Page 1089 of 2399

CHRYSLER CARAVAN 2002 Service Manual ENGINE COOLANT TEMP SENSOR (GAS) - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 K900 18DB/DG SENSOR GROUND 2 K2 18VT/OR ENGINE COOLANT TEMPERATURE SENSOR SIGNAL ENGINE OIL PRESSURE SENSOR (DIESEL) - BLACK 3 WAY

Page 1090 of 2399

CHRYSLER CARAVAN 2002 Service Manual EVAPORATOR TEMPERATURE SENSOR - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 C21 20DB/LG EVAPORATOR TEMPERATURE SENSOR SIGNAL 2 C121 20DB/DG SENSOR GROUND FLOOR CONSOLE LAMP - BLACK 2 WAY CAV CIRCUIT FUNCTION 1

Page 1091 of 2399

CHRYSLER CARAVAN 2002 Service Manual FRONT CIGAR LIGHTER - RED/NATURAL 3 WAY CAV CIRCUIT FUNCTION 1 F306 16DB/PK FUSED ACCESSORY RELAY OUTPUT 1 F306 16DB/PK FUSED ACCESSORY RELAY OUTPUT 2 E14 20OR/TN (BUILT-UP-EXPORT) PANEL LAMPS DRIVER

Page 1092 of 2399

CHRYSLER CARAVAN 2002 Service Manual FUEL INJECTOR NO. 1 (DIESEL) - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 K111 14DB/LB COMMON INJECTOR DRIVER 2 K11 14WT/DB FUEL INJECTOR NO. 1 CONTROL FUEL INJECTOR NO. 2 (2.4L/3.3L/3.8L) - BLACK 2 WAY CAV C

Page 1093 of 2399

CHRYSLER CARAVAN 2002 Service Manual FUEL INJECTOR NO. 4 (2.4L/3.3L/3.8L) - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 K342 16BR/WT AUTOMATIC SHUT DOWN RELAY OUTPUT 2 K14 16BR/TN FUEL INJECTOR NO. 4 DRIVER FUEL INJECTOR NO. 4 (DIESEL) - BLACK 2

Page 1094 of 2399

CHRYSLER CARAVAN 2002 Service Manual FUEL PRESSURE SOLENOID (DIESEL) - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 K342 16BR/WT ECM/PCM RELAY OUTPUT 2 K87 16BR FUEL PRESSURE SOLENOID CONTROL FUEL PUMP MODULE - LT. GRAY 4 WAY CAV CIRCUIT FUNCTION

Page 1095 of 2399

CHRYSLER CARAVAN 2002 Service Manual HEADLAMP SWITCH - BLACK 13 WAY CAV CIRCUIT FUNCTION 1 Z403 20BK/YL (BUILT-UP-EXPORT) GROUND 2 L78 20WT/OR (BUILT-UP-EXPORT) FUSED PARK LAMP RELAY OUTPUT 3- - 4 Z407 18BK/OR GROUND 5 L36 20WT/DB (BUILT

Page 1096 of 2399

CHRYSLER CARAVAN 2002 Service Manual IDLE AIR CONTROL MOTOR (3.3L/3.8L) - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 K39 18VT/DG IDLE AIR CONTROL NO. 1 DRIVER 2 K60 18VT/LG IDLE AIR CONTROL NO. 2 DRIVER IGNITION COIL (2.4L) - BLACK 3 WAY CAV CIR
