Page 945 of 2255

DODGE RAM 2002 Service Repair Manual C126 (DIESEL) - GRAY (ENGINE SIDE) CAV CIRCUIT 1 K20 18DG 2 V37 18RD/LG (M/T) 3 T125 18DB 4 D20 18DG 5 D21 18PK/DB 6 D1 18VT/BR 7 D2 18WT/BK 8 G85 18OR/BK 9 C22 18DB 10 K24 18GY/BK 11 V32 18YL/BK 12 Z

Page 946 of 2255

DODGE RAM 2002 Service Repair Manual C129 - (CHASSIS HARNESS SIDE) CAV CIRCUIT 11 L1 18VT/BK 12 A6 12RD/OR 13 L62 16BR/RD 14 A61 16DG/BK C129 - (HEADLAMP AND DASH SIDE) CAV CIRCUIT 1 B113 20RD/VT 2 B114 20WT/VT 3 Z13 12BK 4 B40 12LB 5 K4

Page 947 of 2255

DODGE RAM 2002 Service Repair Manual C130 (DIESEL) - (TRANSMISSION SIDE) CAV CIRCUIT 23 K226 18DB/WT 24 V36 18TN/RD 26 T41 20BK/WT (A/T) 26 Z12 18BK/TN (M/T) 27 - 28 F18 18LG/BK 29 K30 18PK (A/T) 30 K4 18BK/LB (A/T) 30 K104 18BK/LB (M/T)

Page 948 of 2255

DODGE RAM 2002 Service Repair Manual C130 (DIESEL) (IN PDC) - (HEADLAMP AND DASH SIDE) CAV CIRCUIT 27 - 28 F18 20LG/BK 29 K30 22PK 30 A341 20DG/YL 31 T16 18RD 32 D220 20WT/VT 33 G7 20WT/OR 34 T6 22OR/WT 35 T125 18DB 36 S21 18YL/BK 37 S22

Page 949 of 2255

DODGE RAM 2002 Service Repair Manual C130 (GAS) - (ENGINE HARNESS SIDE) CAV CIRCUIT 31 T16 18RD(A/T) 32 - 33 G7 18WT/OR 34 T6 18OR/WT(A/T) 35 T125 18DB(A/T) 36 Y193 18WT/LG 37 T41 20BK/WT 37 Z11 20BK/WT(M/T) 38 K31 18BR/WT 39 F18 18LG/BK

Page 950 of 2255

DODGE RAM 2002 Service Repair Manual C130 (GAS) (IN PDC) - (HEADLAMP AND DASH SIDE) CAV CIRCUIT 33 G7 20WT/OR 34 T6 22OR/WT (A/T) 35 T125 18DB (A/T) 36 Y193 18WT/LG 37 T41 22BK/WT 38 K31 20BR/WT 39 F18 20LG/BK 40 C3 22DB/BK 41 V37 22RD/L

Page 951 of 2255

DODGE RAM 2002 Service Repair Manual C134 - BLACK (HEADLAMP AND DASH SIDE) CAV CIRCUIT 35 D1 20VT/BR 36 D2 20WT/BK 37 - 38 - 39 F12 20DB/WT 40 G107 20GY 41 - 42 L50 18WT/TN 42 L50 18WT/TN 43 G85 22OR/BK(DIESEL) 44 - 45 L63 16DG/RD 46 L62

Page 952 of 2255

DODGE RAM 2002 Service Repair Manual C134 - BLACK (I/P HARNESS SIDE) CAV CIRCUIT 1- 2 V10 16BR 3 G34 16RD/GY 4- 5 Z3 18BK/OR 6 G29 22BK/WT 7- 8 L10 18BR/LG 9- 10 A2 14PK/BK 11 C1 12DG 12 - 13 A1 10RD 14 V5 16DG 15 V49 16RD/BK 16 L4 18VT/
