Page 937 of 2255

DODGE RAM 2002 Service Repair Manual Component Page
Clutch Pedal Position Switch (M/T)..... 8W-80-35
Controller Antilock Brake C1.......... 8W-80-35
Controller Antilock Brake C2 (ABS)..... 8W-80-35
Crankshaft Position Sensor (Gas 8.0L) .

Component Page
Clutch Pedal Position Switch (M/T)..... 8W-80-35
Controller Antilock Brake C1.......... 8W-80-35
Controller Antilock Brake C2 (ABS)..... 8W-80-35
Crankshaft Position Sensor (Gas 8.0L) . . . 8W-80-36
Crankshaft Position Sensor
(Gas Except 8.0L)................. 8W-80-36
Cummins Bus (Diesel)............... 8W-80-36
Cup Holder Lamp................... 8W-80-36
Data Link Connector................. 8W-80-36
Daytime Running Lamp Module........ 8W-80-37
Dome Lamp....................... 8W-80-37
Driver Airbag...................... 8W-80-37
Driver Cylinder Lock Switch........... 8W-80-37
Driver Door Ajar Switch (Base)......... 8W-80-38
Driver Door Ajar Switch (Premium)..... 8W-80-38
Driver Door Lock Motor.............. 8W-80-38
Driver Door Window/Lock Switch....... 8W-80-38
Driver Heated Seat Cushion........... 8W-80-38
Driver Heated Seat Switch............ 8W-80-39
Driver Lumbar Motor................ 8W-80-39
Driver Power Seat Front Vertical Motor
(Club Cab)....................... 8W-80-39
Driver Power Seat Front Vertical Motor
(Standard Cab)................... 8W-80-39
Driver Power Seat Horizontal Motor
(Club Cab)....................... 8W-80-39
Driver Power Seat Horizontal Motor
(Standard Cab)................... 8W-80-40
Driver Power Seat Rear Vertical Motor
(Club Cab)....................... 8W-80-40
Driver Power Seat Rear Vertical Motor
(Standard Cab)................... 8W-80-40
Driver Power Seat Switch (Club Cab).... 8W-80-40
Driver Power Seat Switch
(Standard Cab)................... 8W-80-41
Driver Power Window Motor........... 8W-80-41
Electric Brake Provision.............. 8W-80-41
Engine Control Module (Diesel)........ 8W-80-41
Engine Coolant Temperature Sensor
(Diesel)......................... 8W-80-42
Engine Coolant Temperature Sensor
(Gas)........................... 8W-80-43
Engine Oil Pressure Sensor (Diesel)..... 8W-80-43
Engine Oil Pressure Sensor (Gas)....... 8W-80-43
EVAP/Purge Solenoid................ 8W-80-43
Front Washer Pump................. 8W-80-43
Fuel Heater (Diesel)................. 8W-80-43
Fuel Injection Pump (Diesel)........... 8W-80-44
Fuel Injector No. 1.................. 8W-80-44
Fuel Injector No. 2.................. 8W-80-44
Fuel Injector No. 3.................. 8W-80-44
Fuel Injector No. 4.................. 8W-80-44
Fuel Injector No. 5.................. 8W-80-45
Fuel Injector No. 6.................. 8W-80-45
Fuel Injector No. 7 (5.2L/5.9L/8.0L)..... 8W-80-45Component Page
Fuel Injector No. 8 (5.2L/5.9L/8.0L)..... 8W-80-45
Fuel Injector No. 9 (8.0L)............. 8W-80-45
Fuel Injector No. 10 (8.0L)............ 8W-80-46
Fuel Pump Module (Gas)............. 8W-80-46
Fuel Tank Module (Diesel)............ 8W-80-46
Fuel Transfer Pump (Diesel)........... 8W-80-46
G300............................. 8W-80-46
Generator......................... 8W-80-47
Glove Box Lamp And Switch........... 8W-80-47
Headlamp Switch C1................ 8W-80-47
Headlamp Switch C2................ 8W-80-47
Heated Mirror Switch................ 8W-80-48
High Note Horn.................... 8W-80-48
Idle Air Control Motor................ 8W-80-48
Ignition Coil (3.9L/5.2L/5.9L).......... 8W-80-48
Ignition Coil 4 Pack (8.0L)............ 8W-80-48
Ignition Coil 6 Pack (8.0L)............ 8W-80-49
Ignition Switch C1.................. 8W-80-49
Ignition Switch C2.................. 8W-80-49
Instrument Cluster C1............... 8W-80-49
Instrument Cluster C2............... 8W-80-50
Intake Air Heater Relays (Diesel)....... 8W-80-50
Intake Air Temperature Sensor (Diesel) . . 8W-80-50
Intake Air Temperature Sensor (Gas).... 8W-80-50
Joint Connector No. 1 (In PDC)........ 8W-80-50
Joint Connector No. 2 (In PDC)........ 8W-80-51
Joint Connector No. 5................ 8W-80-52
Joint Connector No. 6................ 8W-80-52
Joint Connector No. 7................ 8W-80-53
Joint Connector No. 8................ 8W-80-53
Junction Block C1................... 8W-80-54
Junction Block C2................... 8W-80-54
Junction Block C3................... 8W-80-54
Junction Block C4................... 8W-80-55
Junction Block C5................... 8W-80-55
Junction Block C6................... 8W-80-55
Junction Block C7................... 8W-80-55
Junction Block C8................... 8W-80-56
Junction Block C9................... 8W-80-56
Leak Detection Pump (Gas)........... 8W-80-56
Left Back-Up Lamp.................. 8W-80-57
Left Fog Lamp..................... 8W-80-57
Left Front Door Speaker (Premium)..... 8W-80-57
Left Front Door Speaker (Standard)..... 8W-80-57
Left Front Fender Lamp
(Dual Rear Wheels)................ 8W-80-57
Left Front Wheel Speed Sensor (ABS) . . . 8W-80-58
Left Headlamp..................... 8W-80-58
Left License Lamp.................. 8W-80-58
Left Outboard Clearance Lamp......... 8W-80-58
Left Outboard Headlamp............. 8W-80-58
Left Outboard Identification Lamp...... 8W-80-59
Left Park/Turn Signal Lamp........... 8W-80-59
Left Power Mirror................... 8W-80-59
8W - 80 - 2 8W-80 CONNECTOR PIN-OUTSBR/BE

Page 938 of 2255

DODGE RAM 2002 Service Repair Manual Component Page
Left Rear Fender Lamp
(Dual Rear Wheels)................ 8W-80-59
Left Rear Speaker (Premium 2 Door).... 8W-80-59
Left Rear Speaker (Premium 4 Door).... 8W-80-60
Left Rear Speaker (Stan

Component Page
Left Rear Fender Lamp
(Dual Rear Wheels)................ 8W-80-59
Left Rear Speaker (Premium 2 Door).... 8W-80-59
Left Rear Speaker (Premium 4 Door).... 8W-80-60
Left Rear Speaker (Standard 2 Door).... 8W-80-60
Left Rear Speaker (Standard 4 Door).... 8W-80-60
Left Remote Radio Switch............. 8W-80-60
Left Speed Control Switch............ 8W-80-60
Left Tail/Stop/Turn Signal Lamp........ 8W-80-61
Left Tweeter (Premium).............. 8W-80-61
Left Visor/Vanity Lamp............... 8W-80-61
Low Note Horn..................... 8W-80-61
Manifold Absolute Pressure Sensor
(3.9L/5.2L/5.9L)................... 8W-80-61
Manifold Absolute Pressure Sensor
(8.0L).......................... 8W-80-62
Manifold Air Pressure Sensor (Diesel).... 8W-80-62
Multi-Function Switch............... 8W-80-62
Output Speed Sensor................ 8W-80-63
Overdrive Switch................... 8W-80-63
Overhead Console (Base).............. 8W-80-63
Overhead Console (Highline)........... 8W-80-63
Oxygen Sensor 1/1 Left Bank Up
(5.9L HD/8.0L)................... 8W-80-63
Oxygen Sensor 1/1 Left Bank Up
(California)...................... 8W-80-64
Oxygen Sensor 1/1 Upstream
(A/T Except 8.0L)................. 8W-80-64
Oxygen Sensor 1/1 Upstream
(M/T Except 8.0L)................. 8W-80-64
Oxygen Sensor 1/2 Downstream
(3.9L/5.2L)....................... 8W-80-64
Oxygen Sensor 1/2 Left Bank Down
(California)...................... 8W-80-64
Oxygen Sensor 1/2 Pre-Catalyst (8.0L) . . . 8W-80-65
Oxygen Sensor 1/3 Post Catalyst (8.0L) . . 8W-80-65
Oxygen Sensor 2/1 Right Bank Up (5.9l HD)
(5.2L/5.9L/8.0L California).......... 8W-80-65
Oxygen Sensor 2/2 Right Bank Down
(California)...................... 8W-80-65
Park/Neutral Position Switch (A/T)...... 8W-80-65
Passenger Airbag................... 8W-80-66
Passenger Airbag On/Off Switch C1..... 8W-80-66
Passenger Airbag On/Off Switch C2..... 8W-80-66
Passenger Cylinder Lock Switch........ 8W-80-66
Passenger Door Ajar Switch........... 8W-80-66
Passenger Door Lock Motor........... 8W-80-66
Passenger Door Window/Lock Switch.... 8W-80-67
Passenger Heated Seat Cushion........ 8W-80-67
Passenger Heated Seat Switch......... 8W-80-67
Passenger Lumbar Motor............. 8W-80-67
Passenger Power Seat Front Vertical Motor
(Club Cab)....................... 8W-80-68
Passenger Power Seat Horizontal Motor
(Club Cab)....................... 8W-80-68Component Page
Passenger Power Seat Rear Vertical Motor
(Club Cab)....................... 8W-80-68
Passenger Power Seat Switch (Club Cab) . 8W-80-68
Passenger Power Window Motor........ 8W-80-68
Power Mirror Switch................. 8W-80-69
Power Outlet....................... 8W-80-69
Powertrain Control Module C1 (Diesel) . . . 8W-80-69
Powertrain Control Module C1 (Gas).... 8W-80-70
Powertrain Control Module C2 (Diesel) . . . 8W-80-71
Powertrain Control Module C2 (Gas).... 8W-80-71
Powertrain Control Module C3 (Diesel) . . . 8W-80-72
Powertrain Control Module C3 (Gas).... 8W-80-73
Radio C1.......................... 8W-80-74
Radio C2.......................... 8W-80-74
Radio C3.......................... 8W-80-74
Radio Choke Relay.................. 8W-80-74
Rear Wheel Speed Sensor (ABS)........ 8W-80-74
Right Back-Up Lamp................ 8W-80-75
Right Fog Lamp.................... 8W-80-75
Right Front Door Speaker (Premium).... 8W-80-75
Right Front Door Speaker (Standard).... 8W-80-75
Right Front Fender Lamp
(Dual Rear Wheels)................ 8W-80-75
Right Front Wheel Speed Sensor (ABS) . . 8W-80-76
Right Headlamp.................... 8W-80-76
Right License Lamp................. 8W-80-76
Right Outboard Clearance Lamp....... 8W-80-76
Right Outboard Headlamp............ 8W-80-76
Right Outboard Identification Lamp..... 8W-80-77
Right Park/Turn Signal Lamp.......... 8W-80-77
Right Power Mirror.................. 8W-80-77
Right Rear Fender Lamp
(Dual Rear Wheels)................ 8W-80-77
Right Rear Speaker (2 Door Premium) . . . 8W-80-77
Right Rear Speaker (4 Door Premium) . . . 8W-80-78
Right Rear Speaker (Standard 2 Door) . . . 8W-80-78
Right Rear Speaker (Standard 4 Door) . . . 8W-80-78
Right Remote Radio Switch........... 8W-80-78
Right Speed Control Switch........... 8W-80-78
Right Tail/Stop/Turn Signal Lamp...... 8W-80-78
Right Tweeter (Premium)............. 8W-80-79
Right Visor/Vanity Lamp.............. 8W-80-79
Seat Belt Switch (Club Cab)........... 8W-80-79
Seat Belt Switch (Standard Cab)....... 8W-80-79
Seat Heat Interface Module........... 8W-80-79
Speed Control Servo................. 8W-80-80
Tailgate Lamp (Dual Rear Wheels)...... 8W-80-80
Throttle Position Sensor (Gas)......... 8W-80-80
Trailer Tow Connector................ 8W-80-80
Transmission Solenoid Assembly........ 8W-80-80
Underhood Lamp................... 8W-80-81
Washer Fluid Level Switch............ 8W-80-81
Water In Fuel Sensor (Diesel).......... 8W-80-81
Wiper Motor....................... 8W-80-81
BR/BE8W-80 CONNECTOR PIN-OUTS 8W - 80 - 3

Page 939 of 2255

DODGE RAM 2002 Service Repair Manual 4WD SWITCH - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 G107 18BK/GY 4WD SWITCH SENSE
2 Z1 18BK GROUND
A/C COMPRESSOR CLUTCH - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 C3 18DB/BK A/C COMPRESSOR CLUTCH RELAY OUTPUT

Page 940 of 2255

DODGE RAM 2002 Service Repair Manual A/C LOW PRESSURE SWITCH-2WAY
CAV CIRCUIT FUNCTION
1 C20 18BR A/C SWITCH SENSE
2 C22 18DB A/C SWITCH SENSE
ACCELERATOR PEDAL POSITION SENSOR (DIESEL)-6WAY
CAV CIRCUIT FUNCTION
1 K104 18BK/LB SENSOR GRO

Page 941 of 2255

DODGE RAM 2002 Service Repair Manual AIRBAG CONTROL MODULE - 23 WAY
CAV CIRCUIT FUNCTION
17 - -
18 - -
19 - -
20 - -
21 D1 18VT/BR CCD BUS (+)
22 D2 18WT/BK CCD BUS (-)
23 - -
AMBIENT TEMPERATURE SENSOR-2WAY
CAV CIRCUIT FUNCTION
1 G31 20

Page 942 of 2255

DODGE RAM 2002 Service Repair Manual BATTERY TEMPERATURE SENSOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K4 20BK/LB SENSOR GROUND
2 K118 20PK/YL BATTERY TEMPERATURE SENSOR SIGNAL
BLEND DOOR ACTUATOR-6WAY
CAV CIRCUIT FUNCTION
1 F15 20DB FUSED

Page 943 of 2255

DODGE RAM 2002 Service Repair Manual BRAKE PRESSURE SWITCH - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Z1 20BK GROUND
2 G9 20GY/BK RED BRAKE WARNING INDICATOR DRIVER
BYPASS JUMPER (A/T) - GREEN 2 WAY
CAV CIRCUIT FUNCTION
1 T141 14YL/RD FUSED IG

Page 944 of 2255

DODGE RAM 2002 Service Repair Manual C114 - BLACK (AMBIENT TEMPERATURE SEN-
SOR SIDE)
CAV CIRCUIT
1 G31 20VT/LG
2 G32 20BK/VT
C114 - BLACK (HEADLAMP AND DASH SIDE)
CAV CIRCUIT
1 G31 20VT/LG
2 G32 20BK/VT
C125 (DIESEL) - (ENGINE SIDE)
CAV

Load next 8 pages

Page: < prev 1-10 ... 905-912 913-920 921-928 929-936 937-944 945-952 953-960 961-968 969-976 ... 2256 next >

air filter headlight bulb overheating oil type seats fuel pressure
