Page 1121 of 2399

CHRYSLER CARAVAN 2002 Service Manual PASSENGER POWER SEAT HORIZONTAL MOTOR - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 P14 14LG/OR PASSENGER HORIZONTAL FORWARD SWITCH SENSE 2 P16 14LG/WT PASSENGER HORIZONTAL REARWARD SWITCH SENSE PASSENGER POWE

Page 1122 of 2399

CHRYSLER CARAVAN 2002 Service Manual PASSENGER POWER WINDOW SWITCH - BLACK 8 WAY CAV CIRCUIT FUNCTION 1 F304 12WT/PK (EXCEPT BUILT-UP-EXPORT RHD)FUSED WINDOW CIRCUIT BREAKER OUTPUT 1 F304 16WT/PK (BUILT-UP-EXPORT LHD)FUSED WINDOW CIRCUIT

Page 1123 of 2399

CHRYSLER CARAVAN 2002 Service Manual POWER LIFTGATE MODULE C1 - BLACK 8 WAY CAV CIRCUIT FUNCTION 1 Q83 18OR/GY LIFTGATE LATCH CLUTCH DRIVER 2 Q88 16TN/BR (EXCEPT BUILT-UP-EXPORT)LIFTGATE OPEN DRIVER 2 Q88 14TN/BR (BUILT-UP-EXPORT) LIFTGA

Page 1124 of 2399

CHRYSLER CARAVAN 2002 Service Manual POWER MIRROR SWITCH - BLACK 13 WAY CAV CIRCUIT FUNCTION 1 P70 18TN/LB (MEMORY) RIGHT MIRROR COMMON DRIVER (RIGHT/DOWN) 1 P70 20TN/LB RIGHT MIRROR COMMON DRIVER (RIGHT/DOWN) 2- - 3- - 4- - 5 E18 20OR/L

Page 1125 of 2399

CHRYSLER CARAVAN 2002 Service Manual POWER WINDOW SWITCH (LOWLINE) - BLACK 8 WAY CAV CIRCUIT FUNCTION 1 F304 16WT/PK FUSED WINDOW CIRCUIT BREAKER OUTPUT 2 Z421 12BK/BR GROUND 3 Z421 12BK/BR GROUND 4- - 5 Q26 12OR/GY MASTER WINDOW SWITCH

Page 1126 of 2399

CHRYSLER CARAVAN 2002 Service Manual POWERTRAIN CONTROL MODULE C2 (GAS) - GRAY/GRAY 40 WAY CAV CIRCUIT FUNCTION 41 V37 18VT SPEED CONTROL SWITCH SIGNAL 42 C18 18LB/BR A/C PRESSURE SENSOR SIGNAL 43 K900 18DB/DG SENSOR GROUND 44 F888 18BR/

Page 1127 of 2399

CHRYSLER CARAVAN 2002 Service Manual RADIATOR FAN NO. 1 (DIESEL) - GRAY 2 WAY CAV CIRCUIT FUNCTION 1 N202 12DB/OR RADIATOR FAN NO. 1 CONTROL 2 N201 12DB/LG RADIATOR FAN RELAY NO. 1 OUTPUT RADIATOR FAN NO. 1 (GAS) - BLACK 2 WAY CAV CIRCUI

Page 1128 of 2399

CHRYSLER CARAVAN 2002 Service Manual RADIATOR FAN RELAY NO. 1 (DIESEL) - BLUE 9 WAY CAV CIRCUIT FUNCTION 1- - 2 N201 12DB/LG RADIATOR FAN RELAY NO. 1 OUTPUT 3- - 4 K342 16BR/WT ECM/PCM RELAY OUTPUT 5- - 6 N210 18DB/DG LOW SPEED RADIATOR
