Page 1073 of 2399

CHRYSLER CARAVAN 2002 Service Manual C331 (DIESEL) - BLACK (CABIN HEATER JUMPER SIDE) CAV CIRCUIT 1 A119 16RD/OR 2 C41 20LB/DG 3 D21 20WT/BR 4 Z149 16BK/DB C331 (DIESEL) - GRAY (CABIN HEATER COMPONENT SIDE) CAV CIRCUIT 1 A119 14RD/OR 2 C

Page 1074 of 2399

CHRYSLER CARAVAN 2002 Service Manual CABIN HEATER ASSIST C2 (DIESEL) - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 A119 14RD/OR FUSED B(+) 2 Z149 14BK/DB GROUND CAMSHAFT POSITION SENSOR (DIESEL) - BLACK 3 WAY CAV CIRCUIT FUNCTION 1 K944 20BK/GY C

Page 1075 of 2399

CHRYSLER CARAVAN 2002 Service Manual CENTER HIGH MOUNTED STOP LAMP - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 Z350 20BK/TN GROUND 2 L50 18WT/TN BRAKE LAMP SWITCH OUTPUT CLOCKSPRING C1 - WHITE 6 WAY CAV CIRCUIT FUNCTION 1 X920 20GY/OR RADIO CON

Page 1076 of 2399

CHRYSLER CARAVAN 2002 Service Manual CLOCKSPRING C5 - YELLOW 4 WAY CAV CIRCUIT FUNCTION 1 R45 18OR/LB DRIVER SQUIB 1 LINE 2 2 R43 18BK/LB DRIVER SQUIB 1 LINE 1 3 R63 18TN/LB DRIVER SQUIB 2 LINE 2 4 R61 18OR/LB DRIVER SQUIB 2 LINE 1 CLUTC

Page 1077 of 2399

CHRYSLER CARAVAN 2002 Service Manual CONTROLLER ANTILOCK BRAKE - BLACK 24 WAY CAV CIRCUIT FUNCTION 1 Z107 12BK/DG GROUND 2 B1 18DG/OR RIGHT REAR WHEEL SPEED SENSOR SIGNAL 3 B2 18DG/LB RIGHT REAR WHEEL SPEED SENSOR 12 VOLT SUPPLY 4- - 5 D

Page 1078 of 2399

CHRYSLER CARAVAN 2002 Service Manual CRANKSHAFT POSITION SENSOR (GAS) - BLACK 3 WAY CAV CIRCUIT FUNCTION 1 F888 18BR/PK 8 VOLT SUPPLY 2 K900 18DB/DG SENSOR GROUND 3 K24 18BR/LB CRANKSHAFT POSITION SENSOR SIGNAL DATA LINK CONNECTOR - BLAC

Page 1079 of 2399

CHRYSLER CARAVAN 2002 Service Manual DOSING PUMP (DIESEL) - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 18RD DOSING PUMP CONTROL 2 Z149 18BK/DB GROUND DRIVER AIRBAG C1 - BROWN 2 WAY CAV CIRCUIT FUNCTION 1 R43 18BK/LB DRIVER SQUIB 1 LINE 1 2 R45 1

Page 1080 of 2399

CHRYSLER CARAVAN 2002 Service Manual DRIVER DOOR COURTESY LAMP - GRAY 3 WAY CAV CIRCUIT FUNCTION 1 Z322 20BK/BR (RHD) GROUND 1 Z321 20BK/BR (LHD) GROUND 2- - 3 M21 20YL/BR COURTESY LAMPS DRIVER DRIVER DOOR LOCK SWITCH - BLACK 3 WAY CAV C
