Page 721 of 3787

NISSAN TIIDA 2011 Service Repair Manual TRUNK LID OPENERBL-211
< SERVICE INFORMATION >
C
DE
F
G H
J
K L
M A
B
BL
N
O P
1. Disconnect front door lock asse mbly RH (door unlock sensor)
connector.
2. Check continuity between trunk lid opener s

Page 722 of 3787

NISSAN TIIDA 2011 Service Repair Manual BL-212
< SERVICE INFORMATION >
TRUNK LID OPENER
1. Connect BCM connector.
2. Check voltage between BCM connector and ground.
OK or NG
OK >> Check the condition of harness and connector.
NG >> Replace

Page 723 of 3787

NISSAN TIIDA 2011 Service Repair Manual TRUNK LID OPENERBL-213
< SERVICE INFORMATION >
C
DE
F
G H
J
K L
M A
B
BL
N
O P
OK or NG
OK >> GO TO 3
NG >> Repair or replace harness.
3.CHECK TRUNK LID OPENER SWITCH
Check continuity between trunk l

Page 724 of 3787

NISSAN TIIDA 2011 Service Repair Manual BL-214
< SERVICE INFORMATION >
TRUNK LID OPENER
1. Disconnect Intelligent Key unit connector M52 and BCM con-nector M18.
2. Check continuity between Intelligent Key unit connector (A) M52
terminal 23

Page 725 of 3787

NISSAN TIIDA 2011 Service Repair Manual TRUNK LID OPENERBL-215
< SERVICE INFORMATION >
C
DE
F
G H
J
K L
M A
B
BL
N
O P
3.CHECK TRUNK LAMP SWITCH AND TRUNK RELEASE SOLENOID GROUND CIRCUIT
Check continuity between trunk lamp switch and trunk

Page 726 of 3787

NISSAN TIIDA 2011 Service Repair Manual BL-216
< SERVICE INFORMATION >
FUEL FILLER LID OPENER
FUEL FILLER LID OPENER
Removal and Installation of Fuel Filler Lid OpenerINFOID:0000000005929410
REMOVAL
1. Remove trunk side finisher (RH). Refer

Page 727 of 3787

NISSAN TIIDA 2011 Service Repair Manual VEHICLE SECURITY (THEFT WARNING) SYSTEMBL-217
< SERVICE INFORMATION >
C
DE
F
G H
J
K L
M A
B
BL
N
O P
VEHICLE SECURITY (THE FT WARNING) SYSTEM
Component Parts and Harness Connector LocationINFOID:0000

Page 728 of 3787

NISSAN TIIDA 2011 Service Repair Manual BL-218
< SERVICE INFORMATION >
VEHICLE SECURITY (THEFT WARNING) SYSTEM
System Description
INFOID:0000000005929412
DESCRIPTION
Operation Flow
Setting the vehicle security system
Initial condition• Ig

BL-218
< SERVICE INFORMATION >
VEHICLE SECURITY (THEFT WARNING) SYSTEM
System Description
INFOID:0000000005929412
DESCRIPTION
Operation Flow
Setting the vehicle security system
Initial condition• Ignition switch is in OFF position.
Disarmed phase• When the vehicle is being driven or when any door or trunk (sedan) is open, the vehicle security system is
set in the disarmed phase on the assumption that the owner is inside or near the vehicle.
Pre-armed phase and armed phase• The vehicle security system turns into the "pre-armed" phase (security lamp illuminates) when the BCM receives LOCK signal from front door key cylinder switch, keyfob or Intelligent Key after all doors and trunk
(sedan) are closed.
• All doors and trunk (sedan) are closed after front doors are locked by key or door lock and unlock switch.
The security indicator lamp illuminates for 30 seconds. then, the system automatically shifts into the "armed"
phase.
Canceling the set vehicle security system
Armed phase is canceled when the driver unlocks the doors or the trunk (sedan) with the key, keyfob or Intelli-
gent Key.
Activating the alarm operation of the vehicle security system
Make sure the system is in the armed phase.
When one of the following operations is performed, the system sounds the horns and flashes the headlamps
for about 50 seconds.
1. Any door is opened before unlocking door with key, keyfob or Intelligent Key.
2. Door is unlocked without using key, keyfob or Intelligent Key.
3. Trunk (sedan) is opened without using the key, trunk lid opener switch, keyfob or Intelligent Key (sedan).
POWER SUPPLY AND GROUND
Power is supplied at all times• through 10A fuse [No.13, located in the fuse block (J/B)]
10. Trunk lamp switch and trunk release
solenoid B127
(sedan view with trunk open) 11. Trunk key cylinder switch B142
(sedan) 12. Main power window and door lock/
unlock switch D7, D8
Power window and door lock/unlock
switch RH D105
13. Horn E18, E20
PIIA1367E
Revision: May 2010 2011 Versa
