POWER DOOR LOCK SYSTEMBL-57 < SERVICE INFORMATION > C DE F G H J K L M A B BL N O P 1. Check continuity between passenger select unlock relay con- nector (A) M2 terminal 4 and rear door lock actuator

Page 568 of 3787

NISSAN TIIDA 2011 Service Repair Manual BL-58 < SERVICE INFORMATION > REMOTE KEYLESS ENTRY SYSTEM REMOTE KEYLESS ENTRY SYSTEM Component Parts and Harness Connector LocationINFOID:0000000005929302 System DescriptionINFOID:0000000005929303 IN
