Fig. 4: Checking Operation Of Shift Solenoids No. 1 & No. 2
Courtesy of Mitsubishi Motor Sales of America.
SELF-DIAGNOSTIC SYSTEM
SYSTEM DIAGNOSIS
NOTE: Before testing transmission, ensure fluid level is correct
and throttle and shift cables are properly adjusted. Ensure
engine starts with shift lever in Park and Neutral to ensure
proper adjustment of park/neutral position switch.
Transmission must first be tested by checking for stored
codes. See RETRIEVING DIAGNOSTIC TROUBLE CODES (DTC).
TCM monitors transmission operation and contains a self-
diagnostic system which stores a DTC if an electronic control system
failure or problem exists. If a problem exists in any of the solenoids
or speed sensors and a DTC is set, TCM delivers a signal to blink the
ATF TEMP light on instrument panel to warn the driver. DTC may be set
if a failure exists and can be retrieved for transmission diagnosis.
RETRIEVING DIAGNOSTIC TROUBLE CODES (DTC)
NOTE: Before retrieving DTC, ensure proper battery voltage exists
for proper self-diagnosis system operation. DO NOT disconnect
battery or ECM connectors before retrieving DTC.
Retrieving Codes Using Scan Tool
Ensure ignition switch is in OFF position. Connect scan tool
to Data Link Connector (DLC). See Fig. 5. Turn ignition switch to ON
position. Check for stored DTC and record code(s). See DIAGNOSTIC
TROUBLE CODE IDENTIFICATION table.

If DTC 51 is set also, go to DTC 51: 1ST GEAR RATIO SIGNAL
INCORRECT test. If DTC 51 is not set, check overdrive brake for a
mechanical failure. See OVERDRIVE BRAKE in MITSUBISHI R4AW3 & V4AW3
OVERHAUL article.
SYMPTOM TROUBLE SHOOTING
NOTE: Check system using appropriate scan tool. See WIRING DIAGRAMS
for electrical schematics and COMPONENT TESTING.
COMMUNICATION WITH SCAN TOOL NOT POSSIBLE
If scan tool cannot communicate with TCM, check proper
connection with DLC. Check TCM power circuits, TCM ground circuits and
malfunctioning TCM.
SHIFT POINTS INCORRECT
If shift points are incorrect, check for DTCs. If no DTC is
present, check oil temperature sensor, pattern select switch, 4WD low
range detection switch and TCM for proper operation.
UPSHIFTS OCCUR SPONTANEOUSLY
If upshifting occurs spontaneously, check park/neutral
position switch, overdrive switch and TCM for proper operation.
TCC LOCK-UP MALFUNCTIONING
If TCC lock-up system is not operating properly, check torque
converter, valve body, lock-up switch and oil temperature switch.
COMPONENT TESTING
A/T FLUID TEMPERATURE SWITCH
1) Remove fluid temperature switch, located to rear of
neutral safety switch. Immerse switch in container of ATF up to top
threaded portion of switch. Using a DVOM, check continuity between
switch terminals. Continuity should not exist when fluid temperature
is 257
F (125C) or less.
2) When fluid is heated to 289-304F (143-151C), continuity
should exist. Replace switch if necessary. Apply thread sealant to
fluid temperature switch threads and install in transmission.
BRAKELIGHT SWITCH
1) Disconnect electrical connector from brakelight switch,
located near brake pedal. Using ohmmeter, ensure continuity exists
between terminal No. 2 (White/Red wire) and terminal No. 3 (Green
wire) with brake pedal released. Replace brakelight switch if
continuity does not exist. Continuity should not exist between
terminals No. 2 and No. 3 with brake pedal depressed.
2) If continuity does not exist, ensure brake pedal is
properly adjusted so brakelight switch has proper travel for switch
operation. If proper brakelight switch travel exists, replace
brakelight switch.
ENGINE COOLANT TEMPERATURE (ECT) SENSOR

specified, bleed system and inspect hydraulic and clutch components.
See CLUTCH PEDAL SPECIFICATIONS table.
CLUTCH PEDAL INTERLOCK SWITCH
1) Place transmission in Neutral and apply parking brake.
Turn ignition switch to START position with clutch pedal not
depressed. Engine should not crank. If engine cranks, adjust or
replace interlock switch.
2) Disconnect interlock switch connector. Interlock switch
connector is located at clutch pedal. Depress and release interlock
switch. Using ohmmeter, check continuity between interlock switch
terminals. If continuity exists with interlock switch depressed and
does not exist with switch released, switch is okay. Adjust or replace
as necessary.
REMOVAL & INSTALLATION
CLUTCH ASSEMBLY
Removal (2WD Models)
1) Disconnect negative battery cable. Remove shift knob, dust
cover retaining plate, gaskets, stopper plate and control lever
assembly. Raise and support vehicle.
2) Remove front exhaust pipe. Drain transmission fluid. Index
mark drive shaft flange and remove drive shaft.
3) Disconnect back-up light switch connector, speedometer
cable connection and exhaust pipe mounting bracket. Remove lower
bellhousing cover. Disconnect clutch cable from clutch lever.
4) Support transmission with jack. Remove rear engine mount
nuts and bolts from transmission. Remove crossmember with rear engine
mount. Remove remaining bellhousing bolts, move transmission toward
rear and lower from vehicle.
5) If reusing pressure plate, index mark pressure plate to
flywheel for installation reference. Install a clutch alignment tool
to prevent pressure plate and clutch disc from dropping. Loosen
pressure plate bolts gradually in a crisscross pattern to avoid
warping pressure plate flange during removal. Remove pressure plate
and clutch disc. See Fig. 3.
Inspection
1) Check release bearing and release fork for damage or wear.
DO NOT clean release bearing assembly in solvent.
2) Inspect pressure plate surface for wear, cracks, and/or
discoloration. Measure diaphragm spring ends for wear and uneven
height. Replace assembly if height difference between fingers exceeds
.02" (.5 mm).
3) Check facing of clutch disc for loose rivets, uneven
contact, deterioration, seizure or oil saturation. Measure distance
from clutch disc surface to head of rivet. Replace clutch disc if
distance is less than .012" (.30 mm). Replace worn or defective
components as necessary. See Fig. 4.
CAUTION: Install clutch disc with manufacturer's stamp mark (located
near hub of clutch disc) toward pressure plate.
Installation
1) Using a clutch alignment tool, install pressure plate and
clutch disc. If reusing pressure plate, ensure index marks are
aligned. Tighten bolts evenly in a crisscross pattern to
specification. See TORQUE SPECIFICATIONS . See Fig. 3.
2) Clean release bearing sliding surface. DO NOT clean

release bearing with solvent. Apply a light coat of multipurpose
grease to release bearing sliding surface. Apply a very light coating
of grease to input shaft splines. DO NOT allow grease or dirt on
clutch disc or pressure plate surfaces.
3) To install remaining components, reverse removal
procedure. Refill all fluids to proper levels. Adjust all control
cables, clutch pedal height and free play. See CLUTCH PEDAL HEIGHT and
CLUTCH PEDAL FREE PLAY under ADJUSTMENTS. See Fig. 1.
Removal (4WD Models)
1) Remove switch panel from rear console. Remove suspension
control switch or hole cover. Disconnect rear console harness
connector. Remove side panel. Remove rear console assembly. Remove
shift lever knob(s). Remove floor console harness connector. Remove
front console assembly.
2) Move transmission lever to Neutral position and transfer
lever to 4H (4WD high range) position. Remove control lever boot
retainer and boot. Remove transmission and transfer control lever
assemblies. Remove control lever bushing (transmission), gaskets and
stopper plates.
3) Raise and support vehicle. Remove skid plate and front
exhaust pipe. Drain transmission and transfer case fluid. Index mark
front and rear drive shaft flanges. Remove front and rear drive
shafts.
4) Remove drive shaft dust seals. Disconnect HI/LO and
2WD/4WD detection switch connectors. Disconnect back-up light switch
connector. Disconnect center differential lock detection switch
connector. Disconnect center differential lock operation switch
connector. Disconnect 4WD operation detection switch.
5) Disconnect speedometer cable. Remove clutch slave cylinder
heat shield. Remove clutch slave cylinder (without disconnecting
hydraulic line) and wire aside. Remove starter and starter cover.
Remove heat shield, both transmission stays and bellhousing lower
cover.
6) Support transmission with transmission jack. Remove
transfer case roll stopper and bracket. Remove crossmember and engine
mounting rear insulator. Remove transfer case protector bracket and
mass damper. Remove remaining bellhousing bolts. Pull toward rear of
vehicle to free transmission input shaft from clutch. Lower
transmission/transfer assembly from vehicle.
7) If reusing pressure plate, mark pressure plate to flywheel
for installation reference. Insert a clutch alignment tool to prevent
pressure plate and clutch disc from dropping. Loosen pressure plate
bolts gradually in a crisscross pattern to avoid warping pressure
plate flange during removal. Remove pressure plate and clutch disc.
See Fig. 3 .
Fig. 3: Removing & Installing Clutch On Flywheel (Typical)
Courtesy of Mitsubishi Motor Sales of America.
Inspection
1) Check release bearing and release fork for damage or wear.

Apply a very light coating of grease to input shaft splines. DO NOT
allow grease or dirt on clutch disc or pressure plate surfaces.
3) To install remaining components, reverse removal
procedure. Refill all fluids to proper levels. Adjust all control
cables, clutch pedal height and free play. See CLUTCH PEDAL HEIGHT and
CLUTCH PEDAL FREE PLAY under ADJUSTMENTS. See Fig. 1.
CLUTCH RELEASE BEARING & RELEASE FORK
Removal (2WD Models)
1) Remove transmission. See CLUTCH ASSEMBLY. Remove return
clips, release bearing and carrier. Use a punch to remove shift arm
spring pin and release lever assembly. Remove shift arm, felt packing
and 2 return springs. See Fig. 5.
2) Ensure release bearing turns freely and smoothly under
light load. Replace bearing if noise, roughness or dryness is present.
DO NOT clean bearing in solvent. Use shop towel or compressed air
only.
Installation
1) Insert lever and shaft into left side of transmission
case. Place shift arm, felt packing and return springs on shaft
assembly. Apply grease to inside of bushing and oil seal lips. Apply
oil to felt packing.
2) Align shift arm pin and control shaft pin holes. Drive
spring pins into position, with slit area upward. Reverse removal
procedure to complete installation. Check pedal height and free play.
Adjust if necessary. See CLUTCH PEDAL HEIGHT and
CLUTCH PEDAL FREE PLAY under ADJUSTMENTS.
Removal (4WD Models)
1) Remove transmission. See CLUTCH ASSEMBLY. Remove return
spring or clips, and remove release bearing.
2) Slide release fork toward outside of transmission and
disengage from fulcrum ball. DO NOT slide release fork toward inside
of case, or damage to fulcrum ball clip will result. Remove release
fork boot.
Installation
To install, reverse removal procedure. Apply grease to
fulcrum ball contact area of release fork before installing. Fill
groove of release bearing inside diameter with grease before
installing. See Fig. 5.

cross shaft and rack piston for wear and damage. Check contact part of
adjusting bolt for uneven wear. Check dust seal, oil seal and "O"
rings for wear and damage.
Reassembly
1) Install NEW cross shaft lower "U" packing (if removed).
Press lower cross shaft oil seal into gearbox housing. See Fig. 3.
Press bearing and oil seal into top cover. Install bearing race and
"O" ring.
2) Apply transmission fluid to seal ring contact areas on
mainshaft, and install seal rings firmly into valve grooves. Wrap
serrated part of mainshaft with vinyl tape. Mount valve body to valve
housing. Install cage and align hole in cage with channel in
mainshaft. Install bearing race and insert balls.
3) Install mainshaft into valve housing while pressing on
bearing race to prevent balls from falling out. Using spanner wrench,
install lock nut and tighten until it contacts bearing race.
4) Tighten lock nut while measuring mainshaft endplay using
dial indicator. When mainshaft endplay is .001" (.003 mm), use a punch\
to crimp circumference of lock nut. Ensure mainshaft rotates freely.
5) Apply transmission fluid to "O" ring and piston seal ring,
and install into gearbox housing. Install rack piston until it
contacts edge of mainshaft. Rotate mainshaft to align ball raceway
with insertion hole. Install 19 balls.
NOTE: Insert balls so no clearance exists between balls.
6) Place remaining 7 balls in circulator and install
circulator to rack piston. Install circulator holder. Install NEW
cross shaft upper "U" packing (if removed). Install upper cross shaft
"O" ring. Apply transmission fluid to rack piston seal ring and insert
valve housing. Rotate mainshaft until rack piston is centered (neutral
position).
7) Install adjusting plate so beveled part is facing upward.
Using a feeler gauge, measure clearance between adjusting bolt and
cross shaft. If clearance is greater than .002" (.05 mm), replace with\
appropriate adjusting plate.
8) Apply multipurpose grease to seal surface of "U" packing.
Apply transmission fluid to cross shaft teeth and side cover "O" ring.
Install cross shaft to side cover, and temporarily tighten adjusting
bolt lock nut.
CAUTION: DO NOT rotate side cover during installation, or damage to
cross shaft oil seal may result.
9) Apply transmission fluid to rack piston teeth and shaft
areas. Apply multipurpose grease to oil seal lip. Install side cover
assembly (with cross shaft) to gearbox.
10) Position mainshaft in straight-ahead position. While
turning adjusting bolt, measure mainshaft combined starting torque
using Preload Socket (MB990228-01) and an INCH-lb. torque wrench.
Combined starting torque should be 4-11 INCH lbs. (.5-1.3 N.m). Center\
reading should be 2 INCH lbs. (.2 N.m) higher than reading at either
end.
11) Tighten adjusting bolt lock nut to specification. See
TORQUE SPECIFICATIONS . Install pitman arm with mating marks aligned.
POWER STEERING PUMP
Disassembly
1) Remove suction connector bolts. Mount pump in a soft-jawed
vise. Remove pump cover bolts and cover. Using a plastic mallet, tap
pulley assembly shaft from pump housing. See Fig. 4.

damage. Inspect groove of rotor vane and cam surface for stepped wear.
Check vane for damage. Install vane into rotor groove. Measure
clearance between vane and rotor groove. If clearance exceeds .0024"
(.061 mm), replace entire assembly.
2) Check ring and rotor sides for damage. Replace entire
assembly if any damage is present. Check sliding surfaces of control
valve for obstructions. Replace parts as required. If control valve is
replaced, always use valve with same identification mark as one being
replaced. Check power steering fluid pressure.
Reassembly
1) Lubricate "O" rings and internal pump components with ATF
before reassembly. Install flow control valve spring and control valve
in housing.
2) Install and tighten pressure connector. Depress control
valve to check for smooth operation. Apply grease to lip of oil seal.
Install oil seal into pump body. Install pulley assembly into pump
body.
3) Install rotor to pulley assembly with punch mark at pump
cover side. Install snap ring. Lift rotor to ensure that snap ring is
in countersunk part of shaft. Align cam ring dowel holes and install
cam ring with punch mark on pump body side.
4) Apply transmission fluid to vanes, and install vanes onto
rotor with rounded edges outward. Install "O" ring, cam case and pump
cover. Install and tighten suction connector.
TORQUE SPECIFICATIONS
TORQUE SPECIFICATIONS








\









\









\









\









\









\









\







Application Ft. Lbs. (N.m)\
Adjusting Bolt Lock Nut .................................... 27 (37)\
Idler Arm Bracket-To-Frame Bolt & Nut
Montero ............................................ 40-47 (54-64)\
Montero Sport ............................................ 43 (59)\
Idler Arm-To-Bracket Lock Nut ............................. 101 (44)\
Oil Pump Cover Bolts ....................................... 15 (20)\
Pitman Arm-To-Cross Shaft Nut
Montero ........................................ 108-123 (146-176)\
Montero Sport .................................. 108-123 (147-167)\
Pressure Hose In-Line Fitting
Montero .................................................. 25 (34)\
Montero Sport ............................................ 16 (22)\
Relay Rod-To-Idler Arm Nut ................................. 33 (44)\
Relay Rod-To-Pitman Arm Nut ................................ 33 (44)\
Side Cover Bolts
Montero .................................................. 36 (49)\
Montero Sport ...................................... 41-47 (50-64)\
Steering Gear Hose Fittings ................................ 11 (15)\
Steering Gear-To-Frame Bolts ......................... 40-47 (54-64)\
Tie Rod Adjusting Sleeve Lock Nuts ......................... 69 (93)\
Tie Rod End Castle Nuts .................................... 33 (44)\
Valve Housing Bolts
Montero .................................................. 36 (49)\
Montero Sport ...................................... 41-47 (56-64)\
Valve Housing Lock Nut ......................................... ( 1)
( 1) - Tighten lock nut until it contacts bearing race.









\









\









\









\









\









\









\

TRANSMISSION SERVICING - A/T
1998 Mitsubishi Montero
1997-98 TRANSMISSION SERVICING
Mitsubishi Automatic Transmission
Diamante, Eclipse, Galant, Mirage, Montero, 3000GT
IDENTIFICATION
AUTOMATIC TRANSMISSION APPLICATIONS








\









\









\









\









\









\









\







Model Transmission/Transaxle
Diamante ..................................... Model F4A51 Transaxle
Eclipse
AWD ........................................ Model W4A33 Transaxle
FWD
2.0L Non-Turbo ........................... Model F4AC1 Transaxle
2.0L Turbo ............................... Model F4A33 Transaxle
2.4L ....................................... Model F4A23 Transaxle
Galant ....................................... Model F4A23 Transaxle
Mirage
1.5L ....................................... Model F4A41 Transaxle
1.8L ....................................... Model F4A42 Transaxle
Montero
2WD ..................................... Model R4AW3 Transmission
4WD ..................................... Model V4AW3 Transmission
3000GT ....................................... Model F4A33 Transaxle









\









\









\









\









\









\









\







LUBRICATION
SERVICE INTERVALS
Transaxle/Transmission
Check fluid level every 12 months or 15,000 miles. Change
fluid and filter every 30,000 miles. If vehicle is operated under
severe conditions, change fluid more often. If severe darkening of
fluid and strong odor are noted, bands should also be adjusted.
Transfer Case
On 4WD and AWD models, change transfer case fluid every 30,
000 miles.
CHECKING FLUID LEVEL
Transaxle/Transmission
1) Park vehicle on level area. Ensure oil is at normal
operating temperature, parking brake is engaged, and engine is at
idle. Move gear selector through each position, stopping briefly at
each selection.
2) Place gear selector in Neutral, and clean area around
dipstick tube. Ensure fluid level is between lower and upper marks,
but never over upper mark, in HOT range. Add or drain fluid if
necessary.
CAUTION: If severe darkening of fluid and strong odor are noted,
change fluid and filter, and adjust bands.
Transfer Case (All Others)
