NISSAN TIIDA 2011 Service Repair Manual HOW TO ERASE PERMANENT DTCEC-35
< BASIC INSPECTION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
PERMANENT DTC SERVICE PROCEDURE
Work Procedure (Group A)INFOID:0000000006314655
JSBIA0401GB
JSBIA0064GB
Re

Page 1330 of 3787

NISSAN TIIDA 2011 Service Repair Manual EC-36
< BASIC INSPECTION >[HR16DE]
HOW TO ERASE PERMANENT DTC
1.CHECK DTC
Check DTC.
Is any DTC detected?
YES >> Repair malfunction(s) and erase DTC. Refer to EC-103, "On Board Diagnosis Function".
N

Page 1331 of 3787

NISSAN TIIDA 2011 Service Repair Manual HOW TO ERASE PERMANENT DTCEC-37
< BASIC INSPECTION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Work Procedure (Group B)INFOID:0000000006314656
NOTE:
Drive the vehicle according to only driving patterns

Page 1332 of 3787

NISSAN TIIDA 2011 Service Repair Manual EC-38
< BASIC INSPECTION >[HR16DE]
HOW TO ERASE PERMANENT DTC
5. Select Service $0A with GST.
Is any permanent DTC detected?
YES >> GO TO 3.
NO >> END
3.DRIVE DRIVING PATTERN B
CAUTION:
• Always dri

EC-38
< BASIC INSPECTION >[HR16DE]
HOW TO ERASE PERMANENT DTC
5. Select Service $0A with GST.
Is any permanent DTC detected?
YES >> GO TO 3.
NO >> END
3.DRIVE DRIVING PATTERN B
CAUTION:
• Always drive at a safe speed.
• Never erase self-diagnosis results.
• If self-diagnosis results are erased during the trip of driving pattern B or D, the counter of driving
pattern B and D is reset.
With CONSULT-III
1. Start engine and warm it up to normal operating temperature.
2. Use “PERMANENT DTC WORK SUPPORT” mode with CONSULT-III to drive the vehicle according to driving pattern B. Refer to EC-106, "
CONSULT-III Function", EC-37, "Work Procedure (Group B)".
With GST
1. Start engine and warm it up to normal operating temperature.
2. Drive the vehicle according to driving pattern B. Refer to EC-37, "
Work Procedure (Group B)".
>> GO TO 4.
4.CHECK PERMANENT DTC
With CONSULT-III
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
4. Turn ignition switch ON.
5. Select “PERMANENT DTC ST ATUS” mode with CONSULT-III.
With GST
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
4. Turn ignition switch ON.
5. Select Service $0A with GST.
Is any permanent DTC detected?
YES >> GO TO 5.
NO >> END
5.DRIVE DRIVING PATTERN D
CAUTION:
• Always drive at a safe speed.
• Never erase self-diagnosis results.
• If self-diagnosis results are erased during the trip of driving pattern B or D, the counter of driving
pattern B and D is reset.
1. Drive the vehicle according to driving pattern D. Refer to EC-37, "
Work Procedure (Group B)".
>> GO TO 6.
6.CHECK PERMANENT DTC
With CONSULT-III
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
4. Turn ignition switch ON.
5. Select “PERMANENT DTC ST ATUS” mode with CONSULT-III.
With GST
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
Revision: May 2010 2011 Versa

Page 1333 of 3787

NISSAN TIIDA 2011 Service Repair Manual HOW TO ERASE PERMANENT DTCEC-39
< BASIC INSPECTION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
3. Turn ignition switch OFF and wait at least 10 seconds.
4. Turn ignition switch ON.
5. Select Service $0

Page 1334 of 3787

NISSAN TIIDA 2011 Service Repair Manual EC-40
< FUNCTION DIAGNOSIS >[HR16DE]
ENGINE CONTROL SYSTEM
FUNCTION DIAGNOSIS
ENGINE CONTROL SYSTEM
System DiagramINFOID:0000000005929763
JMBIA2191GB
Revision: May 2010
2011 Versa

Page 1335 of 3787

NISSAN TIIDA 2011 Service Repair Manual ENGINE CONTROL SYSTEMEC-41
< FUNCTION DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
System DescriptionINFOID:0000000005929764
ECM performs various controls such as fuel
injection control and i

Page 1336 of 3787

NISSAN TIIDA 2011 Service Repair Manual EC-42
< FUNCTION DIAGNOSIS >[HR16DE]
ENGINE CONTROL SYSTEM
1. Mass air flow sensor
(with intake air temperature sensor) 2. Engine coolant temperature sensor 3. Electric throttle control actuator
4. Ca
