Page 1425 of 1501

MITSUBISHI MONTERO 1998 Service Manual Loose or worn wheel See WHEEL ALIGNMENT
bearings
Loose or worn tie rod ends See SUSPENSION
Worn upper ball joints

Loose or worn wheel See WHEEL ALIGNMENT
bearings
Loose or worn tie rod ends See SUSPENSION
Worn upper ball joints See Ball Joint Checking
in SUSPENSION
Worn shock absorbers Replace shock absorbers
Worn strut bushings Replace strut bushings
\
\
\
\
\
\
\

Car Pulls to Mismatched or uneven tires Check tire condition
One Side
Broken or sagging springs See SUSPENSION
Loose or worn strut See SUSPENSION
bushings
Improper wheel alignment See WHEEL ALIGNMENT
Improper rear axle Check rear axle
alignment alignment
Power steering gear See STEERING
unbalanced
Front brakes dragging See BRAKES
\
\
\
\
\
\
\

Abnormal Tire Unbalanced tires Check tire balance &
Wear rotation
Sagging or broken springs See SUSPENSION
Incorrect front end See WHEEL ALIGNMENT
alignment
Faulty shock absorbers Replace chock absorbers
\
\
\
\
\
\
\

Scuffed Tires Toe-In incorrect See WHEEL ALIGNMENT
Suspension arm bent or See appropriate
twisted SUSPENSION article
\
\
\
\
\
\
\

Springs Bottom Bent or broken springs See SUSPENSION
or Sag
Leaking or worn shock Replace shock absorbers
absorbers
Frame misalignment Check frame for damage
\
\
\
\
\
\
\

Spring Noises Loose "U" Bolts See SUSPENSION
Loose or worn bushings See SUSPENSION
Worn or missing interliners See SUSPENSION
\
\
\
\
\
\
\

Shock Absorber Loose shock mountings Check & tighten
Noise mountings
Worn bushings Replace bushings

Page 1426 of 1501

$MITSUBISHI MONTERO 1998 Service Manual Air in system Bleed air from system Undercoating on shocks Remove undercoating ��\ ��\ ��\ ��$

Air in system Bleed air from system
Undercoating on shocks Remove undercoating
\
\
\
\
\
\
\

Car Leans or Loose stabilizer bar See SUSPENSION
Sways on Corners
Faulty shocks or mountings Replace shocks or
mountings
Broken or sagging springs See SUSPENSION
\
\
\
\
\
\
\

Shock Absorbers Worn seals or reservoir See SUSPENSION
Leaking tube crimped
\
\
\
\
\
\
\

Broken Springs Loose "U" bolts See SUSPENSION
Inoperative shock absorbers Replace shock absorbers
\
\
\
\
\
\
\

WHEEL ALIGNMENT TROUBLE SHOOTING
NOTE: This is GENERAL information. This article is not intended
to be specific to any unique situation or individual vehicle
configuration. The purpose of this Trouble Shooting
information is to provide a list of common causes to
problem symptoms. For model-specific Trouble Shooting,
refer to SUBJECT, DIAGNOSTIC, or TESTING articles available
in the section(s) you are accessing.
BASIC WHEEL ALIGNMENT TROUBLE SHOOTING CHART
\
\
\
\
\
\
\

CONDITION POSSIBLE CAUSE CORRECTION\
\
\
\
\
\
\

Premature Tire Improper tire inflation Check tire pressure
Wear
Front alignment out of See ALIGNMENT SPECS in
tolerance WHEEL ALIGNMENT section
Suspension components worn See SUSPENSION section
Steering system components See STEERING section
worn
Improper standing height See WHEEL ALIGNMENT
Uneven or sagging springs See SUSPENSION section
Bent wheel See WHEEL ALIGNMENT
Improper torsion bar See SUSPENSION section
adjustment
Loose or worn wheel See WHEEL BEARING ADJ.
bearings in SUSPENSION section
Worn or defective shock Replace shock absorbers
Tires out of balance Check tire balance
\
\
\
\
\
\
\

Pulls to One Improper tire inflation Check tire pressure
Side
Brake dragging See BRAKE section

Page 1427 of 1501

MITSUBISHI MONTERO 1998 Service Manual Mismatched tires See WHEEL ALIGNMENT
Broken or sagging spring See SUSPENSION section
Broken torsion bar See SUSPENSION s

Mismatched tires See WHEEL ALIGNMENT
Broken or sagging spring See SUSPENSION section
Broken torsion bar See SUSPENSION section
Power steering valve not See STEERING section
centered
Front alignment out of See WHEEL ALIGNMENT
tolerance section
Defective wheel bearing See WHEEL BEARINGS in
SUSPENSION section
Uneven sway bar links See SUSPENSION section
Frame bent Check for frame damage
Steering system bushing See STEERING section
worn
\
\
\
\
\
\
\

Hard Steering Idler arm bushing too tight See STEERING LINKAGE
in STEERING section
Ball joint tight or seized See SUSPENSION section
Steering linkage too tight See STEERING LINKAGE in
STEERING section
Power steering fluid low Add proper amount of
fluid
Power steering drive belt See STEERING section
loose
Power steering pump See STEERING section
defective
Steering gear out of See STEERING section
adjustment
Incorrect wheel alignment See WHEEL ALIGNMENT
Damaged steering gear See STEERING section
Damaged suspension See SUSPENSION section
Bent steering knuckle or See SUSPENSION section
supports
\
\
\
\
\
\
\

Vehicle Strut rod or control arm See SUSPENSION section
"Wanders" bushing worn
Loose or worn wheel See WHEEL BEARINGS in
bearings SUSPENSION section
Improper tire inflation Check tire pressure
Stabilizer bar missing or See SUSPENSION section
defective

Page 1428 of 1501

MITSUBISHI MONTERO 1998 Service Manual Wheel alignment out of See Adjustment in
tolerance WHEEL ALIGNMENT section
Broken spring See SUSPENSION se

Page 1429 of 1501

MITSUBISHI MONTERO 1998 Service Manual WAVEFORMS - INJECTOR PATTERN TUTORIAL
1998 Mitsubishi Montero
GENERAL INFORMATION
Waveforms - Injector Pattern Tutorial
* PLEASE READ THIS FIRST *
NOTE: This article is

WAVEFORMS - INJECTOR PATTERN TUTORIAL
1998 Mitsubishi Montero
GENERAL INFORMATION
Waveforms - Injector Pattern Tutorial
* PLEASE READ THIS FIRST *
NOTE: This article is intended for general information purposes
only. This information may not apply to all makes and models.
PURPOSE OF THIS ARTICLE
Learning how to interpret injector drive patterns from a Lab
Scope can be like learning ignition patterns all over again. This
article exists to ease you into becoming a skilled injector pattern
interpreter.
You will learn:
* How a DVOM and noid light fall short of a lab scope.
* The two types of injector driver circuits, voltage controlled
& current controlled.
* The two ways injector circuits can be wired, constant
ground/switched power & constant power/switched ground.
* The two different pattern types you can use to diagnose with,
voltage & current.
* All the valuable details injector patterns can reveal.
SCOPE OF THIS ARTICLE
This is NOT a manufacturer specific article. All different
types of systems are covered here, regardless of the specific
year/make/model/engine.
The reason for such broad coverage is because there are only
a few basic ways to operate a solenoid-type injector. By understanding
the fundamental principles, you will understand all the major points
of injector patterns you encounter. Of course there are minor
differences in each specific system, but that is where a waveform
library helps out.
If this is confusing, consider a secondary ignition pattern.
Even though there are many different implementations, each still has
a primary voltage turn-on, firing line, spark line, etc.
If specific waveforms are available in On Demand for the
engine and vehicle you are working on, you will find them in the
Engine Performance section under the Engine Performance category.
IS A LAB SCOPE NECESSARY?
INTRODUCTION
You probably have several tools at your disposal to diagnose
injector circuits. But you might have questioned "Is a lab scope
necessary to do a thorough job, or will a set of noid lights and a
multifunction DVOM do just as well?"
In the following text, we are going to look at what noid
lights and DVOMs do best, do not do very well, and when they can
mislead you. As you might suspect, the lab scope, with its ability to
look inside an active circuit, comes to the rescue by answering for
the deficiencies of these other tools.
OVERVIEW OF NOID LIGHT

Page 1430 of 1501

MITSUBISHI MONTERO 1998 Service Manual The noid light is an excellent "quick and dirty" tool. It can
usually be hooked to a fuel injector harness fast and the flashing
light is easy to understand. It is a dependable way to identif

The noid light is an excellent "quick and dirty" tool. It can
usually be hooked to a fuel injector harness fast and the flashing
light is easy to understand. It is a dependable way to identify a no-
pulse situation.
However, a noid light can be very deceptive in two cases:
* If the wrong one is used for the circuit being tested.
Beware: Just because a connector on a noid light fits the
harness does not mean it is the right one.
* If an injector driver is weak or a minor voltage drop is
present.
Use the Right Noid Light
In the following text we will look at what can happen if the
wrong noid light is used, why there are different types of noid lights
(besides differences with connectors), how to identify the types of
noid lights, and how to know the right type to use.
First, let's discuss what can happen if the incorrect type of
noid light is used. You might see:
* A dimly flashing light when it should be normal.
* A normal flashing light when it should be dim.
A noid light will flash dim if used on a lower voltage
circuit than it was designed for. A normally operating circuit would
appear underpowered, which could be misinterpreted as the cause of a
fuel starvation problem.
Here are the two circuit types that could cause this problem:
* Circuits with external injector resistors. Used predominately
on some Asian & European systems, they are used to reduce the
available voltage to an injector in order to limit the
current flow. This lower voltage can cause a dim flash on a
noid light designed for full voltage.
* Circuits with current controlled injector drivers (e.g. "Peak
and Hold"). Basically, this type of driver allows a quick
burst of voltage/current to flow and then throttles it back
significantly for the remainder of the pulse width duration.
If a noid light was designed for the other type of driver
(voltage controlled, e.g. "Saturated"), it will appear dim
because it is expecting full voltage/current to flow for the
entire duration of the pulse width.
Let's move to the other situation where a noid light flashes
normally when it should be dim. This could occur if a more sensitive
noid light is used on a higher voltage/amperage circuit that was
weakened enough to cause problems (but not outright broken). A circuit\
with an actual problem would thus appear normal.
Let's look at why. A noid light does not come close to
consuming as much amperage as an injector solenoid. If there is a
partial driver failure or a minor voltage drop in the injector
circuit, there can be adequate amperage to fully operate the noid
light BUT NOT ENOUGH TO OPERATE THE INJECTOR.
If this is not clear, picture a battery with a lot of
corrosion on the terminals. Say there is enough corrosion that the
starter motor will not operate; it only clicks. Now imagine turning on
the headlights (with the ignition in the RUN position). You find they
light normally and are fully bright. This is the same idea as noid
light: There is a problem, but enough amp flow exists to operate the
headlights ("noid light"), but not the starter motor ("injector").
How do you identify and avoid all these situations? By using
the correct type of noid light. This requires that you understanding

Page 1431 of 1501

MITSUBISHI MONTERO 1998 Service Manual the types of injector circuits that your noid lights are designed for.
There are three. They are:
* Systems with a voltage controlled injector driver. Another
way to say it: The noid l

the types of injector circuits that your noid lights are designed for.
There are three. They are:
* Systems with a voltage controlled injector driver. Another
way to say it: The noid light is designed for a circuit with
a "high" resistance injector (generally 12 ohms or above).
* Systems with a current controlled injector driver. Another
way to say it: The noid light is designed for a circuit with
a low resistance injector (generally less than 12 ohms)
without an external injector resistor.
* Systems with a voltage controlled injector driver and an
external injector resistor. Another way of saying it: The
noid light is designed for a circuit with a low resistance
injector (generally less than 12 ohms) and an external
injector resistor.
NOTE: Some noid lights can meet both the second and third
categories simultaneously.
If you are not sure which type of circuit your noid light is
designed for, plug it into a known good car and check out the results.
If it flashes normally during cranking, determine the circuit type by
finding out injector resistance and if an external injector resistor
is used. You now know enough to identify the type of injector circuit.
Label the noid light appropriately.
Next time you need to use a noid light for diagnosis,
determine what type of injector circuit you are dealing with and
select the appropriate noid light.
Of course, if you suspect a no-pulse condition you could plug
in any one whose connector fit without fear of misdiagnosis. This is
because it is unimportant if the flashing light is dim or bright. It
is only important that it flashes.
In any cases of doubt regarding the use of a noid light, a
lab scope will overcome all inherent weaknesses.
OVERVIEW OF DVOM
A DVOM is typically used to check injector resistance and
available voltage at the injector. Some techs also use it check
injector on-time either with a built-in feature or by using the
dwell/duty function.
There are situations where the DVOM performs these checks
dependably, and other situations where it can deceive you. It is
important to be aware of these strengths and weaknesses. We will cover
the topics above in the following text.
Checking Injector Resistance
If a short in an injector coil winding is constant, an
ohmmeter will accurately identify the lower resistance. The same is
true with an open winding. Unfortunately, an intermittent short is an
exception. A faulty injector with an intermittent short will show
"good" if the ohmmeter cannot force the short to occur during testing.
Alcohol in fuel typically causes an intermittent short,
happening only when the injector coil is hot and loaded by a current
high enough to jump the air gap between two bare windings or to break
down any oxides that may have formed between them.
When you measure resistance with an ohmmeter, you are only
applying a small current of a few milliamps. This is nowhere near
enough to load the coil sufficiently to detect most problems. As a
result, most resistance checks identify intermittently shorted
injectors as being normal.
There are two methods to get around this limitation. The
first is to purchase an tool that checks injector coil windings under

Page 1432 of 1501

MITSUBISHI MONTERO 1998 Service Manual full load. The Kent-Moore J-39021 is such a tool, though there are
others. The Kent-Moore costs around $240 at the time of this writing
and works on many different manufacturers systems.
The

full load. The Kent-Moore J-39021 is such a tool, though there are
others. The Kent-Moore costs around $240 at the time of this writing
and works on many different manufacturer's systems.
The second method is to use a lab scope. Remember, a lab
scope allows you to see the regular operation of a circuit in real
time. If an injector is having an short or intermittent short, the lab
scope will show it.
Checking Available Voltage At the Injector
Verifying a fuel injector has the proper voltage to operate
correctly is good diagnostic technique. Finding an open circuit on the
feed circuit like a broken wire or connector is an accurate check with
a DVOM. Unfortunately, finding an intermittent or excessive resistance
problem with a DVOM is unreliable.
Let's explore this drawback. Remember that a voltage drop due
to excessive resistance will only occur when a circuit is operating?
Since the injector circuit is only operating for a few milliseconds at
a time, a DVOM will only see a potential fault for a few milliseconds.
The remaining 90+% of the time the unloaded injector circuit will show
normal battery voltage.
Since DVOMs update their display roughly two to five times a
second, all measurements in between are averaged. Because a potential
voltage drop is visible for such a small amount of time, it gets
"averaged out", causing you to miss it.
Only a DVOM that has a "min-max" function that checks EVERY
MILLISECOND will catch this fault consistently (if used in that mode).\
The Fluke 87 among others has this capability.
A "min-max" DVOM with a lower frequency of checking (100
millisecond) can miss the fault because it will probably check when
the injector is not on. This is especially true with current
controlled driver circuits. The Fluke 88, among others fall into this
category.
Outside of using a Fluke 87 (or equivalent) in the 1 mS "min-\
max" mode, the only way to catch a voltage drop fault is with a lab
scope. You will be able to see a voltage drop as it happens.
One final note. It is important to be aware that an injector
circuit with a solenoid resistor will always show a voltage drop when
the circuit is energized. This is somewhat obvious and normal; it is a
designed-in voltage drop. What can be unexpected is what we already
covered--a voltage drop disappears when the circuit is unloaded. The
unloaded injector circuit will show normal battery voltage at the
injector. Remember this and do not get confused.
Checking Injector On-Time With Built-In Function
Several DVOMs have a feature that allows them to measure
injector on-time (mS pulse width). While they are accurate and fast to\
hookup, they have three limitations you should be aware of:
* They only work on voltage controlled injector drivers (e.g
"Saturated Switch"), NOT on current controlled injector
drivers (e.g. "Peak & Hold").
* A few unusual conditions can cause inaccurate readings.
* Varying engine speeds can result in inaccurate readings.
Regarding the first limitation, DVOMs need a well-defined
injector pulse in order to determine when the injector turns ON and
OFF. Voltage controlled drivers provide this because of their simple
switch-like operation. They completely close the circuit for the
entire duration of the pulse. This is easy for the DVOM to interpret.
The other type of driver, the current controlled type, start
off well by completely closing the circuit (until the injector pintle
opens), but then they throttle back the voltage/current for the
duration of the pulse. The DVOM understands the beginning of the pulse

Load next 8 pages

Page: < prev 1-10 ... 1393-1400 1401-1408 1409-1416 1417-1424 1425-1432 1433-1440 1441-1448 1449-1456 1457-1464 ... 1504 next >

jack points wheel bolts deactivate airbag wheel torque engine oil capacity brake pads
