Page 3617 of 3787
SE-12
< SERVICE INFORMATION >
FRONT SEAT
Passenger Seat
INFOID:0000000005929605
Removal and InstallationINFOID:0000000006415817
CAUTION:
• When removing and installing, use shop cloths to protect parts from damage.
• Before removal, be sure to turn ignition switch OFF, disconnect both battery terminals, and then wait
for at least three minutes.
MANUAL SEAT
Removal
1. Seat assembly 2. Head rest holder (locked) 3. Headrest
4. Headrest holder (free) 5. Seat cushion outer finisher6. Front leg cover
7. Reclining device control wire 8. Seat cushion inner finisher 9. Snap pin
10. Reclining lever knob 11. Lever cover 12. Seat belt buckle
13. Push nut 14. Rear leg cover
WBIA0848E
Revision: May 2010 2011 Versa
Page 3618 of 3787

FRONT SEATSE-13
< SERVICE INFORMATION >
C
DE
F
G H
J
K L
M A
B
SE
N
O P
1. Disconnect the negative and positive battery term inals, then wait at least three minutes.
2. Remove the rear leg covers.
3. Remove the front leg covers.
4. Remove the mounting bolts on the back si de of the front seat. (TORX bolt: T50)
5. Remove the mounting bolts on the front side of the front seat. (TORX bolt: T50)
6. Disconnect the harness connector under the seat and remove harness securing clips.
7. Set seatback in a neutral position, and t hen remove front seat from the vehicle.
Installation
Installation is in the reverse order of removal. Be careful of the following three points.
• Before the installation, confirm that the inside and outside slide rails are locked at the same positions.
• Confirm that the slide rail location pin is set to the hole on the floor.
• Clamp the harness in position.
Disassembly and AssemblyINFOID:0000000006415818
SEAT CUSHION FINISHER
Disassembly
CAUTION:
• Front passenger seat is equipped with an Occupant Classification System sensor and control mod-
ule. Do not disassemble front passenger seat cushion assembly or remove the trim as this will affect
the Occupant Classificatio n System calibration.
• During installation, the wire harn ess clips must be installed in the holes they were originally in. Do
not add additional clips.
1. Remove the seat from the vehicle. Refer to SE-12, "
Removal and Installation".
2. Remove the seat recline and lift levers.
PIIB2669J
PIIB2668J
Revision: May 2010 2011 Versa
Page 3619 of 3787
SE-14
< SERVICE INFORMATION >
FRONT SEAT
3. Remove the seat cushion outer finisher.
4. Remove the seat cushion finisher B. First release the clip on the back and then remove in the order as
shown.
• : Metal clip
• : Clip
5. Remove the front seat belt buckle.
Assembly
Assembly is the reverse order of removal.
SEAT CUSHION TRIM AND PAD
Disassembly
1. Remove the seat cushion finishers. Refer to "SEAT CUSHION FINISHER".
2. Remove the retainer of seat cushion trim.
3. Remove the hog rings to separate the seat cushion pad and seat cushion trim.
4. Remove seat cushion trim and seat cushion pad from the seat cushion frame.
Assembly
Assembly is in the reverse order of disassembly.
PIIB2607E
PIIB2609E
Revision: May 2010 2011 Versa
Page 3620 of 3787
REAR SEATSE-15
< SERVICE INFORMATION >
C
DE
F
G H
J
K L
M A
B
SE
N
O P
REAR SEAT
Component Parts DrawingINFOID:0000000006411909
60:40 SPLIT FOLD DOWN SEAT - HATCHBACK
ALJIA0527ZZ
1. Rear seatback lock knob 2. Rear seat striker cover3. Rear seatback side trim RH
4. Rear seatback side assembly RH 5. Rear seatback side pad and frame
RH6. Rear seatback trim RH
Revision: May 2010
2011 Versa
Page 3621 of 3787

SE-16
< SERVICE INFORMATION >
REAR SEAT
Removal and Installation
INFOID:0000000006415821
CAUTION:
When removing and in stalling, use shop cloths to protect parts from damage.
60:40 SPLIT FOLD DOWN SEAT - HATCHBACK
Removal
1. Pull seat cushion up, then remove the seat cushion from the
seat cushion hook.
2. Remove the center seatbelt anchor bolt (A) from under the seat.
3. Remove the seatback mounting bolts in the reverse order as shown from the right rear seat back brackets.
7. Rear seatback assembly RH 8. Rear seatback pad RH 9. Seat cushion assembly
10. Rear seat cushion trim 11. Rear seat cushion pad and frame 12. Rear seat cushion hook (body)
13. Rear seatback assembly LH 14. Rear seatback trim LH 15. Rear seatback pad LH
16. Trim clip 17. Rear seatback side trim RH 18. Rear seatback side pad and frame
LH
19. Rear seatback side assembly LH 20. Rear seat lock assembly 21. Locking headrest holder
22. Rear headrest 23. Free headrest holder 24. Rear seat cushion hook (seat)
25. Rear seatback side bracket 26. Rear seat striker RH 27. Rear seatback center bracket
28. Rear seat striker LH
PIIB4085J
WIIA1234E
WIIA1287E
Revision: May 2010 2011 Versa
Page 3622 of 3787
REAR SEATSE-17
< SERVICE INFORMATION >
C
DE
F
G H
J
K L
M A
B
SE
N
O P
4. Remove the seatback mounting bolts in the reverse order as shown from the left rear seat back brackets.
5. Remove the seatback from the vehicle.
6. Remove the kicking plate rear inner. Refer to SE-15, "
Component Parts Drawing".
7. Remove the bolt under the seatback side.
8. Pull seatback side up, and then remove seatback side.
9. Remove the rear seatback center bracket bolts and the rear seatback center bracket.
10. Remove the rear seatback side bracket bolt and the rear seat- back side bracket.
11. Remove the rear seatback finisher. Refer to .
12. Remove the rear seat striker bolts and the rear seat striker.
Installation
Installation is in the reverse order of removal.
• When installing the rear seatback side bracket perform the following procedure:
WIIA1288E
PIIB2482J
PIIB2483J
PIIB2484J
Revision: May 2010 2011 Versa
Page 3623 of 3787
SE-18
< SERVICE INFORMATION >
REAR SEAT
1. Install the rear seatback side bracket, temporarily tighten theseatback assembly and rear seatback side bracket bolt.
2. Lift to fold up seatback assembly. Be sure to lock seatback assembly to rear seat striker.
3. Tighten the rear seatback side bracket bolt. NOTE:
Confirm that side hinge bracket location pin is set to the hole on
the seatback backside.
• Install the left rear seat back brackets and seatback mounting
bolts.
• Install the right rear seat bac k brackets and the rear seat back
bracket bolts.
Disassembly and AssemblyINFOID:0000000006415822
60:40 SPLIT FOLD DOWN SEAT - HATCHBACK
Disassembly of Armrest
1. Fold up the backside of the seatback trim and then remove the armrest nuts.
PIIB2484J
WIIA1288E
WIIA1287E
PIIB2913J
Revision: May 2010 2011 Versa
Page 3624 of 3787
REAR SEATSE-19
< SERVICE INFORMATION >
C
DE
F
G H
J
K L
M A
B
SE
N
O P
2. Push the armrest toward left side while pulling backward to remove.
3. Remove the rear seat bushing, and then remove the armrest hinge cover by pulling it backward.
Assembly of Armrest
Assembly is in the reverse order of disassembly.
Disassembly of Seatback Trim and Pad
1. Remove the headrest.
2. Remove the retainer under the back of seatback.
3. Remove the clips, and then remove the striker cover.
PIIB2915J
PIIB6507E
PIIB2486J
PIIB2485J
Revision: May 2010 2011 Versa
