2. Remove the console mask. Refer to IP-11, "Component Parts".
3. Insert one end of the Tool (A) into one of the square holes inside the power socket.
4. Lift up the handle of the Tool until the other end of the Tool is inside the socket and snaps into the other square hole in the
power socket.
5. Pull the power socket straight out with the Tool.
6. Disconnect power socket connector.
Installation
Installation is in the reverse order of removal.
NOTE:
Make sure to align the tab with the square notched area during
installation. Tool number:
— (J-42059)
AWMIA1182GB
AWMIA1183GB
Revision: May 2010 2011 Versa
Page 3786 of 3787
WW-40
< SERVICE INFORMATION >
HORN
HORN
Wiring Diagram - HORN -INFOID:0000000005929252
Removal and InstallationINFOID:0000000005929253
REMOVAL
1. Remove the front grille. Refer to EI-23, "Removal and Installation".
ABLWA1011GB
Revision: May 2010 2011 Versa
Page 3787 of 3787
HORN
WW-41
< SERVICE INFORMATION >
C
D E
F
G H
I
J
L
M A
B
WW
N
O P
2. Disconnect the horn connector.
3. Remove the horn nut (A) and remove the horn (1).
INSTALLATION
Installation is in the reverse order of removal.
ALKIA1767ZZ
