1998 MITSUBISHI MONTERO Service Manual

thoroughly with soap and water.
CAUTION: Never use non-detergent or straight mineral oil.
FUEL SYSTEM SERVICE
WARNING: Relieve fuel system pressure prior to servicing any fuel
system component (fuel injection models).
HALOGEN BULBS
Halogen bulbs contain pressurized gas which may explode if
overheated. DO NOT touch glass portion of bulb with bare hands. Eye
protection should be worn when handling or working around halogen
bulbs.
RADIATOR CAP
CAUTION: Always disconnect the fan motor when working near the
radiator fan. The fan is temperature controlled and could
start at any time even when the ignition key is in the OFF
position. DO NOT loosen or remove radiator cap when cooling
system is hot.
RADIATOR FAN
WARNING: Keep hands away from radiator fan. Fan is controlled by a
thermostatic switch which may come on or run for up to 15 minutes even
after engine is turned off.
WARRANTY INFORMATION
CAUTION: Due to the different warranties offered in various regions
and the variety of after-market extended warranties
available, please refer to the warranty package that came
with the vehicle to verify all warranty options.
FUSES & CIRCUIT BREAKERS
FUSE PANEL LOCATION
The electrical system is protected against shorts by fuses
that are designed to fail, to prevent damage to the wire harness. The
fuse block is located under the instrument panel on the driver's side.
If a fuse is blown, locate the cause before replacing the fuse. Spare
fuses are contained in the fuse block.
FUSE PANEL IDENTIFICATION
Fuse & Circuit Breaker Identification
PASSENGER COMPARTMENT

Fig. 3: Passenger Compartment Fuse Box
Courtesy of Mitsubishi Motor Sales of America.
1 - 15 Amp (Light Blue)
Cigarette Lighter

2 - 10 Amp (Red)
Radio
3 - 10 Amp (Red)
Heater Relay
4 - 10 Amp (Red)
4A/T
5 - 20 Amp (Yellow)
Front & Rear Air Conditioner
6 - 10 Amp (Red)
Turn Signals
7 - 10 Amp (Red)
Meters
8 - 10 Amp (Red)
Horn
9 - 15 Amp (Light Blue)
Wiper
10 - 10 Amp (Red)
Power Window Control
11 - 10 Amp (Red)
Four Wheel Drive System, Overdrive Control (Vehicles With
Automatic Transmission Only)
12 - 15 Amp (Light Blue)
Power Door Locks
13 - 10 Amp (Red)
Doom Light, Clock
14 - 15 Amp (Light Blue)
Backup Lights
15 - 15 Amp (Light Blue)
Stoplights
16 - 25 Amp
Heater
17 - 15 Amp (Light Blue)
Accessory Socket
18 - 10 Amp (Red)
Rear Heater
19 - Spare Fuse
ENGINE COMPARTMENT
Fig. 4: Engine Compartment Fusible Links
Courtesy of Mitsubishi Motor Sales of America.

1 - 60 Amp
Battery
2 - 100 Amp
Alternator
3 - 20 Amp (Yellow)
Multipoint Injection
4 - 40 Amp
Ignition Switch
5 - 30 Amp (Green)
Rear Window Defogger
6 - 30 Amp (Green)
Power Window Control
7 - 30 Amp (Green)
Air Conditioner
8 - 40 Amp
Lights
9 - 10 Amp (Red)
AIR CONDITIONING & HEAT Compressor
10 - 25 Amp
Condenser Fan
11 - 10 Amp (Red)
Tail Lights
12 - 10 Amp (Red)
Headlight Upper Beam
13 - 10 Amp (Red)
Hazard Warning Flashers

METRIC CONVERSIONS
1998 Mitsubishi Montero
GENERAL INFORMATION
METRIC CONVERSIONS
METRIC CONVERSIONS
Metric conversions are making life more difficult for the
mechanic. In addition to doubling the number of tools required,
metric-dimensioned nuts and bolts are used alongside English
components in many new vehicles. The mechanic has to decide which tool
to use, slowing down the job. The tool problem can be solved by trial
and error, but some metric conversions aren't so simple. Converting
temperature, lengths or volumes requires a calculator and conversion
charts, or else a very nimble mind. Conversion charts are only part of
the answer though, because they don't help you "think" metric, or
"visualize" what you are converting. The following examples are
intended to help you "see" metric sizes:
LENGTH
Meters are the standard unit of length in the metric system.
The smaller units are 10ths (decimeter), 100ths (centimeter), and
1000ths (millimeter) of a meter. These common examples might help you
to visualize the metric units:
* A meter is slightly longer than a yard (about 40 inches).
* An aspirin tablet is about one centimeter across (.4 inches).
* A millimeter is about the thickness of a dime.
VOLUME
Cubic meters and centimeters are used to measure volume, just
as we normally think of cubic feet and inches. Liquid volume
measurements include the liter and milliliter, like the English quarts
or ounces.
* One teaspoon is about 4 cubic centimeters.
* A liter is about one quart.
* A liter is about 61 cubic inches.
WEIGHT
The metric weight system is based on the gram, with the most
common unit being the kilogram (1000 grams). Our comparable units are
ounces and pounds:
* A kilogram is about 2.2 pounds.
* An ounce is about 28 grams.
TORQUE
Torque is somewhat complicated. The term describes the amount
of effort exerted to turn something. A chosen unit of weight or force
is applied to a lever of standard length. The resulting leverage is
called torque. In our standard system, we use the weight of one pound
applied to a lever a foot long, resulting in the unit called a foot-
pound. A smaller unit is the inch-pound (the lever is one inch long).
Metric units include the meter kilogram (lever one meter long
with a kilogram of weight applied) and the Newton-meter (lever one

meter long with force of one Newton applied). Some conversions are:
* A meter kilogram is about 7.2 foot pounds.
* A foot pound is about 1.4 Newton-meters.
* A centimeter kilogram (cmkg) is equal to .9 inch pounds.
PRESSURE
Pressure is another complicated measurement. Pressure is
described as a force or weight applied to a given area. Our common
unit is pounds per square inch. Metric units can be expressed in
several ways. One is the kilogram per square centimeter (kg/cm
).
Another unit of pressure is the Pascal (force of one Newton on an area
of one square meter), which equals about 4 ounces on a square yard.
Since this is a very small amount of pressure, we usually see the
kiloPascal, or kPa (1000 Pascals). Another common automotive term for
pressure is the bar (used by German manufacturers), which equals 10
Pascals. Thoroughly confused? Try the examples below:
* Atmospheric pressure at sea level is about 14.7 psi.
* Atmospheric pressure at sea level is about 1 bar.
* Atmospheric pressure at sea level is about 1 kg/cm
.
* One pound per square inch is about 7 kPa.
CONVERSION FACTORS
CONVERSION FACTORS
\
\
\
\
\
\
\

TO CONVERT TO  MULTIPLY BY
\b
\
\
\
\
\
 \
\



LENGTH


Millimeters (mm) Inches  .03937

Inches Millimeters  25.4

Meters (M) Feet  3.28084

Feet Meters  .3048

Kilometers(Km) Miles  .62137
\b
\
\
\
\
\
 \
\



AREA


Square Centimeters (cm) Square Inches  .155

Square Inches Square Centimeters  6.45159
\b
\
\
\
\
\
 \
\



VOLUME


Cubic Centimeters Cubic Inches  .06103

Cubic Inches Cubic Centimeters  16.38703

Liters Cubic Inches  61.025

Cubic Inches Liters  .01639

Liters Quarts  1.05672

Quarts Liters  .94633

Liters Pints  2.11344

Pints Liters  .47317

Liters Ounces  33.81497

Ounces Liters  .02957
\b
\
\
\
\
\
 \
\



WEIGHT


Grams Ounces  .03527

Ounces Grams  28.34953

Kilograms Pounds  2.20462

Pounds Kilograms  .45359
\b
\
\
\
\
\
 \
\



WORK


Centimeter Kilograms Inch Pounds  .8676

Pounds/Sq. Inch Kilograms/Sq.Centimeter .07031

Bar Pounds/Sq. Inch  14.504

Pounds/Sq. Inch Bar  .06895

Atmosphere Pounds/Sq. Inch  14.696

Pounds/Sq. Inch Atmosphere  .06805
\b
\
\
\
\
\
 \
\



TEMPERATURE


Centigrade Degrees Fahrenheit Degrees (Cx(9)/5)+32

Fahrenheit Degrees Centigrade Degrees (F-32)x(5)/9
\f
\
\
\

\
\

\
\

CONVERSION FACTORS (Cont.)
\
\
\
\
\
\
\

INCHES DECIMALS mm

\b
\
\
\
\
\
\
\





1/64 ...................... .016 ........................ .397

1/32 ...................... .031 ........................ .794

3/64 ...................... .047 ....................... 1.191

1/16 ...................... .063 ....................... 1.588

5/64 ...................... .078 ....................... 1.984

3/32 ...................... .094 ....................... 2.381

7/64 ...................... .109 ....................... 2.778

1/8 ....................... .125 ....................... 3.175

9/64 ...................... .141 ....................... 3.572

5/32 ...................... .156 ....................... 3.969

11/64 ..................... .172 ....................... 4.366

3/16 ...................... .188 ....................... 4.763

13/64 ..................... .203 ....................... 5.159

7/32 ...................... .219 ....................... 5.556

15/64 ..................... .234 ....................... 5.953

1/4 ....................... .250 ....................... 6.350

17/64 ..................... .266 ....................... 6.747

9/32 ...................... .281 ....................... 7.144

19/64 ..................... .297 ....................... 7.541

5/16 ...................... .313 ....................... 7.938

21/64 ..................... .328 ....................... 8.334

11/32 ..................... .344 ....................... 8.731

23/64 ..................... .359 ....................... 9.128

3/8 ....................... .375 ....................... 9.525

25/64 ..................... .391 ....................... 9.992

13/32 ..................... .406 ...................... 10.319

27/64 ..................... .422 ...................... 10.716

7/16 ...................... .438 ...................... 11.113

29/64 ..................... .453 ...................... 11.509

15/32 ..................... .469 ...................... 11.906

31/64 ..................... .484 ...................... 12.303

1/2 ....................... .500 ...................... 12.700

33/64 ..................... .516 ...................... 13.097

17/32 ..................... .531 ...................... 13.494

35/64 ..................... .547 ...................... 13.891

9/16 ...................... .563 ...................... 14.288

37/64 ..................... .578 ...................... 14.684

19/32 ..................... .594 ...................... 15.081

39/64 ..................... .609 ...................... 15.478

5/8 ....................... .625 ...................... 15.875

41/64 ..................... .641 ...................... 16.272

21/32 ..................... .656 ...................... 16.669

43/64 ..................... .672 ...................... 17.066

11/16 ..................... .687 ...................... 17.463

45/64 ..................... .703 ...................... 17.859

23/32 ..................... .719 ...................... 18.256

47/64 ..................... .734 ...................... 18.653

3/4 ....................... .750 ...................... 19.050

49/64 ..................... .766 ...................... 19.447

25/32 ..................... .781 ...................... 19.844

51/64 ..................... .797 ...................... 20.241

13/16 ..................... .813 ...................... 20.638

53/64 ..................... .828 ...................... 21.034

27/32 ..................... .844 ...................... 21.431

55/64 ..................... .859 ...................... 21.828

7/8 ....................... .875 ...................... 22.225

57/64 ..................... .891 ...................... 22.622

29/32 ..................... .906 ...................... 23.019

59/64 ..................... .922 ...................... 23.416

15/16 ..................... .938 ...................... 23.813

61/64 ..................... .953 ...................... 24.209

31/32 ..................... .969 ...................... 24.606

63/64 ..................... .984 ...................... 25.003

1 ......................... 1.000 ..................... 25.400
\f
\
\
\
\
\
\
\
