MITSUBISHI MONTERO 1998 Service Manual Fig. 9: Testing Electric Cooling Fan Relay (Montero, Montero
Sport & 3000GT)
Courtesy of Mitsubishi Motor Sales of America.
SYSTEM TESTING
NOTE: For appropriate wiring diagram, see WIRIN

Page 282 of 1501

MITSUBISHI MONTERO 1998 Service Manual speed, coolant temperature and A/C operation request, PCM
will command low, medium or high speed fan operation.
Diamante
1) If only the radiator fan does not operat

speed, coolant temperature and A/C operation request, PCM
will command low, medium or high speed fan operation.
Diamante
1) If only the radiator fan does not operate, check fusible
link No. 6 located in engine compartment relay box. If only the
condenser fan does not operate, check dedicated fuse No. 16 (20-amp)
located in engine compartment relay box. See WIRING DIAGRAMS. Repair
as necessary.
2) If radiator fan and condenser fan operate in all speeds
except low, check appropriate low speed relay. See COMPONENT TESTS.
See WIRING DIAGRAMS . If low speed relay is okay, check PCM. See
appropriate G - TESTS W/CODES article in ENGINE PERFORMANCE.
* G - TESTS W/CODES - 1997
* G - TESTS W/CODES - 1998
3) If radiator fan and condenser fan operate in all speeds
except high, check appropriate high speed relay. See COMPONENT TESTS.
See WIRING DIAGRAMS . If high speed relay is okay, check PCM. See
appropriate G - TESTS W/CODES article in ENGINE PERFORMANCE.
* G - TESTS W/CODES - 1997
* G - TESTS W/CODES - 1998
4) To confirm radiator fan or condenser fan operation, see
FAN OPERATING MODE (DIAMANTE) table. If fan operation is not as
specified, check wiring harness for opens or shorts. Repair as
necessary.
FAN OPERATING MODE (DIAMANTE) ( 1)
\
\
\
\
\
\
\

Power Circuit
Coolant Operating Radiator Condenser
Temp.
F (C) Low/High Fan Speed Fan Speed
13 MPH ( 2)
221 (105) ( 2) ........ On/Off ....... Low ................ Low
221 (105) ( 3) ........ Off/On ....... Mid ................ Mid
239 (115) ( 3) ........ On/On ........ High .............. High
13 MPH ( 3)
221 (105) ( 2) ........ On/Off ....... Low ................ Low
221 (105) ( 2) ........ On/On ........ High .............. High
30 MPH ( 2)
203 (95) ( 2) ........ Off/Off ....... Off ................ Off
203 (95) ( 3) ......... On/Off ....... Low ................ Off
221 (105) ( 3) ........ Off/On ....... Mid ................ Mid
30 MPH ( 3)
194 (90) ( 2) ........ Off/Off ....... Off ................ Off
194 (90) ( 3) ......... On/Off ....... Low ................ Off
221 (105) ( 3) ........ On/On ........ High ............... Mid
50 MPH ( 3)
221 (105) ( 2) ....... Off/Off ....... Off ................ Off
221 (105) ( 3) ........ On/On ........ High ............... Mid
( 1) - A/C request switch is turned off.
( 2) - Approximate vehicle speed/coolant temperature or less.
( 3) - Approximate vehicle speed/coolant temperature or more.
\
\
\
\
\
\
\

NOTE: Operation of radiator and condenser fans is controlled by
vehicle Powertrain Control Module (PCM). Based on vehicle
speed, coolant temperature and A/C operation request, PCM

Page 283 of 1501

MITSUBISHI MONTERO 1998 Service Manual will command low, medium or high speed fan operation.
Eclipse
1) If only the radiator fan does not operate, check fusible
link No. 7 (20-amp) located in engine compartment r

will command low, medium or high speed fan operation.
Eclipse
1) If only the radiator fan does not operate, check fusible
link No. 7 (20-amp) located in engine compartment relay box. If only
the condenser fan does not operate, check dedicated fuse No. 9 (20-
amp) located in engine compartment relay box. See WIRING DIAGRAMS.
Repair as necessary.
2) If radiator fan and condenser fan operate in all speeds
except low, check appropriate low speed relay. See COMPONENT TESTS.
See WIRING DIAGRAMS . If low speed relay is okay, check PCM. See
appropriate G - TESTS W/CODES article in ENGINE PERFORMANCE.
* G - TESTS W/CODES - 2.0L NON-TURBO - 1997
* G - TESTS W/CODES - 2.0L TURBO - 1997
* G - TESTS W/CODES - 2.4L - 1997
* G - TESTS W/CODES - 2.0L NON-TURBO - 1998
* G - TESTS W/CODES - 2.0L TURBO & 2.4L - 1998
3) If radiator fan and condenser fan operate in all speeds
except high, check appropriate high speed relay. See COMPONENT TESTS.
See WIRING DIAGRAMS . If high speed relay is okay, check PCM. See
appropriate G - TESTS W/CODES article in ENGINE PERFORMANCE.
* G - TESTS W/CODES - 2.0L NON-TURBO - 1997
* G - TESTS W/CODES - 2.0L TURBO - 1997
* G - TESTS W/CODES - 2.4L - 1997
* G - TESTS W/CODES - 2.0L NON-TURBO - 1998
* G - TESTS W/CODES - 2.0L TURBO & 2.4L - 1998
4) To confirm radiator fan or condenser fan operation, see
FAN OPERATING MODE (ECLIPSE NON-TURBO) or FAN OPERATING MODE (ECLIPSE\
2.0L TURBO & 2.4L) table. If fan operation is not as specified, check
wiring harness for opens or shorts. Repair as necessary.
FAN OPERATING MODE (ECLIPSE NON-TURBO)
\
\
\
\
\
\
\

With A/T With M/T
Coolant Radiator Radiator Condenser
Temp.
F (C) Fan Speed Fan Speed Fan Speed
28 MPH ( 1) ( 2)
203 (95) ( 2) .......... Off ......... Off ................ Off
203-210 (95-99) ....... Mid ......... High ............... Off\
210 (99) ( 3) .......... High ........ High ............... Mid
28-50 MPH ( 1)
194 (90) ( 2) .......... Off ......... Off ................ Off
194-210 (90-99) ....... Mid ......... High ............... Off\
210 (99) ( 3) .......... High ........ High ............... Mid
50 MPH ( 1) ( 3)
210 (99) ( 2) .......... Off ......... Off ................ Mid
210 (99) ( 3) .......... High ........ High ............... Off
12 MPH ( 2) ( 4)
210 (99) ( 2) .......... Mid ......... High ............... Mid
210-242 (99-117) ...... High ........ High .............. High\
242 (117) ( 3) ......... High ........ High .............. High
12-50 MPH ( 4)
210 (99) ( 2) .......... Mid ......... High ............... Mid
210-242 (99-117) ...... High ........ High .............. High\
242 (117) ( 3) ......... High ........ High .............. High
50 MPH ( 3) ( 4)
210 (99) ( 2) .......... Mid ......... High ............... Mid
210-242 (99-117) ( 3) .. High ........ High .............. High

Page 284 of 1501

MITSUBISHI MONTERO 1998 Service Manual 242 (117) (3) ......... High ........ High .............. High
( 1) - A/C request switch is turned off.
( 2) - Approximate vehicle speed/coolant temperature or less.
( 3) - Approximate vehicle

242 (117) (3) ......... High ........ High .............. High
( 1) - A/C request switch is turned off.
( 2) - Approximate vehicle speed/coolant temperature or less.
( 3) - Approximate vehicle speed/coolant temperature or more.
( 4) - A/C request switch is turned on.
\
\
\
\
\
\
\

FAN OPERATING MODE (ECLIPSE 2.0L TURBO & 2.4L)\
\
\
\
\
\
\

With A/T With M/T
Coolant Radiator Radiator Condenser
Temp.
F (C) Fan Speed Fan Speed Fan Speed
28 MPH ( 1) ( 2)
203 (95) ( 2) .......... Off ......... Off ................ Off
203-210 (95-99) ....... Low ......... Mid ................ Off\
210 (99) ( 3) .......... High ........ High ............... Mid
28-50 MPH ( 1)
194 (90) ( 2) .......... Off ......... Off ................ Off
194-210 (90-99) ....... Low ......... Mid ................ Off\
210 (99) ( 3) .......... High ........ High ............... Mid
50 MPH ( 1) ( 3)
210 (99) ( 2) .......... Off ......... Off ................ Off
210 (99) ( 3) .......... High ........ High ............... Mid
12 MPH ( 2) ( 4)
210 (99) ( 2) .......... Low ......... Mid ................ Mid
210-242 (99-117) ...... High ........ High .............. High\
242 (117) ( 3) ......... High ........ High .............. High
12-50 MPH ( 4)
210 (99) ( 2) .......... Low ......... Mid ................ Mid
210-242 (99-117) ...... High ........ High .............. High\
242 (117) ( 3) ......... High ........ High .............. High
50 MPH ( 3) ( 4)
210 (99) ( 2) .......... Low ......... Mid ................ Mid
210-242 (99-117) ( 3) .. High ........ High .............. High
242 (117) ( 3) ......... High ........ High .............. High
( 1) - A/C request switch is turned off.
( 2) - Approximate vehicle speed/coolant temperature or less.
( 3) - Approximate vehicle speed/coolant temperature or more.
( 4) - A/C request switch is turned on.
\
\
\
\
\
\
\

NOTE: Operation of radiator and condenser fans is controlled by
vehicle Powertrain Control Module (PCM). Based on vehicle
speed, coolant temperature and A/C operation request, PCM
will command low, medium or high speed fan operation.
Galant
1) If only the radiator fan does not operate, check fusible
link No. 5 (30-amp) located in engine compartment relay box. If only
the condenser fan does not operate, check dedicated fuse No. 3 (30-
amp) located in engine compartment relay box. See WIRING DIAGRAMS.
Repair as necessary.
2) If radiator fan and condenser fan operate in all speeds
except low, check appropriate low speed relay. See COMPONENT TESTS.
See WIRING DIAGRAMS . If low speed relay is okay, check PCM. See
appropriate G - TESTS W/CODES article in ENGINE PERFORMANCE.
* G - TESTS W/CODES - 1997
* G - TESTS W/CODES - 1998

Page 285 of 1501

MITSUBISHI MONTERO 1998 Service Manual 3) If radiator fan and condenser fan operate in all speeds
except high, check appropriate high speed relay. See COMPONENT TESTS.
See WIRING DIAGRAMS . If high speed relay is okay, check PCM.

3) If radiator fan and condenser fan operate in all speeds
except high, check appropriate high speed relay. See COMPONENT TESTS.
See WIRING DIAGRAMS . If high speed relay is okay, check PCM. See
appropriate G - TESTS W/CODES article in ENGINE PERFORMANCE.
* G - TESTS W/CODES - 1997
* G - TESTS W/CODES - 1998
4) To confirm radiator fan or condenser fan operation, see
appropriate FAN OPERATING MODE (GALANT) table. If fan operation is not\
as specified, check wiring harness for opens or shorts. Repair as
necessary.
FAN OPERATING MODE (GALANT) ( 1)
\
\
\
\
\
\
\

Coolant Radiator Condenser
Temp. F (C) Fan Speed Fan Speed
28 MPH ( 2)
203 (95) ( 2) ................ Off .......................... Off
203-221 (95-105) ............ Low .......................... Low\
221 (105) ( 3) .............. High ......................... High
28-50 MPH
194 (90) ( 2) ................ Off .......................... Off
194-221 (90-105) ............ Low .......................... Low\
221 (105) ( 3) .............. High ......................... High
50 MPH ( 3)
221 (105) ( 2) ............... Off .......................... Off
221 (105) ( 3) .............. High ......................... High
Any Speed ( 4)
221 (105) ( 2) ............... Low .......................... Low
221 (105) ( 3) .............. High ......................... High
( 1) - A/C request switch is turned off.
( 2) - Approximate vehicle speed/coolant temperature or less.
( 3) - Approximate vehicle speed/coolant temperature or more.
( 4) - A/C request switch is turned on.
\
\
\
\
\
\
\

NOTE: Operation of radiator and condenser fans is controlled by
vehicle Powertrain Control Module (PCM). Based on vehicle
speed, coolant temperature and A/C operation request, PCM
will command low, medium or high speed fan operation.
Mirage
1) If only the radiator fan does not operate, check fusible
link No. 5 (30-amp) located in engine compartment relay box. If only
the condenser fan does not operate, check fusible link No. 2 (100-amp)\
and dedicated fuse No. 1 (25-amp) located in engine compartment relay
box. See WIRING DIAGRAMS . Repair as necessary.
2) If fusible links and dedicated fuse are okay, check
appropriate fan relay and/or fan motor for proper operation. See
COMPONENT TESTS. See WIRING DIAGRAMS. If fan relay and motor are okay,
check PCM. See appropriate G - TESTS W/CODES article in ENGINE
PERFORMANCE.
* G - TESTS W/CODES - 1.5L - 1997
* G - TESTS W/CODES - 1.8L - 1997
* G - TESTS W/CODES - 1998
3) To confirm radiator fan or condenser fan operation, see
appropriate FAN OPERATING MODE (MIRAGE) table. If fan operation is not\
as specified, check wiring harness for opens or shorts. Repair as

Page 286 of 1501

$MITSUBISHI MONTERO 1998 Service Manual necessary. FAN OPERATING MODE (MIRAGE) ��\ ��\ ��\ ��\ ��\ ��\ ��\ ��$

necessary.
FAN OPERATING MODE (MIRAGE)
\
\
\
\
\
\
\

Power Circuit
Coolant Operating Radiator Condenser
Temp.
F (C) RAD/COND Fan Speed Fan Speed
203 (95) ( 1) ( 2) ...... Off/Off ....... Off ................ Off
203-221 (95-105) ( 1) ... On/Off ........ On ................ Off
221 (105) ( 1) ( 3) ...... On/On ......... On ................. On
All Temp. ( 4) .......... On/On ......... On ................. On
( 1) - A/C request switch is turned off.
( 2) - Approximate coolant temperature or less.
( 3) - Approximate coolant temperature or more.
( 4) - A/C request switch is turned on.
\
\
\
\
\
\
\

NOTE: Operation of radiator and condenser fans is controlled by
vehicle Powertrain Control Module (PCM). Based on vehicle
speed, coolant temperature and A/C operation request, PCM
will command low, medium or high speed fan operation.
3000GT
1) If neither the radiator fan nor the condenser fan operate,
check fusible link No. 5 (40-amp). See WIRING DIAGRAMS. If only the
condenser fan does not operate, check dedicated fuse No. 8 (20-amp).
2) If the condenser fan operates in all speeds except low and
A/C compressor clutch does not enter the ON state, check for A/C
compressor lock controller unit output signal. If the A/C compressor
clutch does enter the ON state, check condenser fan low speed relay
operation.
3) If the radiator fan and the condenser fan operate in all
speeds except high, check PCM. See appropriate G - TESTS W/CODES
article in ENGINE PERFORMANCE. If fan operation is not as specified,
check wiring harness for opens or shorts. Repair as necessary.
* G - TESTS W/CODES - NON-TURBO - 1997
* G - TESTS W/CODES - TURBO - 1997
* G - TESTS W/CODES - 1998
4) To confirm radiator fan or condenser fan operation, see
appropriate FAN OPERATING MODE (3000GT) table. If fan operation is not\
as specified, check wiring harness for opens or shorts. Repair as
necessary.
FAN OPERATING MODE (3000GT)
\
\
\
\
\
\
\

Power Circuit
Coolant Operating Radiator Condenser
Temp.
F (C) Low/High Fan Speed Fan Speed
50 MPH ( 1) ( 2)
203 (95) ( 2) ........ Off/Off ....... Off ................ Off
203-221 (95-105) ..... On/Off ....... Low ................ Off\
221 (105) ( 3) ........ On/On ........ High .............. High
50 MPH ( 1) ( 3)
221 (105) ( 2) ....... Off/Off ....... Off ................ Off
221 (105) ( 3) ........ On/On ........ High .............. High
All Speeds
221 (105) ( 2) ........ On/Off ....... Low ................ Low
221 (105) ( 3) ........ On/On ........ High .............. High

Page 287 of 1501

MITSUBISHI MONTERO 1998 Service Manual (1) - A/C compressor lock controller output is low (zero volts).
( 2) - Approximate vehicle speed/coolant temperature or less.
( 3) - Approximate vehicle speed/coolant temperature or more.
( 4) - A/C

Page 288 of 1501

MITSUBISHI MONTERO 1998 Service Manual Fig. 11: Wiring Diagram (1997-98 Eclipse - 2.0L A/T)

Load next 8 pages

Page: < prev 1-10 ... 249-256 257-264 265-272 273-280 281-288 289-296 297-304 305-312 313-320 ... 1504 next >

checking oil coolant reservoir weight emergency towing engine oil capacity radiator
