Page 2553 of 3787

NISSAN TIIDA 2011 Service Repair Manual TIMING CHAINEM-163 < SERVICE INFORMATION > [MR18DE] C D E F G H I J K L M A EM NP O 21. Press stopper tab (A) in the direction shown to push the timing chain slack guide (B) toward ti ming chain tensi

Page 2554 of 3787

NISSAN TIIDA 2011 Service Repair Manual EM-164 < SERVICE INFORMATION >[MR18DE] TIMING CHAIN • Check timing chain and oil pump drive chain for cracks (A) and any excessive wear (B) at the roller links of timing chain. • Replace timing c

Page 2555 of 3787

NISSAN TIIDA 2011 Service Repair Manual TIMING CHAINEM-165 < SERVICE INFORMATION > [MR18DE] C D E F G H I J K L M A EM NP O Never use an impact or other power tool to remo ve the engine oil pump sprocket bolt. If an impact or other power to

Page 2556 of 3787

NISSAN TIIDA 2011 Service Repair Manual EM-166 < SERVICE INFORMATION >[MR18DE] TIMING CHAIN 6. Align the matching marks of each sprocket with the matching marks of timing chain. NOTE: *: There are 2 outer grooves in camshaft sprocket (INT).

Page 2557 of 3787

NISSAN TIIDA 2011 Service Repair Manual TIMING CHAINEM-167 < SERVICE INFORMATION > [MR18DE] C D E F G H I J K L M A EM NP O 9. Check matching mark position of timing chain and each sprocket again. 10. Apply new engine oil to new front oil s

Page 2558 of 3787

NISSAN TIIDA 2011 Service Repair Manual EM-168 < SERVICE INFORMATION >[MR18DE] TIMING CHAIN • Make sure O-ring on cylinder block is correctly installed. • Be careful not to damage front oil seal by interference with front end of cranks

Page 2559 of 3787

NISSAN TIIDA 2011 Service Repair Manual TIMING CHAINEM-169 < SERVICE INFORMATION > [MR18DE] C D E F G H I J K L M A EM NP O InspectionINFOID:0000000006413291 INSPECTION AFTER INSTALLATION • Before starting engine, check oil/fluid levels i

Page 2560 of 3787

NISSAN TIIDA 2011 Service Repair Manual EM-170 < SERVICE INFORMATION >[MR18DE] CAMSHAFT CAMSHAFT ComponentINFOID:0000000005931018 Removal and InstallationINFOID:0000000005931019 REMOVAL WARNING: • Put a “CAUTION: FLAMMABLE” sign in t
