1998 MITSUBISHI MONTERO Service Manual

Page 1241 of 1501

MITSUBISHI MONTERO 1998  Service Manual   Upper  ..............................................  44-65 (59-88)\
Ball Joint-To-Lower Control Arm Bolt  .......................  60 (81)\
Ball Joint-To-Upper Control Arm Bolt  ................

Page 1242 of 1501

MITSUBISHI MONTERO 1998  Service Manual SUSPENSION - REAR
1998 Mitsubishi Montero
         1997-98 SUSPENSION
          Rear - RWD & 4WD
          Montero, Montero Sport
         DESCRIPTION
NOTE:    For testing and diagnosis information o

Page 1243 of 1501

MITSUBISHI MONTERO 1998  Service Manual Fig. 2:  Exploded View Of Rear Suspension (Montero)
Courtesy of Mitsubishi Motor Sales of America.
         ADJUSTMENTS & INSPECTION
          WHEEL ALIGNMENT SPECIFICATIONS & PROCEDURES
NOTE:    Whee

Page 1244 of 1501

MITSUBISHI MONTERO 1998  Service Manual          REAR SUSPENSION ASSEMBLY
NOTE:    Procedures for Montero are for lateral rod, coil springs and
         lower arms only. Procedures for Montero Sport are for leaf
         springs only.

Page 1245 of 1501

MITSUBISHI MONTERO 1998  Service Manual          2) Remove upper shock mounting nuts and washers. On Montero
remove shock lower mounting nuts and bolts. On Montero Sport remove
shock lower mounting nuts and washers. Remove shock assembly.

Page 1246 of 1501

MITSUBISHI MONTERO 1998  Service Manual * SUSPENSION UNIFORM INSPECTION GUIDELINES *
1998 Mitsubishi Montero
         GENERAL INFORMATION
          Steering, Suspension, Wheel Alignment, Wheels and Tires
          Motorist Assurance Progra

Page 1247 of 1501

MITSUBISHI MONTERO 1998  Service Manual          TIE ROD ENDS (INNER AND OUTER)
          TRACK BARS
          TRAILING ARMS
          WHEEL BEARINGS, RACES AND SEALS
          Wheel Alignment
          WHEEL ALIGNMENT
          Wheels and

Page 1248 of 1501

MITSUBISHI MONTERO 1998  Service Manual profit organizations. MAP conducted pilot programs in twelve states
before announcing the program nationally in October, 1998. During the
pilots, participating repair shops demonstrated their adherenc
