Page 1225 of 3787
CVT-170
< SERVICE INFORMATION >[RE0F08B]
SECONDARY SPEED SENSOR
SECONDARY SPEED SENSOR
Exploded ViewINFOID:0000000005928971
Removal and InstallationINFOID:0000000005928972
REMOVAL
1. Disconnect the battery cable from the negative terminal.
2. Remove air duct (inlet) and air cleaner case. Refer to
EM-135, "
Component".
3. Disconnect secondary speed sensor connector.
4. Remove secondary speed sensor.
5. Remove O-ring from secondary speed sensor.
INSTALLATION
Note the following, and install in the reverse order of removal.
CAUTION:
• Never reuse O-ring.
• Apply CVT fluid to O-ring.
InspectionINFOID:0000000005928973
INSPECTION AFTER INSTALLATION
Check for CVT fluid leakage and check CVT fluid level. Refer to CVT-14, "Checking CVT Fluid".
1. Secondary speed sensor2. O-ring3. Transaxle assembly
: Apply CVT Fluid NS-2.
JSDIA0751GB
Revision: May 2010 2011 Versa
Page 1226 of 3787
AIR BREATHER HOSECVT-171
< SERVICE INFORMATION > [RE0F08B]
D
E
F
G H
I
J
K L
M A
B
CVT
N
O P
AIR BREATHER HOSE
Removal and InstallationINFOID:0000000005928974
REMOVAL
1. Remove air duct (front), air duct (inlet) and air cleaner case. Refer to EM-135.
2. Remove air breather hose.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
Make sure air breather hose is not collapsed or bl ocked due to folding or bending when installed.
NOTE:
• Install the air breather hose (1) to the air breather tube (2) so that the paint mark (A) faces upward. Also make sure the air breather
hose end is pushed up to the tube bend portion.
• When installing air breather hose (1) to air duct and air cleaner case, make sure to fully insert the hose clips.
1. Air cleaner case 2. Air duct 3. Clip
4. Air breather hose 5. Air breather tube 6. CVT
WCIA0612E
WCIA0613E
Revision: May 2010 2011 Versa
Page 1227 of 3787
CVT-172
< SERVICE INFORMATION >[RE0F08B]
OIL PAN
OIL PAN
Exploded ViewINFOID:0000000006413338
Removal and InstallationINFOID:0000000006413339
REMOVAL
1. Remove engine under cover.
2. Remove drain plug from oil pan and then drain the CVT fluid.
3. Remove oil pan bolts ( ), and then remove oil pan and oil pan
gasket.
• : Front
4. Remove magnets from oil pan.
INSTALLATION
Note the following, and install in the reverse order of removal.
CAUTION:
1. Transaxle assembly 2. Oil pan bolt 3. Drain plug
4. Drain plug gasket 5. Oil pan 6. Oil pan gasket
7. Magnet
AWDIA0875GB
AWDIA0876ZZ
Revision: May 2010 2011 Versa
Page 1228 of 3787
OIL PANCVT-173
< SERVICE INFORMATION > [RE0F08B]
D
E
F
G H
I
J
K L
M A
B
CVT
N
O P
• Never reuse oil pan gasket and drain plug gasket.
• Completely remove all moisture, oil and old gasket, etc. from the oil pan gasket mounting surface of
transaxle case and oil pan.
InspectionINFOID:0000000006413340
INSPECTION AFTER REMOVAL
Check oil pan for foreign material.
• If a large amount of worn material is found, clutch plate may be worn.
• If iron powder is found, bearings, gears, or clutch plates may be worn.
• If aluminum powder is found, bushing may be worn, or ch ips or burrs of aluminum casting parts may enter.
Check points where wear is found in all cases.
INSPECTION AFTER INSTALLATION
Check for CVT fluid leakage and check CVT fluid level. Refer to CVT-14, "Checking CVT Fluid".
Revision: May 2010 2011 Versa
Page 1229 of 3787
CVT-174
< SERVICE INFORMATION >[RE0F08B]
DIFFERENTIAL SIDE OIL SEAL
DIFFERENTIAL SIDE OIL SEAL
Removal and InstallationINFOID:0000000005928975
COMPONENTS
REMOVAL
1. Remove drive shaft assembly. Refer to
FAX-9.
2. Remove differential side oil seal using a suitable tool. CAUTION:
Do not scratch transaxle case or converter housing.
INSTALLATION
1. Drive the new differential side oil seal into the transaxle caseside (B) and converter housing side (C) until it is flush using
Tool.
Unit: mm (in)
CAUTION:
• Do not reuse differential side oil seals.
• Apply specified NISSAN CVT fluid to side oil seals.
2. Install drive shaft assembly. Refer to FA X - 9
.
3. Check CVT fluid level and leakage. Refer to CVT-14, "
Checking CVT Fluid".
1. CVT2. Differential side oil seal : Apply CVT Fluid NS-2.
WCIA0610E
SCIA2412E
Tool number : — (J-47244)
: ST33400001 (J-47005)
Dimensions (A) 0±0.5 (0 ±0.020)
WCIA0611E
Revision: May 2010 2011 Versa
Page 1230 of 3787
![NISSAN TIIDA 2011 Service Repair Manual CVT OIL WARMER SYSTEMCVT-175
< SERVICE INFORMATION > [RE0F08B]
D
E
F
G H
I
J
K L
M A
B
CVT
N
O P
CVT OIL WARMER SYSTEM
WATER HOSE
WATER HOSE : Exploded ViewINFOID:0000000006068646
WATER HOSE : Removal NISSAN TIIDA 2011 Service Repair Manual CVT OIL WARMER SYSTEMCVT-175
< SERVICE INFORMATION > [RE0F08B]
D
E
F
G H
I
J
K L
M A
B
CVT
N
O P
CVT OIL WARMER SYSTEM
WATER HOSE
WATER HOSE : Exploded ViewINFOID:0000000006068646
WATER HOSE : Removal](/manual-img/5/57396/w960_57396-1229.png)
CVT OIL WARMER SYSTEMCVT-175
< SERVICE INFORMATION > [RE0F08B]
D
E
F
G H
I
J
K L
M A
B
CVT
N
O P
CVT OIL WARMER SYSTEM
WATER HOSE
WATER HOSE : Exploded ViewINFOID:0000000006068646
WATER HOSE : Removal and InstallationINFOID:0000000006068647
REMOVAL
WARNING:
Never remove the radiator cap when the engine is hot. Serious burns could occur from high pressure
coolant escaping from the radiator.
CAUTION:
Perform this step engine is cold.
1. Remove air duct (inlet). Refer to EM-135, "
Component".
2. Remove hose clamps, and remove CVT water hose A.
3. Remove hose clamps, and remove CVT water hose B.
4. Remove hose clamps, and remove CVT water hose C.
5. Remove CVT water tube.
INSTALLATION
Installation is in the reverse order of removal.
1. Hose clamp 2. CVT water hose C3. CVT water tube
4. CVT water hose B 5. Transaxle assembly6. CVT oil warmer
7. CVT water hose A
A. Water pump B. Water inlet-outlet
Refer to GI-8, "
Component" for symbols in the figure.
JSDIA1290GB
Revision: May 2010 2011 Versa
Page 1231 of 3787
![NISSAN TIIDA 2011 Service Repair Manual CVT-176
< SERVICE INFORMATION >[RE0F08B]
CVT OIL WARMER SYSTEM
When installing water hoses, install them according to the following:
• Insert CVT water hose according to dimension “A” described
NISSAN TIIDA 2011 Service Repair Manual CVT-176
< SERVICE INFORMATION >[RE0F08B]
CVT OIL WARMER SYSTEM
When installing water hoses, install them according to the following:
• Insert CVT water hose according to dimension “A” described](/manual-img/5/57396/w960_57396-1230.png)
CVT-176
< SERVICE INFORMATION >[RE0F08B]
CVT OIL WARMER SYSTEM
When installing water hoses, install them according to the following:
• Insert CVT water hose according to dimension “A” described
below.
• Set hose clamps (1) at the both ends of fluid cooler hose (2) with dimension (A) from the hose edge.
• Hose clamp should not interfere with the bulge.
*: Refer to the illustrations for the specific position of each hose clamp tab.
• The illustrations indicate the view from the hose ends.
• When installing hose clamps the center line of each clamp tab should be positioned as shown.
WATER HOSE : InspectionINFOID:0000000006068648
INSPECTION AFTER INSTALLATION
Start and warm up the engine. Visually check that there is no leakage of engine coolant and CVT fluid.
CVT FLUID COOLER HOSE
CVT water hose (1) Insert side tube (2) Dimension “A”
CVT water hose A Water inlet-outlet
End reaches the spool portion (B)
CVT oil warmer
CVT water hose B CVT oil warmer
CVT water tube
CVT water hose C CVT water tube
Water pump
JSDIA1291ZZ
Dimension (A) : 5 – 7 mm (0.20 – 0.28 in)
SCIA8123E
CVT water hose
Hose end Paint mark
Position of hose clamp*
CVT water hose A Water inlet-outlet side Facing forward A
CVT oil warmer side
Facing forward A
CVT water hose B CVT oil warmer side
Facing to the right of the vehicle B
CVT water tube side Facing forward A
CVT water hose C CVT water tube side
Facing forward A
Water pump side Facing upward C
D: Vehicle front
E : Vehicle upper
JSDIA1292ZZ
Revision: May 2010
2011 Versa
Page 1232 of 3787
CVT OIL WARMER SYSTEMCVT-177
< SERVICE INFORMATION > [RE0F08B]
D
E
F
G H
I
J
K L
M A
B
CVT
N
O P
CVT FLUID COOLER HO SE : Exploded ViewINFOID:0000000006068649
COMPONENT PARTS LOCATION
CVT FLUID COOLER HOSE : Removal and InstallationINFOID:0000000006068650
REMOVAL
1. Remove air duct (inlet). Refer to EM-135, "Component".
2. Remove hose clamps, and remove CVT fluid cooler hose A.
3. Remove hose clamps, and remove CVT fluid cooler hose B.
4. Remove CVT fluid cooler tube A and CVT fluid cooler tube B.
INSTALLATION
Installation is in the reverse order of removal.
1. CVT fluid cooler hose A 2. Hose clamp3. CVT fluid cooler tube A
4. Gasket 5. Transaxle assembly6. CVT fluid cooler tube B
7. CVT fluid cooler hose B 8. CVT oil warmer
Refer to GI-8, "
Component" for symbols in the figure.
JSDIA1288GB
Revision: May 2010 2011 Versa
