Page 3353 of 3787

NISSAN TIIDA 2011 Service Repair Manual TROUBLE DIAGNOSISMTC-37 < SERVICE INFORMATION > C DE F G H I K L M A B MTC N O P 1. Disconnect front air control connector. 2. Check continuity between front blower motor harness connector M62 (A) ter

Page 3354 of 3787

NISSAN TIIDA 2011 Service Repair Manual MTC-38 < SERVICE INFORMATION > TROUBLE DIAGNOSIS OK >> GO TO 11. NG >> Repair harness or connector. 11 .CHECK FAN SWITCH Check continuity between front air control terminal 9 and 10, 11, 12, 13, 14. O

Page 3355 of 3787

NISSAN TIIDA 2011 Service Repair Manual TROUBLE DIAGNOSISMTC-39 < SERVICE INFORMATION > C DE F G H I K L M A B MTC N O P 6.CHECK MAGNET CLUTCH CIRCUIT Perform diagnostic procedure for the magnetic clutch . Refer to "DIAGNOSTIC PROCEDURE FOR

Page 3356 of 3787

NISSAN TIIDA 2011 Service Repair Manual MTC-40 < SERVICE INFORMATION > TROUBLE DIAGNOSIS OK or NG OK >> GO TO 3. NG >> Check harness for open circuit. Repair or replace if necessary. 3.CHECK POWER SUPPLY FOR A/C COMPRESSOR 1. Disconnect A/

Page 3357 of 3787

NISSAN TIIDA 2011 Service Repair Manual TROUBLE DIAGNOSISMTC-41 < SERVICE INFORMATION > C DE F G H I K L M A B MTC N O P 1. Turn ignition switch OFF. 2. Disconnect front air control and BCM connector. 3. Check continuity between front air

Page 3358 of 3787

NISSAN TIIDA 2011 Service Repair Manual MTC-42 < SERVICE INFORMATION > TROUBLE DIAGNOSIS 1. Turn ignition switch OFF. 2. Disconnect front air control connector and BCM connector. 3. Check continuity between BCM harness connector M18 (A) ter

Page 3359 of 3787

NISSAN TIIDA 2011 Service Repair Manual TROUBLE DIAGNOSISMTC-43 < SERVICE INFORMATION > C DE F G H I K L M A B MTC N O P OK or NG OK >> GO TO 15. NG >> GO TO 17. 15.CHECK A/C SWITCH CIRCUIT 1. Turn ignition switch OFF. 2. Disconnect front a

Page 3360 of 3787

NISSAN TIIDA 2011 Service Repair Manual MTC-44 < SERVICE INFORMATION > TROUBLE DIAGNOSIS OK or NG OK >> • GO TO 18 (with CVT).• GO TO 19 (without CVT). NG >> GO TO 21. 18.CHECK THERMO CONTROL AMP. GROUND CIRCUIT 1. Turn ignition switch
