DODGE RAM 2002 Service Repair Manual 8W-80 CONNECTOR PIN-OUTS
Component Page
4WD Switch........................ 8W-80-4
A/C Compressor Clutch................ 8W-80-4
A/C Heater Control................... 8W-80-4
A/C Heater Temperature Se

8W-80 CONNECTOR PIN-OUTS
Component Page
4WD Switch........................ 8W-80-4
A/C Compressor Clutch................ 8W-80-4
A/C Heater Control................... 8W-80-4
A/C Heater Temperature Select......... 8W-80-4
A/C High Pressure Switch............. 8W-80-4
A/C Low Pressure Switch.............. 8W-80-5
Accelerator Pedal Position Sensor
(Diesel).......................... 8W-80-5
Aftermarket Trailer Tow Connector...... 8W-80-5
Airbag Control Module................ 8W-80-5
Ambient Temperature Sensor........... 8W-80-6
Ash Receiver Lamp................... 8W-80-6
Automatic Day/Night Mirror............ 8W-80-6
Back-Up Lamp Switch (M/T)........... 8W-80-6
Battery Temperature Sensor............ 8W-80-7
Blend Door Actuator.................. 8W-80-7
Blower Motor....................... 8W-80-7
Blower Motor Resistor Block............ 8W-80-7
Brake Lamp Switch.................. 8W-80-7
Brake Pressure Switch................ 8W-80-8
Bypass Jumper (A/T)................. 8W-80-8
C105.............................. 8W-80-8
C105.............................. 8W-80-8
C106.............................. 8W-80-8
C106.............................. 8W-80-8
C114 .............................. 8W-80-9
C114 .............................. 8W-80-9
C125 (Diesel)....................... 8W-80-9
C125 (Diesel)....................... 8W-80-9
C126 (Diesel)....................... 8W-80-10
C126 (Diesel)....................... 8W-80-10
C129............................. 8W-80-10
C129............................. 8W-80-11
C130 (Diesel)....................... 8W-80-11
C130 (Diesel) (In PDC)............... 8W-80-12
C130 (Gas)........................ 8W-80-13
C130 (Gas) (In PDC)................. 8W-80-14
C134............................. 8W-80-15
C134............................. 8W-80-17
C203............................. 8W-80-18
C203............................. 8W-80-19
C205............................. 8W-80-20
C205............................. 8W-80-20
C206 (Heated Seats)................. 8W-80-20
C206 (Heated Seats)................. 8W-80-21
C237............................. 8W-80-21
C237............................. 8W-80-21
C303............................. 8W-80-22
C303............................. 8W-80-22
C308............................. 8W-80-22
C308............................. 8W-80-22
C329 (Club Cab).................... 8W-80-22Component Page
C329 (Club Cab).................... 8W-80-23
C329 (Standard Cab)................ 8W-80-23
C329 (Standard Cab)................ 8W-80-23
C333 (Club Cab).................... 8W-80-23
C333 (Club Cab).................... 8W-80-23
C333 (Standard Cab)................ 8W-80-24
C333 (Standard Cab)................ 8W-80-24
C342............................. 8W-80-24
C342............................. 8W-80-24
C343............................. 8W-80-24
C343............................. 8W-80-24
C344 (Dual Rear Wheels)............. 8W-80-25
C344 (Dual Rear Wheels)............. 8W-80-25
C345............................. 8W-80-25
C345............................. 8W-80-25
C346............................. 8W-80-26
C346............................. 8W-80-26
C347............................. 8W-80-26
C347............................. 8W-80-27
C348............................. 8W-80-27
C348............................. 8W-80-28
C352............................. 8W-80-28
C352............................. 8W-80-28
C353............................. 8W-80-28
C353............................. 8W-80-28
C358............................. 8W-80-29
C358............................. 8W-80-29
C359 (Heated Seat).................. 8W-80-29
C359 (Heated Seat).................. 8W-80-29
C360 (Club Cab).................... 8W-80-30
C360 (Club Cab).................... 8W-80-30
C361............................. 8W-80-30
C361............................. 8W-80-30
C364............................. 8W-80-31
C364............................. 8W-80-31
C365 (Heated Seat).................. 8W-80-31
C365 (Heated Seat).................. 8W-80-31
Camshaft Position Sensor (8.0L Gas).... 8W-80-32
Camshaft Position Sensor (Diesel)...... 8W-80-32
Camshaft Position Sensor
(Gas Except 8.0L)................. 8W-80-32
Cargo Lamp No. 1................... 8W-80-32
Cargo Lamp No. 2................... 8W-80-32
Center High Mounted Stop Lamp No. 1 . . 8W-80-33
Center High Mounted Stop Lamp No. 2 . . 8W-80-33
Center Identification Lamp............ 8W-80-33
Central Timer Module C1............. 8W-80-33
Central Timer Module C2............. 8W-80-34
Cigar Lighter...................... 8W-80-34
Clockspring C1..................... 8W-80-34
Clockspring C2..................... 8W-80-34
Clockspring C3..................... 8W-80-35
BR/BE8W-80 CONNECTOR PIN-OUTS 8W - 80 - 1
