Page 1065 of 2399

CHRYSLER CARAVAN 2002 Service Manual C312 - GRAY (BODY SIDE) CAV CIRCUIT 1 M27 20YL/LB 2 M22 20YL/OR 3 G23 20VT/DB 4 G25 20VT/TN 5 D25 20WT/VT 6 A114 20GY/RD 7 F503 20WT/PK 8- 9 P112 20TN/OR (EXCEPT BUILT-UP-EXPORT/POWER MIRRORS) (EXCEPT

Page 1066 of 2399

CHRYSLER CARAVAN 2002 Service Manual C314 (HIGH LINE) - BLACK (BODY SIDE) CAV CIRCUIT 1 G32 20VT/LB (POWER LIFTGATE) 2 L77 18WT/BR 3 L50 18WT/TN 4 P30 20TN/DG 5 P31 20TN/DG (POWER RELEASE/ BUILT-UP-EXPORT LHD SWB GAS) 5 P31 20TN/YL (POWE

Page 1067 of 2399

CHRYSLER CARAVAN 2002 Service Manual C315 (HIGH LINE) - BLACK (LIFTGATE SIDE) CAV CIRCUIT 1 C15 12DB/WT 2 Q76 20OR/LB (POWER LIFTGATE) 3 G78 20VT/OR 4 M11 20YL/VT 5 G165 20VT/GY 6 Q85 18TN/WT (POWER LIFTGATE) 7 Q94 20TN/LG (POWER LIFTGAT

Page 1068 of 2399

CHRYSLER CARAVAN 2002 Service Manual C317 (POWER SLIDING DOOR) - BLACK (RIGHT SLIDING DOOR SIDE) CAV CIRCUIT 1 P38 20TN/DB 2 P34 20TN/LB 3 G76 20TN/OR 4 Z824 14BK/WT 5- 6- 7 G152 20VT/GY 8 D25 20WT/VT 9- 10 A113 14WT/RD C318 (TRAILER TOW

Page 1069 of 2399

CHRYSLER CARAVAN 2002 Service Manual C319 (EXCEPT BUILT-UP-EXPORT/LOW LINE) - BLACK (LIFTGATE SIDE) CAV CIRCUIT 1 C15 12DB/WT 2 L77 18WT/BR 3 L50 18WT/TN 4 P30 20TN/DG 5 P31 20TN/YL 6 G78 20VT/OR 7 M11 20YL/VT 8 W13 18BR/LG 9 F302 18GY/P

Page 1070 of 2399

CHRYSLER CARAVAN 2002 Service Manual C322 (MEMORY) - BLACK (BODY SIDE) CAV CIRCUIT 1 P69 20TN/DB (BUILT-UP-EXPORT) 1 P69 20TN/WT (EXCEPT BUILT-UP-EXPORT) 2 P67 20TN/OR 3 P64 20TN 4 P66 20TN/LG 5 P68 20TN/YL 6 P65 20TN/VT 7 D25 20WT/VT 8

Page 1071 of 2399

CHRYSLER CARAVAN 2002 Service Manual C324 (MANUAL SLIDING DOOR) - BLACK (LEFT MANUAL SLIDING DOOR SIDE) CAV CIRCUIT 1 P5 20BK/DB 2 P32 20BK/TN 3 G77 20BK/DG 4 Z77 20BK C325 (MANUAL SLIDING DOOR) - BLACK (RIGHT DOOR WIRE TRACK ASSEMBLY SI

Page 1072 of 2399

CHRYSLER CARAVAN 2002 Service Manual C327 - YELLOW (SAFETY SEAT SIDE) CAV CIRCUIT 1- 2- 3 R34 18LB/WT (EXCEPT BUILT-UP-EXPORT) 3 R34 18WT/BK (BUILT-UP-EXPORT) 4 R32 18LB/OR (EXCEPT BUILT-UP-EXPORT) 4 R32 18DG/WT (BUILT-UP-EXPORT) C329 (D
